- Page 1 Delta (Touch) Pen Display User Manual Version 2.0 as of 10.03.2020 www.signotec.com...
-
Page 2: Table Of Contents
..............................14 ECHNICAL SUPPORT 11.2..................................14 EPAIRS 11.3........................14 VERVIEW OF ACCESSORIES AND SPARE PARTS DISPOSAL OF DEVICE ..............................15 DECLARATIONS OF CONFORMITY ..........................15 © 2000–2020 signotec GmbH signotec Delta Pen Display user manual Page 2 of 15... -
Page 3: Thank You
1. Thank you! Thank you for having chosen one of signotec’s products. You now have a robust, durable and high- tech solution that is unrivalled in this market segment. The signotec Delta Pen Display is a monitor extension featuring pen input and optionally available capacitive touch functionality. The device func- tions as a monitor and can be managed using the Windows settings (to duplicate or extend the main display). -
Page 4: Warnings And Precautions
Failure to comply with these precautions will result in the loss of your warranty. Furthermore, signotec will not accept any responsibility for the repair or replacement of the device. -
Page 5: Checking The Device Upon Arrival
Immediately upon or after receiving the product, check that all associated components have been delivered. If a component is missing, defective or visibly damaged, please contact signotec or the authorised dealer from whom you purchased the product within one working day. If you do not com-... -
Page 6: Product View
USB cable Ergonomic pen with replaceable pen tip Liquid Crystal Display (LCD) with Cord (attached to the device and pen) a hardened glass surface Status LED © 2000–2020 signotec GmbH signotec Delta Pen Display user manual Page 6 of 15... -
Page 7: Back Side
Mounting fixture for a vertical Hardware revision number pen holder Tension relief for USB cable Barcode with unique serial number Micro-USB port VESA mounting fixture (75 × 75 mm) © 2000–2020 signotec GmbH signotec Delta Pen Display user manual Page 7 of 15... -
Page 8: Vesa Mounting Fixture
USB power connection 7. Connection types The signotec Delta Pen Display signature pad is connected to the computer via USB; there is not an alternative. If you want to connect a device to a network, then we recommend purchasing a ‘true’... -
Page 9: Assembling The Pen Holder
8.2. Folding out/in the support The signotec Delta Pen Display features a foldout support on the back of the device. It can be easily folded out to raise the device up at an angle. In this manner, the device can be conveniently adapted to the conditions wherever it is in use. -
Page 10: Inserting The Usb Cable
Micro-USB plug. The warranty does not cover this type of damage. 8.4. Power supply via USB The signotec Delta signature pad features a USB Y-cable. The cable has two plugs in order to provide the device with sufficient power (1,000 mA max.). One USB 2.0 plug provides an output of 500 mA in accordance with USB specifications. -
Page 11: Configuring The Pen Input
All detected monitors are listed on the left side. You can use the option ‘Select the signotec Pen Display’ on the right to determine which of the connected monitors is the Pen Display. The current selection has a red border. -
Page 12: Maintenance, Care And Cleaning
9. Maintenance, care and cleaning signotec signature pads are maintenance-free. No technical components need to be replaced regularly or depending on use. You should handle the device with care, maintain it regularly and replace accessories promptly if they show signs of use in order to increase the device’s service life as much as possible. -
Page 13: Warranty
Within the warranty period, signotec GmbH will repair free of charge all defects of the product that are caused by processing errors or material defects. It is at the discretion of signotec to repair or replace individual parts or the entire product. The replacement can mean new or repaired parts or a new or repaired product. -
Page 14: Support And Repairs
11. Support and repairs The products and solutions from signotec were designed to make our customers satisfied users. If, contrary to expectations, problems occur, you can find the necessary help and support on our FAQ and support pages. 11.1. Technical support... -
Page 15: Disposal Of Device
GmbH, based in Ratingen, Germany. Reproduction of this documentation, in part or in whole, is subject to prior written approval from signotec GmbH. All hardware and software names used are trade names and/or trademarks of their respective manufacturers/owners. Subject to change at any time without notice.
