Xcel®10-CHANNEL/BANK 6,8,12V
This product is a charger, trickle charger, and
maintainer. Its intelligent microprocessor-controlled
algorithms allow multi-stage charging of various
IMPORTANT: READ AND SAVE THIS SAFETY INSTRUCTION
MANUAL KEEP IT WITH OR NEAR CHARGER AT ALL TIMES
Printed material may not represent the latest information available. Please visit
our web-site
www.DPIpower.com
Manual P/N: MNUL0044-A001 Rev.2 : Copyright © 2020 DPI
BATTERY CHARGER
battery types and chemistries.
for updates to this or other manuals.
1
Advertisement
Table of Contents
Summary of Contents for DPI Xcel 7QP-12F950P25-C00
- Page 1 MANUAL KEEP IT WITH OR NEAR CHARGER AT ALL TIMES Printed material may not represent the latest information available. Please visit our web-site www.DPIpower.com for updates to this or other manuals. Manual P/N: MNUL0044-A001 Rev.2 : Copyright © 2020 DPI...
- Page 2 Model Numbers and Options: 7QP-12F950P25-C00: Wireless option is not installed 7QP-12F950P25-C01: Wireless option is installed Charge algorithm controls BOTH voltage and current for precise charging LCD Display with Menu Select, Microprocessor Controlled, Fully Automatic Read Charge Voltage, Amperage, Errors, and more in plain LCD Display Text ...
- Page 3 1. USER SAFETY OPERATIONS GUIDE Throughout this manual, look for this symbol. It means ‘BE ALERT – YOUR SAFETY IS INVOLVED’. If you do not follow these safety instructions, personal injury or property damage may occur. WARNING – RISK OF EXPLOSIVE GASES. WORKING WITH RECHARGEABLE...
-
Page 4: Personal Precautions While Working With Batteries
2. PERSONAL PRECAUTIONS WHILE WORKING WITH BATTERIES Have someone within range of your voice to come to your aid if needed. Have plenty of fresh water and soap nearby in case battery acid contacts your skin, clothing or eyes. Wear eye and clothing protection and avoid touching eyes. -
Page 5: Safe Grounding Instructions
wired and in good electrical condition, and large enough for the AC rating of charger as specified in this TABLE: RECOMMENDED MINIMUM AWG SIZE FOR EXTENSION CORDS FOR BATTERY CHARGERS Length of cord (feet): AWG size of cord: Refer to the Product ID Label affixed to the product and identify the input requirements such as ‘120Vac, 60Hz, 10Amps’. - Page 6 WARNING: The CHARGE MODE setting affects all charge channels, simultaneously. DO NOT mix battery types on various charge channels. For example, Large Capacity batteries cannot charge with Low Capacity Batteries; nor may Lithium batteries be mixed with Lead Acid Batteries. The MODE Select is accessed via the MENU button.
- Page 7 The MODE Setting affects all Channels simultaneously. If, for example, the factory preset MODE-1 is used, any and all batteries connected to the outputs must be the same or very similar Lead Acid Batteries. The CHARGE MODE VALUES AND SETTINGS is selected via the use of the MENU button.
-
Page 8: Menu Select Button
‘AH’ is an abbreviation for ‘Ampere-Hour’ and denotes the capacity rating of the battery. For example, a battery rating of 32AH stores more energy and has a higher energy capacity than an 18AH battery. These AH capacities also help establish charge safety timer values, explained further in the next section. - Page 9 LCD Display: At Power-On: The LCD Backlight illuminates For approximately 5 seconds, the CHARGE MODE and Battery Type are displayed For approximately 5 seconds the SOFTWARE VERSION displayed After approximately 10 seconds, the display defaults to displaying Channel-1 shown as CH01 in the upper left corner of the LCD display.
-
Page 10: Charging A Rechargeable Battery
7. CHARGING A RECHARGEABLE BATTERY Each set of Yellow and Green LEDs on the front of the charger are used to indicate the charge status state for the channel associated with the set of LEDs. Yellow LED Flashing – Battery testing in progress Yellow LED Solid –... -
Page 11: Usb Interface
Variations in this charge stage are highly dependent on the battery Charge MODE selected. Flooded Lead Acid batteries are often aggressively charged to high voltage levels to force internal gassing which helps to mix the electrolyte. AGM (Absorbed Glass Mat) batteries differ in that this stage limits upper voltage regulation levels which helps prevent them drying out. -
Page 12: Using The App
9. WIRELESS CONNECTION AND USE (-C01 Model Only) Download, Install APP (for wireless product model only: ‘-C01’) Look for the APP on the Google Play Store, ‘DPI 10-Channel C01 Charger’ Download the app and install it Open the APP and follow the easy guide instructions to connect your mobile device ... -
Page 13: Maintenance
APP DISPLAY: Setting The Real Time Clock (RTC): o Press/select the "Write RTC" button o APP will use the Smartphone’s internal clock to set the RTC time in the charger product Reading the Real Time Clock (RTC): o Press/select the "Read RTC" o Time will be displayed using your current time zone settings ... -
Page 14: One-Year Limited Warranty
Diversified Power International LLC (DPI) warrants exclusively to the original purchaser that this charger will be replaced or repaired, at DPI’s option, if it fails during the first year after the date of purchase due to defect in material or workmanship. Proof of purchase is required for all claims.
