Touch Panel Switch is a wall switch with built-in Z-Wave module. It supports basic command
class, association command class, which can control all associated devices synchronously. This
product can be included and operated in any Z-Wave network with other Z-Wave certified devices
from any other manufacturers.
Local and remote wireless control
Touch panel and mobile control
Compatible with any Z-Wave network controller
HIOTH TECHNOLOGY CO.,LTD.
HIOTH
Touch Panel Switch
Introduction
Technical Information
CT-LCZW5025-MH
CT-LCZW5026-MH
CT-LCZW5027-MH
1-pole/2-pole/3-pole Touch Panel Switch
User Manual
Advertisement
Table of Contents
Summary of Contents for Hioth CT-LCZW5025-MH
- Page 1 Z-Wave network with other Z-Wave certified devices from any other manufacturers. Technical Information Local and remote wireless control Touch panel and mobile control Compatible with any Z-Wave network controller HIOTH TECHNOLOGY CO.,LTD.
- Page 2 As shown in Fig.1, using the screwdriver to pry the gaps on the side of the switch, then open the panel. Fig.1 Using both hands to hold the switch panel and forcibly push up, switch panel is desirable. Follow the wiring diagram to insert all wires into right terminals and tighten screws. HIOTH TECHNOLOGY CO.,LTD.
- Page 3 Connect the power supply, and make sure that device in a state of "No node ID". Press and hold any key on the panel for 8 seconds (INDICATION LED on the panel will turn green.). Choose "Z-Wave" to enter the Network Inclusion mode on the APP, then click " ". HIOTH TECHNOLOGY CO.,LTD.
- Page 4 During installation, protect the device from any physical damage by dropping or bumping. If happened, please contact the supplier for maintenance. Keep the device away from acid-base and other corrosive solids, liquids, gases, to avoid damage. Avoid overexertion during operation, to protect device from mechanical damage. HIOTH TECHNOLOGY CO.,LTD.
- Page 5 HIOTH User Manual Read all instructions and documentation and save for future reference. HIOTH TECHNOLOGY CO.,LTD.
