ROTATION LASER R15M ı Instructions of Use
Important:
please read these instructions of use carefully before using the
system and keep them for later reference.
GB
g
e
d
a Laser beam exit
b Adjusting levels
c On / off switch
d Rotation button
Laser
sighting system
8
02_0664-00-GB.indd 8
a
f
e Scan button
f Levelling screws
g Battery compartment
h Base plate
Laser goggles
c
b
h
30.05.13 15:31
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for KWB R15M
Summary of Contents for KWB R15M
- Page 1 ROTATION LASER R15M ı Instructions of Use Important: please read these instructions of use carefully before using the system and keep them for later reference. a Laser beam exit e Scan button b Adjusting levels f Levelling screws c On / off switch...
- Page 2 ROTATION LASER R15M ı Instructions of Use Measuring basics: The rotation laser combines a laser beam with a motorized mechanism. This makes it simple to carry out horizontal and vertical levelling work. The rotation laser may be used in a variety of applications, e.g. on construction sites and in decoration work.
- Page 3 ROTATION LASER R15M ı Instructions of Use 2) Vertical rotation Place the laser on the side extension of the base plate (h). Switch the laser on as described in “Structure”. You will see two stationary dots of light at right angles to each other.
- Page 4 ROTATION LASER R15M ı Instructions of Use General information about use Please note that the laser beam’s visibility declines with increasing ambient brightness. Please use the supplied goggles to better see the laser beam. If possible, darken rooms before commencing measurements. Attention: in unfavourable lighting conditions, it may not be possible to see the laser dot from where the rotation laser is located.
- Page 5 Precision +/- 0.4 mm/m Operating temperature: 0° - 40°C Results measured with the rotation laser must generally be checked. kwb cannot assume any liability for measuring errors and resulting consequential damage. Laser Class 2 in accordance with Laser beam – do not look into EN 60825-1: 2007 the beam.
- Page 6 ROTATION LASER R15M ı Instructions of Use 02_0664-00-GB.indd 13 30.05.13 15:31...
