Summary of Contents for ACONATIC 24HA502AN

  • Page 15 เพื ่ อ เลื อ ก Auto Tuning และกดปุ ่ ม...
  • Page 18 เพื ่ อ เข้ า สู ่ เ มนู...
  • Page 23: Table Of Contents

    Contents Introduction Warning Caution Main Unit Description Remote Control OSD Basic Adjustment Features Specifications Troubleshooting...
  • Page 24: Introduction

    Introduction Thank you very much for purchasing our TV. It serves as a normal colour TV and a PC monitor. To enjoy your set fully from the very beginning, read this manual carefully and keep it handy for future reference. INSTALLATION ①...
  • Page 25: Warning

    Warning CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO AVOID THE RISK OF ELECTRIC SHOCK. DO NOT REMOVE COVER (OR BACK). NO USER- SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This symbol is intended to alert the user to avoid the risk of electric shock.
  • Page 26: Caution

      Caution Caution                                   High voltages are used in the operation of this product. Do not open the product's casing. Refer servicing to qualified service personnel .  ...
  • Page 27 Caution Caution Never stand on, lean on or suddenly push the product or its stand. You should pay special attention to children. Caution Do not place the main unit on an unstable cart stand, shelf or table. Serious injury to an individual and damage to the television may result if it should fall.
  • Page 28: Main Unit Description

    Main unit description Control Panel Button Function Display\ hidden button menu: press the button in the pop-up menu, as shown below. The button menu will be closed automatically after the button is not operated for 5 seconds. Button function selection: press the button shortly, move the focus to the right, and select the corresponding function, such as the short press on the button for 6 times the focus position as shown in the belowpicture.
  • Page 29 Main unit description TV Terminal Connections 1. VGA input terminal. 3. RF Important: The USB port is intended only for data transfer only, other devices cannot be used with this USB connection. The use of USB extension cords is not recommended.
  • Page 30 Open or close subtitle. Press to start playing the disc or MEDIA, or to pause playing . : :Press to play backwards. :Press to play forwards. :Stop playing the disc or Media. :Skip to previous chapter. :Skip to next chapter. 24HA502AN...
  • Page 31: Osd Basic Adjustment

    OSD Basic Adjustment PICTURE Colour You can select the type of picture which best corresponds to your viewing. 1. Press the “MENU” button to enter the OSD menu. Then press “ / ” button to select the “PICTURE” menu. 2. Press “ / ” button to select “Picture Mode” and press the “ENTER” button to enter the sub-menu.
  • Page 32 SOUND You can select the type of sound which best corresponds to your listening. 1. Press the “MENU” button to enter the OSD menu. 2. Then press “ / ” button to select the “SOUND” menu. 3. Press “ / ” button to select “Sound Mode” and press the “ENTER” button to enter the sub-menu.
  • Page 33 TIME Press the “MENU” button to enter the OSD menu. 1. Then press “/” button to select the “TIME” menu. 2. Press “/” button to select “Sleep Timer” and press the “ENTER” button to enter the sleep timer adjustment menu to adjust the sleep timer. 3.
  • Page 34 1. Press the“ MENU” button to enter the OSD menu.Then press the “ ” button to enter the “ OPTION” menu. 2. Press “ ▲/▼” button to select “ OSD Language”and press the “ENTER” button to enter the OSD Language adjustment menu to select your preferred OSD Language. 3.
  • Page 35 1. Press the “ MENU” button to enter the OSD menu.Then press “ ” button to select the “ CHANNEL” menu. 2. Press “▲/▼” button to select “Auto Tuning” and press the “ENTER” button perform auto search.Press the“ MENU” button to return to the previous menu.Press the “EXIT” button to exit. Note:Searching platform will take a long time.
  • Page 36 4. Press “▲/▼” button to select “Program Edit” and press the “ENTER” button to enter. A. DELETE Press “▲/▼” button to select the program and press the “RED” button twice to delete program. B. RENAME Use the “▲” “▼” “ ” “ ” buttons to choose the channel that you want to name.
  • Page 37: Usb Features

    Features Press"SOURCE" button to select the "MEDIA" menu. MOVIE 2. Press the “/” button to enter the “PHOTO” option and press the “ENTER” button to enter. 2.1 Press the “/” button to select the disc drive that you want to watch and press the “ENTER”...
  • Page 38 3. Press the “/” button to enter the “MUSIC” option and press the “ENTER” button to enter. 3.1 Press the “/” button to select the disc drive that you want to watch and press the “ENTER” button to enter. 3.2 Press the “/” button to select the file that you want to listen to in the file selection menu, then press the “ENTER”...
  • Page 39 4.1 Press the “/” button to select the disc drive that you want to watch and press the “ENTER” button to enter. 4.2 Press the “/” button to select the file that you want to watch in the file selection menu and press the “ENTER” button to play. 5.
  • Page 40: Specifications

    SPECIFICATIONS RGB INPUT Horizontal Vertical Mode Resolution Frequency Frequency (KHz) (Hz) 720x400 31.5 640x480 31.5 SVGA 800x600 37.9 1024x768 48.4 WXGA 1366x768 47.7 HDMI INPUT Horizontal Frequency Vertical Frequency Mode Resolution (KHz) (Hz) 640 x 480 31.47 59.94 480i 720 x480i 15.73 59.94/60 576i...
  • Page 42 此处印刷HKC料号条码 Here print HKC parts NO.
