6' & 8' Deluxe Tent
Product Parts
1- Frame
2- Soft Case with Wheels
3- Canopy
4- Stake Kit
Deluxe Frame has 1.25" Steel legs
and plastic coated metal lever
height adjustment
Set-Up
Step 1
Remove the Frame (1) from the soft case (2) and place it
at your desired location.
In tandem with another
person, separate the legs of
the Frame (1) until they are
extended a full arms length.
Step 3
Attach the Canopy (3) by
connecting the loop strips on the
Canopy (3) corners with the hook
strips on the four legs of the Frame
(1).
3
1
2
4
Step 2
Unfold your Canopy (3) and drape over the Frame (1). Position
the apex of the Canopy
(3) with the center pole
of the Frame (1).
Step 4
Stand diagonal to each other, lift and separate the legs
of the Frame (1). The Frame (1) will open a little at a time
so alternate ends until the Frame (1) no longer expands.
DO NOT DRAG FRAME-THIS COULD BEND THE LEGS
Page 1 of 2
Apex
1.20.17
Advertisement
Table of Contents
Summary of Contents for Country Enterprises 6 & 8 Deluxe Tent
- Page 1 6’ & 8’ Deluxe Tent Product Parts 1- Frame 2- Soft Case with Wheels 3- Canopy 4- Stake Kit Deluxe Frame has 1.25” Steel legs and plastic coated metal lever height adjustment Set-Up Step 2 Step 1 Unfold your Canopy (3) and drape over the Frame (1). Position Remove the Frame (1) from the soft case (2) and place it the apex of the Canopy at your desired location.
- Page 2 Set-Up Continued... Step 6 Step 5 Place your foot on the Unlock the Height Adjustment connectors on Frame base of the tent leg as you (1) legs. With connector in unlock position, lift the release and extend the framework upwards until the four sliding connectors lock telescoping legs.
