Operating Instruction

CHUCK 3 ZF ultra-short

Safety instruction

• Every chuck user should familiarise himself

with this operating instruction.

• Stop the work immediately if the chuck

functions incorrectly or is damaged.

• Avoid any hammer blows to the clamping

jaws or other parts of the chuck.

• Bear in mind the clamping jaw ranges!

• Do not start the machine tool with the key/

split pin inserted.

• Only use original MAPROX spare parts.

• Ensure with all chucks that the entire jaw

cogging meshes into the flat spiral.

• Key extensions can result in damage to the

chuck.

• In addition to the safety instructions included

in this operating instruction, the user is to

follow the local safety regulations.

• Size and weight of the work piece are to be

adjusted to the chuck or jaws in question.

• The chucks are used for clamping and/or

processing workpieces on lathes, grinding,

milling and measuring machines. They are

also suited for deployment on dividers.

Spiral

Ring

Retaining

ring

Body

Screw

bores

A-jaws

Table of Contents

Do you have a question about the CHUCK 3 ZF ultra-short and is the answer not in the manual?

Page 1 • Bear in mind the clamping jaw ranges! • Do not start the machine tool with the key/ split pin inserted. • Only use original MAPROX spare parts. • Ensure with all chucks that the entire jaw cogging meshes into the flat spiral.
Page 2 Maintenance The jaws, spirals and guides are to be regularly cleaned and greased. Machine oil or WD40, which also ensure smooth running, are suitable for using on measuring machines. Original MAPROX replacement parts • Stepped jaws A h h h •...
Page 3 Dimensions table for chucks 3 ZF 3 ZF Ø 68 (H7) 48.5 F 0 / +0.01 3 x 3.2 3 x 4.2 3 x 4.2 3 x 5.3 3 x 6.4 3 x 8.4 10.5 Travel Ø Weight in kg, approx. 21.0 Permitted rotational speed 2800...
Page 4 GUARANTEE CONDITIONS We expressly refer you to our General Terms and Conditions at: www.maprox.ch Maprox AG Tel: +41 (0)43 488 18 00 info@maprox.ch Bolstrasse 7 • CH-8620 Wetzikon Fax: +41 (0)43 488 18 08 www.maprox.ch...
