GAS APPLIANCES
BUILD IN APPLIANCES
FOR USE WITH LIQUIFIED PETROLEUM GAS
CAUTION – ALL OUTER SURFACES WILL GET HOT WHEN IN USE
MODEL:- OH88000
PRODIGY 600
USER AND INSTALLATION INSTRUCTIONS
SPINFLO LIMITED, UNIT 19, Oakham Drive, Parkwood Industrial Estate,
Rutland Road, Sheffield S3 9QY, ENGLAND.
TEL: + 44 (0)114 273 8157
FAX: + 44 (0)114 275 3094
Advertisement
Related Manuals for spinflo PRODIGY 600 OH88000
Summary of Contents for spinflo PRODIGY 600 OH88000
- Page 1 CAUTION – ALL OUTER SURFACES WILL GET HOT WHEN IN USE MODEL:- OH88000 PRODIGY 600 USER AND INSTALLATION INSTRUCTIONS SPINFLO LIMITED, UNIT 19, Oakham Drive, Parkwood Industrial Estate, Rutland Road, Sheffield S3 9QY, ENGLAND. TEL: + 44 (0)114 273 8157 FAX: + 44 (0)114 275 3094...
- Page 3 CONTENTS User’s Section Specification ………………………………………………… Introduction ………………………………………………… Using the Hotplate ………………………………………………… Using the Grill ………………………………………………… Using the Oven ………………………………………………… Installation and Servicing Installation Dimensions ………………………………………………… Specification ………………………………………………… Installation Instructions ………………………………………………… Maintenance & Servicing ………………………………………………… SPECIFICATION OH88000 External Dimensions, mm (HxWxD) 936x614x617 Oven Capacity, litres (HxWxD) 60 (335x505x358)
- Page 4 INTRODUCTION This appliance must be installed in accordance with the local, national and European regulations in force. Particular attention shall be given to the requirements regarding ventilation. Read the instructions before installing or using the appliance The appliance is designed for either high or low level installations. Failure to install the appliance correctly could invalidate any warranty or liability claims and lead to prosecution.
- Page 5 OPERATION WARNING • When cooking, young children should be kept away. • Glass lids may shatter when heated. Turn off all burners before shutting the lid • Spillage on the surface of the lid should be removed before opening the lid. Burner operation The burners on this appliance have fixed aeration and no adjustment is required.
- Page 6 OPERATION IMPORTANT • The pan supplied with the appliance is multi functional, for use in grill or oven. • The handle design allows removal or insertion whilst the pan is in use. • Always remove the handle when the pan is in use. Using the Grill 1.
- Page 7 Operation IMPORTANT • The pan supplied with the appliance is multi functional, for use in grill or oven. • The handle design allows removal or insertion whilst the pan is in use. • Always remove the handle when the pan is in use. Using the Oven 1.
- Page 8 OPERATION Cooking Guidelines Best results will be obtained by the shelf positions in this guide. It is not necessary to preheat the oven but advisable for a range of dishes. The oven is capable of full temperature in 15-20 minutes. Most cookery books give details of the shelf positions and gas mark settings for each recipe.
- Page 9 INSTALLATION Regulations and Standards In your own interest of safety, it is law that all gas appliances are installed and serviced by competent persons. CORGI (Confederation for the Registration of Gas Installers) registered installers undertake to work to safe and satisfactory standards. Failure to install the appliance correctly could invalidate any warranty or liability claims and lead to prosecution.
- Page 10 INSTALLATION IMPORTANT • This appliance must be installed into an aperture, sealed off at either side in order to prevent draughts from adjoining cupboards/vents. Ensure that air vents and gas escape holes are kept clear, holes for cables and pipes must be sized to minimize air leakage between compartments.
- Page 11 INSTALLATION Connection Gas connection - To an 8mm OD inlet pipe on the underside of the appliance. It is recommended that the cooker be connected by copper tubing using a compression fitting. Rubber tubing MUST NOT be used. Electrical connection - Ensure that all electrical cables and wires are routed well clear of any heat source, including this appliance.
- Page 12 MAINTENANCE SERVICING This appliance needs little maintenance other than cleaning. All parts should be cleaned using warm soapy water. Do not use abrasive cleaners, steel wool or cleansing powders. When cleaning the burner ring it is essential to ensure that the holes do not become blocked. The control knobs are a push fit and can be removed for cleaning.
- Page 13 MAINTENANCE SERVICING 6. Spark Ignition (where fitted) Remove the hob surface (2). Unscrew the 4 fixing screws and remove the generator cover at the rear left of the appliance. Hotplate burners - Pull off the fixing clip on the burner and remove electrode from the burner cup.
