VC2100 / VC2100 32MB Digital Event Recorder
Product Description：
This system includes one VS2100 single channel digital event recorder and one color camera.
It will automatically have image capture or video recording once motion is detected by
software, or manually by external alarm and will store in SD card (Not included). Simply press
the "PLAY" button and the recorded picture or video can be found quickly and easily.
Special Features：
1. Image Sensor: Color CMOS.
2. Resolution: 380 TV lines.
3. Scanning system: 2:1 interline.
4. Camera preset focus 3 meters.
5. S/N Ratio: >46dB.
6. Auto electronic Iris.
7. LED Illuminator: 5 IR LED.
8. Composite video input and output connections, compatible with most CCTV cameras.
9. Two video inputs, picture in picture monitoring (only selected channel can be recorded).
10. Video signal output can be NTSC or PAL system.
11. Resolution: 640 x 480.
12. Software motion detection
13. Automatic picture capture or video recording once motion is detected (with time and date).
14. Pictures auto play/review in Play mode.
15. LED indication for motion detection mode.
16. Slot for SD card up to 2GB (SD card is not included).
17. 85k per picture/ 640k per motion video (10 sec. long video)
18. External alarm output and input connections (Optional).
19. Includes AC adapter (100V~240V), 5VDC
20. Easy to set up in minutes.
21. Built in 32MB flash memory (for VS2100 32MB only).
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the VC2100 and is the answer not in the manual?

Questions and answers

Related Manuals for Voltek VC2100

Summary of Contents for Voltek VC2100

  • Page 1 VC2100 / VC2100 32MB Digital Event Recorder Product Description： This system includes one VS2100 single channel digital event recorder and one color camera. It will automatically have image capture or video recording once motion is detected by software, or manually by external alarm and will store in SD card (Not included). Simply press the “PLAY”...
  • Page 2 Product layout： Fig. 1 OK SELECTION BUTTON Confirm / Accept the option you select. UP BUTTON / MOTION DETECTION ON, OFF Normally it is used as the UP function selection button. When VS2100 is in standby status, MOTION DETECTION will be ON. Press this button as a quick access button. Press again to turn MOTION DETECTION OFF.
  • Page 3 11. MOTION DETECT INDICATOR LED LED flashes when picture capture / video recording is activated. 12. SD CARD SIOT Insert SD card to store the captured photos/AVI. 13. POWER SWITCH Turn ON / OFF VS2100. 14. PICTURE STORAGE SWITCH Motion captured by internal software or external output triggering. 15.

  • Page 4: Connecting To Power

    Initial set-up： 1. CONNECTING TO CAMERAS Fig. 2 Fig. 3 Please secure the CAMERA at suitable wall as you desire.（Fig.2 & Fig.3） Refer to Fig.2 for bushing installation and then screw on the junction box. iii) Connect the 4 pin din plug of WIRE D to CAMERA. (Fig.4) Connect the yellow RCA jack of WIRE D to the A/V terminal “CAM1”...

  • Page 5: Setting Time And Date

    4. SCART PLUG INSTALLATION (OPTION) If your TV set has no RCA A/V terminal please refer to Fig. 5 for scart transfer. Fig.5 5. CONNECTING TO ALARM (OPTION) Fig.6 6. INSERT SD CARD (NOT INCLUDED) Fig.7 Note: 1) VS2100 can work without SD card and the images will be stored in internal temporary SDRAM or Flesh memory (VS2100 32MB only).
  • Page 6 Select this icon and press “OK” button. Use “UP, DOWN, RIGHT and LEFT button” to adjust date and time. Note: The programmed time and date can only keep 12 hours when Mains is off i.e. when the power adapter is unplugged. 8.
  • Page 7 Press “UP” button again to turn “MOTION DETECTION OFF”. Note: Motion detection mode will be on when every time power is switched on. This is VS2100 internal default. 1. When “motion detect” is ON, it will enter “self-learning mode” (the upper-left icon will keeping flashing) automatically for about 60 seconds until it stops.
  • Page 8 page. Use “UP and DOWN” button to select the folder you want to review and then press “OK” to open that folder. Delete Pictures/AVI/folders： 1. Press “PLAY” button to enter single-picture review page, press “RIGHT or LEFT” button once will enter “Slide show” program to forward or reverse the pictures automatically. Press button again to stop and stay at the picture you want to delete.
  • Page 9 196mm x 130mm x 48mm (Digital image recorder) Dimensions(W x D x H) 125mm x 112mm x 72mm (Camera) Video/Image recorder Signal format NTSC Input signal Composite 1.0Vp - p ± 10% 75Ω (RCA terminal x 2) Output signal Composite 1.0Vp - p ± 10% 75Ω (RCA terminal x 1) Sampling resolution 704H x 240V 704H x 284V...
