ALSE Stocco 5000 User Manual

Thank you very much for your trust and choose our products. In order to ensure your safety, Please read this installation manual first.
Your satisfaction is our greatest pursuit.

1. Safety Precautions:

1. The installation and use with this machine must meet the requirements of the local department. Urban construction, power management, etc.
2. The sliding door must be securely installed, Welding parts without weld, bolt fastening, smooth operation, no vibration and noise, no interference with any other buildings,
green belts, etc. If there is anything wrong, please call the professionals to check it and repair.
3. Accessories from the machine must be keep away from children, do not let the children play the remote control!
The open button must install to a location that the children can never touch it, In order to avoid accidents.
4. If you need to manually open the sliding door, please make sure that you turn off the main power!
5. When the machine overhaul or replacement parts, please make sure that you turn off the main power!
6. If the machine does not need to use for a long time, please make sure that you turn off the main power!
7. When you change the position, disassemble or installing the machine, please make sure that you turn off the main power!
8. Please put this manual in a safe place, the place you can find anytime.
9. A high-voltage electric wire inside the machine, only professionals are allowed to open the case!
10. After the installation must do a complete security test for the whole system. Door open and close flexible test, Noise or abnormal sound test, all the buttons and electric
board stable test, heating status for all Parts. Only through the test can be delivered to use.
II. Technical Parameters:
Parameters Model Stocco - 5000
Voltage 380V
Frequency 50HZ
Main bearing speed 45
Open speed 15m/min
Maximum load (kg) 5000
Ambient temperature -25ºC+65ºC
Sound volume (db) ≤65
Lubrication medium LBG
Cooling method Air-cooled
Host max. temperature 85ºC
Protection class IP44
Certification CCC,CE
III. Transport and storage
1. The product box can never exceed more then 3 layers;
2. Do not climb, stand or place other heavy objects on the product box;
3. No collision, no inversion;
4. Product box should avoid exposure, moisture and rain.
IV. Product check
Please confirm the product once you open the box ；
1.
2. Please check the damage situation during transport;
Sliding Gate Operator / User Manual
Stocco -3000
220V
50HZ
45
15m/min
3000
-25ºC+65ºC
≤65
LBG
Air-cooled
85ºC
IP44
CCC,CE
Stocco 5000
