CV-505ZA2
HDMI 2.0a Audio Extractor &
Embedder
User Manual
The CV-505ZA2
safety regulations and requirements, and has been certified for international use. However, like all
electronic equipments, CV-505ZA2 should be used with care. Please read and follow the safety
instructions to protect yourself from possible injury and to minimize the risk of damage to the unit.
● Follow all instructions and warnings marked on this unit.
● Do not attempt to service this unit yourself, except where explained in this manual.
● Provide proper ventilation and air circulation and do not use near water.
● Keep objects that might damage the device and assure that the placement of this unit is on a
stable surface.
● Use only the power adapter and power cords and connection cables designed for this unit.
● Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the device
before cleaning.
TABLE OF CONTENTS
Introduction .................................................................................................................. 1
Features ........................................................................................................................... 1
Package Contents ........................................................................................................ 1
Specifications ................................................................................................................ 2
Panel Descriptions ...................................................................................................... 3
Connection Diagram .................................................................................................... 5
Warranty ......................................................................................................................... 6
rev: 161216
Made in Taiwan
Safety and Notice
has been tested for conformance to
HDMI 2.0a Audio Extractor & Embedder
Advertisement
Table of Contents
Related Manuals for GoMax Electronics CV-505ZA2
Summary of Contents for GoMax Electronics CV-505ZA2
- Page 1 HDMI 2.0a Audio Extractor & Embedder safety regulations and requirements, and has been certified for international use. However, like all electronic equipments, CV-505ZA2 should be used with care. Please read and follow the safety HDMI 2.0a Audio Extractor & instructions to protect yourself from possible injury and to minimize the risk of damage to the unit.
- Page 2 S/PDIF(Toslink) audio to the outgoing HDMI signal. HDCP compliance CV-505ZA2 is also designed to co-work with any HDMI matrix in the market to make different audio capacity HDMI equipped devices can work with multi-channel HDMI embedded audio at the same time!.
- Page 3 PANEL DESCRIPTIONS DIP Switch Position Description Front Panel 4‐Pin ON [] Enable Audio Extractor Function (via Toslink & 3.5mm) PIN#1 OFF [] Disable Audio Extractor Function ON [] Enable ARC Function PIN#2 OFF [] Disable ARC Function ON [] Reserve d PIN#3 OFF [] Reserve d ON [] Firmware Update Mode PIN#4 OFF [] Normal Mode S/PDIF output (TOSLINK) Stereo output (3.5mm) 4-Pin Dip Switch (Please refer to “Notes”) ARC audio extraction is always via Toslink output HDMI output ***Once enable ARC function, the audio extraction will be valid only via stereo(3.5mm).
- Page 4 The SELLER will NOT be liable for direct, indirect, incidental, special, or consequential damages resulting from any defect or omission in this manual, even if advised of the possibility of such damages. Also, the technical information contained herein regarding the CV-505ZA2 features and specifications is subject to change without further notice.
