Summary of Contents for Ammara Designs PBS-RGH
- Page 1 PBS-RGH Installation Instructions VALVE ONLY For Pressure Balance Shower Set No Finish For easy installation of your faucet you will need: ● To read all the installation completely before beginning. ● To read all warnings, care, and maintenance information. 15121422-A...
- Page 2 PBS-RGH Installation Instructions 2 7/8 ＂ - 3 7/8 ＂ 2 7/8 ＂ -3 7/8 ＂ Mounting hole Mounting hole This valve is designed to fit into a Turn off the water supplies.Install the wall that is 2 7/8 ＂ to 3 7/8 ＂ from...
- Page 3 1.Pressure test and flush the valve. a. Prior to testing, remove mud guard, stem assembly, cartridge as stops as shown. b. Plug the shower outlet and check for leaks. c. After testing, flush system. d. Remove shower outlet plug. Re-install the stops, cartridge, stem assembly and mud guard. 2.Check for leaks.
- Page 4 PBS-RGH Replacement Parts NO. Description Part No. End Cap 5T1C0138NT Stop Valve 9Q1152NT Sleeve 5L0C0861NT Pressure Balance Cartridge 5D0M0262PL Cartridge Nut 5T1C0216NT Sten & Threaded Nipple 9Q1173NT Applicable Standards/Codes IAPMO certified to meet or exceed the following: • ASME A112.18.1/CSA B125.1 •...
