Summary of Contents for Premier T100
- Page 1 SKID STEER LOADER MINI TRENCHER MODELS: T100, T125 OPERATOR’S MANUAL MODEL NUMBER: _________________ SERIAL NUMBER: _________________ WARNING! AVOID INJURY OR DEATH! READ AND UNDERSTAND THIS ENTIRE MANUAL BEFORE INSTALLING, OPERATING OR SERVICING THIS EQUIPMENT!
-
Page 3: Table Of Contents
TABLE OF CONTENTS …………………………………………………… Letter to the Owner …………………………………………………… Warranty Policy …………………………………………………… Warranty Registration Form 4 - 5 …………………………………………………… Product Specifications …………………………………………………… -Chain Options …………………………………………………… Safety Information 7 - 8 …………………………………………………… -To the Operator …………………………………………………… -Before You Start …………………………………………………… -During Trencher Operation ……………………………………………………... -
Page 4: Letter To The Owner
E-Mail: contact@premierattach.com Premier strives to provide superior products and the highest level of customer service. If you have any suggestions on how we can improve for the future, we would appreciate hearing from you. Thank you for putting your trust in PREMIER. -
Page 5: Warranty Policy
This warranty constitutes the entire warranty of PREMIER, and no oral representations, warranties or guarantees by any agent of PREMIER or the seller shall be binding on PREMIER, and no part of this warranty may be modified or extended except upon the express written consent of PREMIER. -
Page 6: Warranty Registration Form
MODEL_________________________________ APPLICATION______________________________________________________________________________ This PREMIER Mini Trencher has been accepted in good condition and I have been instructed by the dealer to read and understand the entire Operator’s Manual for proper installation, proper and safe operation, preventative maintenance, service, warranty, and all other information covered in the Operator’s Manual. I also understand that all operators must read and understand the entire Operator’s Manual. - Page 7 #1 - Fold down here From: ________________________________ Place Postage ________________________________ Here ________________________________ PREMIER 2707 Lofty Drive Fort Wayne, IN 46808 #2 - Fold up here #3 - Tape or seal here...
-
Page 8: Product Specifications
*Output speed and output torque specifications are based on theoretical values and are provided for comparative purposes only. PREMIER is continually striving to improve its products; therefore, we reserve the right to make changes to our products or specifications at any time without notice or obligation. -
Page 9: Safety Information
SAFETY INFORMATION This section is composed of various warnings and safety tips. Read and learn all the information in this section before you attempt to use your trencher. Also read your vehicle owner’s manual before using your equipment. This knowledge will help you operate your unit safely. -
Page 10: During Trencher Maintenance
All bystanders should be kept a minimum of 20 feet (6 meters) away from working area of the trencher. Stop the trencher and shut off the engine if anyone approaches the equipment while it's in motion. They may not be familiar with the equipment, and get in the way of moving parts. -
Page 11: Operating Instructions
Engage the hydraulics to make sure the Trencher is turning freely in both forward and reverse rotation. 4. You are now ready to operate your Premier Trencher. DISCONNECTING THE TRENCHER * Because of the difference in attachment mounting and removal methods among the various brands of skid steers, it is important to consult your skid steer Owner’s Manual for the proper attachment removal method. - Page 12 engine speed. To increase the trencher’s speed, increase loader’s engine speed, to decrease trencher’s speed, decrease loader’s engine speed. When first starting a trench, throttle down the engine to half throttle. This will reduce the shock to the loader and trencher when the digging teeth first contact the ground.
-
Page 13: Operating Techniques
make adjustments, evenly tighten or loosen the nuts on the tensioning assembly bolt (the image below shows the nuts in the fully loosened position). It is common for your trencher to need its digging chain tightened after the first 10 to 20 minutes of operation, as the chain and sprocket seat themselves. - Page 14 STARTING THE TRENCH * Note that the loader is driven in reverse when trenching. You cannot trench driving forward (in most situations). 1. Position the loader with the trencher boom directly over the center of the trench layout. It will take about 4' of TILT DOWN 45 trenching before the trencher will be able to operate at the...
- Page 15 TURNING WHILE TRENCHING Gradual turns can be made while trenching; however, the tightness of the turn is directly proportional to the trenching angle and boom length. In other words, the greater the angle of the trencher boom to the ground level, the sharper the turn that can be trenched.
-
Page 16: Repair And Maintenance
REPAIR AND MAINTENANCE Your PREMIER Mini Trencher was designed to require a minimal amount of maintenance. Very little effort is needed to keep it in top condition; however, it is important to follow the procedures in this section to get the full performance and longevity out of the attachment. -
Page 17: Storage
PERFORMANCE TROUBLESHOOTING Your PREMIER Mini Trencher was designed to be as simple and as trouble free as possible. The purpose of this section is to help you in the event that a problem does develop. While we cannot possibly cover every problem that might occur, you will find that the most common issues are covered here. - Page 18 PROBLEM POSSIBLE CAUSE SOLUTION Insufficient Digging Power Worn chain teeth Replace. Check with pressure gauge. Low system pressure (PSI) If low, investigate cause. Adjust the relief valve or Relief valve damaged or setting wrong replace it, as required. Reduce the load to within Excessive load machine specifications.
- Page 19 PROBLEM POSSIBLE CAUSE SOLUTION Trencher does not dig fast Chain teeth worn Replace the teeth. enough Inspect and repair Quick coupler or hose restriction the hoses and couplers. See the skid steer owner’s Skid steer hydraulic system is weak manual or equipment Dealer. Trencher motor not properly Review with the equipment Dealer.
-
Page 20: Parts List Diagrams
Crumb Catcher Extension Arm 93106 Mini Nose Wheel with Bearing 55207 Mini Trencher Spoil Flap 93110 T100 Drive Assembly 55220 Mini Trencher Top Cover 93111 T125 Drive Assembly *Mini Trencher Boom Options: The 24” or 30” Boom is the basic option. These two boom tube sizes have a modified nose wheel built into the component. For a longer 36”... - Page 21 Figure A REF. # PART # QTY. PART DESCRIPTION 5/8”-11 Crown Lock Nut, Grade 5 40001 1/2”-13 Crown Lock Flange Nut 40005 1/2”-13 x 4-1/2” HHCS, Grade 5 40021 5/8” Flat Washer, Grade 5 40046 1/2”-13 x 1-1/4” HHCS, Grade 5 41015 3/4”-6 ACME Nut, #06055487 45002...
- Page 22 1/2”-13 x 1-1/4” Carriage Bolt, Grade 5 45020 1/2” Split Lock Washer, Grade 5 45022 55207 Mini Trencher Spoil Flap 55220 Mini Trencher Top Cover 55221 Mini Trencher Spoil Flap Fastener 93058 Mini Trencher Mini Skid Mount 93101 Mini Crumber Weldment 93110 T100 Drive Assembly...
- Page 23 Figure C REF. # PART # QTY. PART DESCRIPTION 5/8”-11 Crown Lock Nut, Grade 5 40001 1/2”-13 Crown Lock Flange Nut, Grade 5 40005 1/2”-13 x 3-1/2” HHCS, Grade 5 40029 5/8” Flat Washer, Grade 5 40046 1/2”-13 x 1-1/4” HHCS, Grade 5 41015 1/2”-13 x 1-1/2”...
