- Page 1 ActivUP Walking Desk User manual Model: AU202ED In order to download this manual’s latest version and access to detailed information, please follow this link: http://activup.net/s/?d=manenau200ed Page 1 / 23...
- Page 2 Thank you and congratulations for buying this walking treadmill, model AU202ED ! You can find below some useful information to contact us. Contact ActivUP S.A.S.U 125 route du fer à cheval 74160 Collonges-sous-Salève FRANCE Tel : +33 1 85 08 60 18 Website : http://www.activup.net...
- Page 3 Attention： Please check whether the red security lock is hung on the machine before use it. Please check whether the Red safety lock falls off Put the safety lock and turn on the treadmill Page 3 / 23...
-
Page 4: Table Of Contents
Table of contents / Index Safety instruction ........................5 Special safety instruction ....................... 5 Packing list ..........................6 AU202ED: Product description ..................... 8 Display specification ......................16 Assembly .......................... 16 Console function ....................... 16 Start instruction ........................ 17 Product specifications ......................17 Maintenance ........................ -
Page 5: Safety Instruction
➢ Some models are equipped with a safety key system extension to be placed under your desktop. To know more about it, please download the updated user manual available here : http://activup.net/s/?d=manenau200ed Page 5 / 23... -
Page 6: Packing List
Packing list Parts name Specification Picture Walking desk Internal hexagonal wrench One end with a cross screw driver Multi-function Cross head pin spanner Lubrication oil 20ML Filler Display Power cord Safety key cord 11 Use manual 12 Desktop Page 6 / 23... - Page 7 13 Side plate 14 Foot tube 15 Safety hook 16 Hook Power line for electric lift Hexagon socket M8*16 head screw 19 Console holder Page 7 / 23...
-
Page 8: Au202Ed: Product Description
AU202ED: Product description Desktop Telescopic legs Direction switch Stand column Safety key Walking area Self-service lubrication hole Handle Power switch foot pad Page 8 / 23... -
Page 9: Side Plate
Assembly： Walking desk Desktop Side plate Foot tube Safety hook The First step： Open the box, carry out the machine, find out the desktop, hook, safety hook and foot tube. Page 9 / 23... - Page 10 The second step: Set the desk upright, attach the foot tubes with M8*16 inner hexagon round head screw to the lifting table as shown on the picture below. foot tube ： Page 10 / 23...
-
Page 11: Hook
The third step： Fix the hook on the lifting table with M8*16 inner hexagon flat round head screw, as shown on picture below. Hook Page 11 / 23... - Page 12 The fourth step: Fix the side plate on the lifting table with M8*16 inner hexagon flat round head screw as shown on the picture below. Do not lock the screw at this time. Side plate Side plate Page 12 / 23...
- Page 13 The fifth step: Fix the table plate on the side plate with M8*16 inner hexagon flat round head screw as shown on the picture below. At this time, lock the unlocked screws mounted during the fourth step. Desktop Page 13 / 23...
- Page 14 The sixth step: Put the safety hook on the hook for use in case of need to fold the treadmill, as shown on the picture below. Hook Page 14 / 23...
-
Page 15: Head Screw
The seventh step: When you need to fold up the treadmill, attach the safety hook into the handle of the treadmill and hook on the hook, as shown on the picture below. The eighth step: If the lifting table needs to be separately used, you only need to unscrew out the two M8*50 flat round head screws of the lifting table and the lifting table, and then move the lifting table or the running table away. -
Page 16: Display Specification
Use the treadmill： After the power is plugged in and the safety lock is placed, turn on the switch and the treadmill will be on. At this time, you will hear a "di" sound and the meter will be on. Display specification Time 00:00-99:59 Min... -
Page 17: Start Instruction
Steps Display battery level Start instruction ➢ Press “ ” button, after 3 seconds the machine starts to run at 1km/h ➢ Turn the knob clockwise or counter clockwise “ ” to regulate your speed. ➢ Press“ ” pause the machine. Press again“ ”, the machine continues to maintain its normal operation. -
Page 18: Maintenance
Maintenance A regular maintenance is the only way to keep your walking treadmill functioning for the longest time possible. A lack of maintenance can reduce its lifespan. Adjusting the running belt Adjustment of running belt have two functions: to center the running belt and to adjust its tension. Running belt adjustment has already been done at the factory, but after use the running belt will be stretched and may run with off center position causing friction trim and rear cover damage. - Page 19 WARNING! Do not over-tighten the drum! This will lead to permanent bearing damage! Loosen by rotating both left and right screw equally. You should always be able to lift the running belt by hand. Lubricating Lubricating oil is added during the making process of the walking machine. However, the lubricity of the walking machine must be frequently checked, so that the walking machine can be kept in the optimal use state.
-
Page 20: Mobile App
Mobile App Scan the QR barcode to directly locate the mobile app on your App Store on your device (available for both Android and iOS devices). 一、Create your account 1-1. For first-time users, you must first register. If you already have an account, please enter your username and password. - Page 21 2-1. Activate your smartphone’s Bluetooth. Click on the home page on the blue button “Search” to start the device search. 2-2. Once the Bluetooth scan is completed, your treadmill will be displayed and connected to your smartphone. 2.3、Connect successfully 2-3. After a successful connection, you can select which recording mode you want to use (Normal or Map).
- Page 22 3.1、Motion setting 3-1. The setting menu is available through the icon presented on the picture above. 3.2、Select mode 3-2. After connecting the device, the application will display two modes (Normal or Map), you can choose any mode according to your needs, and then click the "start" button for movement. 3.3、Start exercise Page 22 / 23...
- Page 23 When you start the exercise, all the information about it will be displayed on your phone (distance, time, steps, etc.). In order to stop the recording, press the stop button. Page 23 / 23...
