ALTAI A175CR Assembly And Fitting Instructions

Plasma bracket

Advertisement

Quick Links

Plasma Bracket assembly and fitting instructions.
This is a professional product and is intended for installation by qualified
personnel only.These instructions are intended to be as comprehensive as
possible but at all times it is the responsability of the user/installer to
ensure that the bracket and screen are securely fitted.

Fitting Instructions

1. Open pack. In this pack are included 4 x wall bolts, 4 x 4 screen fixing
screws, 2 x 4 spacers, 3 allen keys, 2 side struts, 2 wall brackets and 2 tilt
arms.
Screen Fixing Screws
Wall
Brackets
Side
Struts
Spacers
A175CR
Wall Bolts
Allen
Keys
Tilt Arms
