AIR PURIFIER
PURY PRO
OPERATING INSTRUCTIONS
Read the instructions carefully before operating or servicing the air purifier.
Observe all the safety instructions; failure to observe the instructions may lead to accidents and/or
damage. Store these instructions in a safe place for future reference.
V 05/20
15

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PURY PRO and is the answer not in the manual?

Questions and answers

Related Manuals for Argo PURY PRO

Summary of Contents for Argo PURY PRO

  • Page 1 AIR PURIFIER PURY PRO OPERATING INSTRUCTIONS Read the instructions carefully before operating or servicing the air purifier. Observe all the safety instructions; failure to observe the instructions may lead to accidents and/or damage. Store these instructions in a safe place for future reference.
  • Page 2 GENERAL OPERATING AND SAFETY INSTRUCTIONS  This appliance is a highly efficient air purifier designed for domestic use only!  Use this air purifier only as outlined in this manual. Any other use not recommended by the manufacturer may cause fire, electric shock or malfunctions.
  • Page 3  To disconnect the appliance, set the switch to OFF and remove the plug from the socket. Pull on the plug only. Do not pull the cord.  Do not bend, drag or twist the cord, or apply force to remove it. Do not operate the unit if its cable or plug are damaged;...
  • Page 4 photo room, etc…) or fumes discharge, because they could affect the product performace.  Do not spray insecticides, oils or paints near the appliance; doing so may damage its plastic parts or start a fire.  Keep corrosive gases, flammable oils and metallic powders away from the appliance! ...

  • Page 5: Description Of Parts

    DESCRIPTION OF PARTS REAR VIEW FRONT VIEW Display and control panel Air outlet Air quality display Dust sensor cover Air inlet Air inlet (decorative panel) (front panel) Composite filter Decorative panel This purifier adopts the side air intake and top air discharge method. It intakes indoor air and the air passes through the composite filter for fast indoor circulation for purification, which effectively removes formaldehyde, odors, smoke and pollen, bacteria, mold, fine dust, volatile organic substances and any toxic gases from domestic activity and allergens.
  • Page 6 Purification occurs through a composite filter made of a system of 4 successive layers of electrostatic type, as shown here below. 1. PRIMARY FILTER 2. MODIFIED ACTIVE CARBON FILTER 3. COMPOSITE FILTER PAPER 4. SPRAY COATING PROTECTION LAYER OPERATIONS BEFORE PUT IN USE When operate unit for first time, tear off the sealing plastic bag of composite filter and then install the composite filter according the following procedures: 1.

  • Page 7: Display And Control Panel

    2. Install the composite filter Take out the composite filter then tear off the sealing plastic bag of filter. When installing the filter, the label FRONT faces outwards. Align the filter at the groove at the middle of base to make sure the filter is correctly positioned (see the figure below) Filter...

  • Page 8: On/Off Button

    1. Mode status display 7. Wifi status display 2. Child lock status display 8. Timer status display 3. Filter replacement indicator 9. Air quality indicator 4. Fan speed status display 10. Display part 5. Fan speed button 11. Mode button 6.

  • Page 9: Timer Button

    FAN SPEED BUTTON This purifier has 5 fan speeds. Under working status, touch the button to select the fan speed, each time this button is pressed the speed changes circularly in the following sequence: 1 -> 2 -> 3 -> 4 -> 5 Under any working mode, press to switch to the manual mode and then adjust the desired fan speed.
  • Page 10 WIFI GUIDE Download and installation of EWPE SMART App 1. Make sure that the device (smartphone or Tablet) used is equipped with a standard version of Android (version 4.4 or higher) and iOS (iOS7.0 or higher) as the operating system. For more details refer to the App.

  • Page 11: Cleaning And Maintenance

    CLEANING AND MAINTENANCE Warning Always pull the air purifier's plug out of the power socket before cleaning it, to prevent electric shocks or malfunctions. Warning Do not wet or immerse the air purifier in water, as this may cause electric shocks. Use a damp and soft cloth to clean the outer surface of the air purifier.
  • Page 12 3. Use moist cotton swab to wipe the sensor 4. Close the cover of sensor lens slightly and then use dry cotton swab to wipe it to make sure no water left on the sensor CLEANING OF FRONT PANEL AND INTERNAL PANEL When the unit operates for long time, there will be a lot of dust inside.

  • Page 13: Troubleshooting

    TROUBLESHOOTING PROBLEMA POSSIBLE CAUSE SOLUTION The power could be not turned on Connect the power The voltage may be not adequate Ensure that it connected 220-240V ~ 50/60 Hz power Unit can’t operate Decorative panel could be not well Ensure that decorative panel is well installed installed of filter replacement is on Check if icon...
  • Page 14 INFORMATION ON CORRECT DISPOSAL OF THE PRODUCT ACCORDING TO EUROPEAN DIRECTIVE 2012/19/EU ON THE DISPOSAL OF ELECTRICAL AND ELECTRONIC WASTE MATERIALS' This appliance must not be scrapped with domestic waste at the end of its life cycle. We call your attention to the crucial role played by the consumer in the reuse, recycling and other forms of recovery of such waste.
