Summary of Contents for Prem-I-Air Elite EH1580
- Page 1 EH1580/EH1580EU Invierno Air Purifier PURIFICATEUR d'Air HEPA Page 1...
-
Page 2: Before Use
IMPORTANT Installer and Users please note: These instructions should be read carefully and left with the user of the product for future reference. BEFORE USE You must inspect the product including its cable and plug for any signs of damage. If the product is damaged, DO NOT use it, and contact your supplier immediately PRODUCT SAFETY •... -
Page 3: Pat Testing
• Do not place the mains lead beneath a carpet or rug. • Attachments or accessories not recommended or sold by the product distributor should not be used. • Do not wash the filter cartridge (HEPA). The cartridge is not washable and doing so will cause damage. -
Page 4: Product Information
PRODUCT INFORMATION 1. First step: Pre-filter: It uses micron mesh filter, effectively resists fibre particulate matter which is bigger than 0.28mm,the blocking rate is over 99.90%.It is convenient to wash and clean over tens of thousands of times. Function: It can prevent large particles in the air, such as hair dandruff, coarse grains and fine dust. - Page 5 3. Third step: 3M coconut-shell active carbon + diatom ooze: can remove up to 99.00% of free Formaldehydes, benzene, ammonia and TVOC’s etc. The harmful substance, characteristic mix and absorptive capacity can comprehensive purify air. 4. Fourth step: 3M True HEPA: can remove up to 99.97% of particulates, such as fine dusts, haze and smoke, pet dander, mould spores, pollen, some bacteria and viruses with a diameter above 0.3micron.
-
Page 6: Before First Use
BEFORE FIRST USE Installing/Replacing the filters The appliance comes with all filters fitted inside, but you have to remove the packaging on the filters before you use the appliance. Remove all filters, unpack them and place them back into the appliance as described below. Tip: Place the appliance against a wall for more stability when you remove or insert filters. -
Page 7: Operation
6: To reattach the front panel, insert the 5: Place filter 1 (pre-filter) in the bottom hooks into the bottom of the appliance. appliance first. Then push the panel Note: Make sure that the side with the against the body of the Appliance. two projections is pointing towards you. - Page 8 quality is bad when it is possibly good. In this case clean the air quality sensor. If this situation persists it is advisable to set the fan speed manually. Fan speed/filter replacement indicators. The lights on the left of the control buttons have a dual purpose.
- Page 9 Adjusting the Air Quality Sensor The air quality sensor can be set to one of 3 levels depending on how clean you wish the air to be. The levels are; Standard Sensitive Extra Sensitive When first turned on the sensor is set to standard. To change the setting follow the instructions below.
-
Page 10: Maintenance
NIGHT Mode This function is only available when the unit is in AUTO Mode. When the room goes dark for 3 minutes the lights on the unit go out and the fan speed is reduced to run the unit in silent mode. When the lights go back on for over 5 minutes the unit resumes normal operation. - Page 11 Cleaning the Air-Quality Sensor Use a soft brush to clean the Remove the protective cover air inlet and outlet of the of the air quality sensor. unit. Use a damp swab to clean Re-attach the protective the air quality sensor, air cover.
- Page 12 warning light comes on. Approximately 1 day before the appliance locks it will beep every 30 minutes to warn that the unit will lock out. When the unit is locked it will just beep when any button is pressed and you can only turn the power on and off.
- Page 13 At time of going to press, the average cost of electricity is £0.13 per unit (kilowatt-hour). The amount you are being charged will be shown on your electricity bill. At this cost, the EH1580 / EU will cost 11.5p per day to run. Page 13...
-
Page 14: Disposal And Recycling
DISPOSAL AND RECYCLING You must not dispose of this appliance with domestic household waste. Most local authorities have specific collection system for appliances and disposal is free of charge to the end-user. When replacing an existing appliance with a similar new appliance your retailer may take the old appliance for disposal. -
Page 15: Service / Warranty
SERVICE WARRANTY Prem-i-Air guarantees the product free from defects in materials and workmanship for a period of 2 years. Should this unit be operated under conditions other than those recommended, at voltages other than the voltage indicated on the unit, or any attempts made to service or modify the unit, then the warranty will be rendered void.
