- Page 1 Bush Baby Blu-Ray Player with Wi-Fi Hidden Camera SKU: BBWiFiBluRayPlayer Version 1.0...
- Page 2 BBWIFIBLURAYPLAYER Please read this manual before operating the BBWiFiBluRayPlayer and keep it handy. The new BBWiFiBluRayPlayer is the perfect solution for anyone needing a covert camera in their living room. It boasts clear 1920x1080p video, and comes built in to a fully functioning Blu-ray player with all of the camera parts sealed inside so no one will question it.
- Page 3 GET FAMILIAR WITH YOUR BBWIFIBLURAYPLAYER Version 1.0...
- Page 4 OPERATING THE BBWIFIBLURAYPLAYER BEFORE YOU START 1. First you must download the TinyCam app from the Google Play Store or the iPhone App Store. o Android: https://play.google.com/store/a pps/details?id=com.rtp2p.tinyca o iPhone: https://apps.apple.com/us/app/ tinycam/id1444285114 2. If you ever need to move your device...
- Page 5 Note: If you are not located in the US, or if you intend to use this product anywhere other than the US, you will need to purchase a converter in order to use the AC wall plug in and avoid damaging the product.
- Page 6 1. Plug the device’s power cord into a wall outlet. 2. Turn on your phone’s Wi-Fi. o Go to your phone’s settings (see pictures on the next page, follow them from the top – down) Version 1.0...
- Page 7 3. After connecting to the device’s Wi-Fi signal, it should display as ‘Connected’ or the ‘Current Network’ (see below picture) o Some devices may produce a warning that the network has no internet access. If you see this, choose to connect to the network anyway.
- Page 8 4. Now that we are connected to the unit’s Wi-Fi signal, go ahead and open the TinyCam App on your phone. 5. When you open the app, it will automatically detect that you are connected to the unit’s Wi-Fi signal and Version 1.0...
- Page 9 ask if you would like to add the device to the TinyCam App. Press “OK”. 6. After pressing “OK”, this will add the device to the TinyCam App and take you to the home screen. o We still need to add the camera to a Wi-Fi network where it is staying in order to livestream it! 7.
- Page 10 8. After tapping the wrench, a new menu will appear with a bunch of different ‘Config’ or ‘Setting’ selections. For now, we want to focus on Wi-Fi Config. Go ahead and select ‘Wi-Fi Config’ and a new menu should open. Version 1.0...
- Page 11 9. After selecting Wi-Fi Config, we are taken to a page where you can choose a network for the unit to connect to, and then type in the password for that wi-fi network. Press ‘Confirm’ when done to pair the unit with the router. You should see something that says “Set Success”.
- Page 12 10. Close the TinyCam App and proceed to step 11. 11. If the unit pairs with your router, it will stop broadcasting its own Wi-Fi signal, and your phone should connect back to the normal network for the area. Version 1.0...
- Page 13 o To verify if the camera added successfully to your router, turn off your phones Wi-Fi, and then open the ‘TinyCam’ app. Using your cellular data, you should be able to stream the device (if you have cellular data enabled). o If your device is still broadcasting its Wi-Fi signal, the unit has failed to pair with your Wi-Fi.
- Page 14 o The default password is 888888. HOW TO ADJUST THE VIDEO QUALITY OF THE STREAM 1. Open the TinyCam App. 2. Open the livestream for your unit. 3. After opening the livestream, in the top center of the screen, you should see three different options.
- Page 15 HOW TO SET UP MOTION DETECTION RECORDING 1. Open the TinyCam app. 2. Tap the wrench icon on your device listing. 3. Navigate to ‘Alarm Config’. Version 1.0...
- Page 16 4. Turn Motion detection to any option besides ‘Close’. 5. Hit the back button on your phone so you can see all the other Config/Setting options again. 6. Choose ‘Micro SD Card Setting’. Version 1.0...
- Page 17 7. Tap the ‘Alarm recording’ box and ensure that it is checked. 8. Your device is now set up for motion detection recording! a. By turning the ‘Alarms’ motion detection levels on, the unit sends an ‘Alarm’ once motion is detected. This alarm triggers the unit to begin recording.
- Page 18 Micro SD Card Setting – A Further Look Version 1.0...
- Page 19 a) Micro SD Card Capacity – This displays what size MicroSD card you have inside the unit, and the total space left. a. The number on the left is the total space left. b. The number on the right is what size MicroSD card you have inside the unit.
- Page 20 f) Recording Length – These are how long the unit’s videos will last. a. If you have full time recording enabled, and set the ‘recording length’ to 180 seconds, your unit will record video 24/7 and the videos will be in 3 minute segments.
- Page 21 j) Time-Lapse Video Recording – This is how long of an elongated video your unit will record. OTHER CONFIG OPTIONS Version 1.0...
- Page 22 a) Time Set – This allows you to set the time/date for the unit. b) Power Frequency – If you are located in the USA, set this to 60Hz (also known as NTSC). Almost all other countries use 50Hz (also known as PAL). c) Initialization –...
- Page 23 servers or contact your server administrator. e) Email Set – These settings will allow the unit to email you notifications regarding motion. Information regarding the SMTP settings, etc can be found through your email provider. Technical Support is not able to tell you what your SMTP settings are –...
- Page 24 a. On most Windows PC, AutoPlay will detect the removable storage and ask how you would like to proceed. Choose ‘Open folder to view files’ b. On Mac devices, the removable storage will appear under ‘Removable Storage’ inside the Finder application. 5.
-
Page 25: Microsd Card
the menu. Next, go to the location you want to save the file to. Right click your mouse, then choose “Paste”. This will copy and save the file to your computer. To delete a file, right click your mouse on the file name, then choose “Delete”... - Page 26 2. Press the folder icon on the bottom left of your device listing. 3. The new screen that opens shows all current recordings on the MicroSD card for the current day. The top right corner (clock icon) allows you to choose which date you wish to view recordings from.
-
Page 27: Troubleshooting
TROUBLESHOOTING THE DEVICE WON’T TURN ON Make sure the plug is securely connected to alarm clock, and the AC Adapter securely plugged into the wall. CANNOT RECORD TO MICROSD CARD Make sure the MicroSD card is inserted into the unit fully. It’s spring loaded so you should feel it click into place. -
Page 28: Other Problems
You can reset the camera from the app by opening the app, going to the device’s settings, scrolling to the bottom, and selecting “Reset Device”. You do not have to delete the app in order to reset the device. HOW TO FACTORY RESET THE DEVICE ... -
Page 29: Specifications
SPECIFICATIONS Stream Resolution 1080P Recording Resolution 720P Video Format .AVI Viewing Angle 90° MicroSD Card 128GB Storage Video Consumption 1 Min = 20MB Playback Software Loop Recording Operating Systems Android, iOS Version 1.0... - Page 30 Version 1.0...
- Page 31 Version 1.0...
- Page 32 QUALITY CONTROL CHECKLIST ☐ Instruction Manual (this) ☐ Instruction Manual for Blu-Ray Player ☐ Remote Control for Blu-Ray Player ☐ MicroSD Card Reader ☐ BBWiFiBluRayPlayer ☐ 128GB MicroSD Card QC Technician: ______________________________ Date: ___________________________________ Version 1.0...
