Installer's Choice SnapRax SR43 Assembly Instructions

Model Numbers

SR43 SR43-26 - Load Rating - 600 Lbs.
SR37 SR37-26 - Load Rating - 600 Lbs.
SR29 SR29-26 - Load Rating - 600 Lbs.
SR21 SR21-26 - Load Rating - 500 Lbs.
SR14 SR14-26 - Load Rating - 300 Lbs.
SR8 SR8-26 - Load Rating - 200 Lbs.

Components and Supplied Hardware

Top
A (4) #1/4-20 x 1/2" Flat Head Socket Screws
SR-T
B (1) 5/32 Hex Wrench
SR-T-26
Base
A (4) #1/4-20 x 1/2" Flat Head Socket Screws
SR-B
B (1) 5/32 Hex Wrench
SR-B-26
Main Rails
(125) #10-32 x 1/2" Self-Tapping Screws
SR43-R
(100) #10-32 x 1/2" Self-Tapping Screws
SR37-R
(75) #10-32 x 1/2" Self-Tapping Screws
SR29-R
(75) #10-32 x 1/2" Self-Tapping Screws
SR21-R
(50) #10-32 x 1/2" Self-Tapping Screws
SR14-R
(25) #10-32 x 1/2" Self-Tapping Screws
SR8-R
Please read INSTALLER'S CHOICE
SnapRax Instructions BEFORE Installation
Assembly Instructions
IMS EP Installer's Choice has provided assembly instructions with the goal to make this assembly as easy
TM
and complete as possible. IMS EP Installer's Choice
covers all details, conditions, or variations. It also does not provide for each and every possible incident in
connection with the installation or use of this product. IMS EP Installer's Choice
information/product changes as required without prior notification. IMS EP Installer's Choice
statement of warranty (expressed or implied), regarding the information contained herein. IMS EP Installer's
Choice assumes no responsibility for accuracy, completeness or sufficiency of the information contained in
TM
this document.
Final installation of equipment into the enclosure (SnapRack) system will be performed by qualified
personnel in accordance with NFPA70, National Electrical Code (NEC). The SnapRack is intended to be
used with UL Listed product.
Not for use in a computer room as defined in the Standard for the Protection of Electronic Computer/
Data Processing Equipment, ANSI/NFPA 75.
WARNING
Do not use this product for any purpose not explicitly specified by Installer's Choice
The size and weight of your rack/component mount equipment must not exceed the stated weight loads
established for each Installer's Choice model.
TM
Failure to comply with these requirements could result in serious injury or property damage. If you do not
understand these directions, or have doubts about the safety of the installation, contact Installer's Choice
Customer Service @ 847-391-8100.
Installer's Choice is not liable for damage/injury caused by incorrect mounting, assembly, or use.
TM

Supplied Parts and Instructions

Before starting installation, please read ALL instructions carefully. Verify all parts are included and undamaged.
If any parts are missing or damaged, do not return the item to your dealer/installer-contact Installer's Choice
Customer Service at 847-391-8100.

Warranty

This warranty is provided in goodwill and extends only to the original purchaser of the IMS EP Installer's Choice
SnapRax product; it is non-transferable. This warranty is automatically void if your Installer's Choice SnapRax
product is modified in any way: improperly installed, extended beyond its stated weight capacity or otherwise
misused or abused. This warranty cannot be transferred over or extended to anyone other than the original
purchaser. The ten-year warranty for all SnapRax and SnapRax-related products is void if the rack is altered or
modified in any way, shape or form.
Installer's Choice disclaims any other warranties, express or implied- including warranties of fitness for a
particular purpose and warranties of merchantability- to the maximum extent permitted by law. Installer's Choice
is not liable for any damages whatsoever arising from the use of or inability to use its products, even if Installer's
Choice has been advised of the possibility of such damages. Installer's Choice disclaims any responsibility for
incidental or consequential damages to the maximum extent permitted by law.
Installer's Choice
1 Innovation Drive • Des Plaines, IL, 60016 • Ph-847-391-8100 • Fax-847-391-8354
SRINSTF-2.0
TM
makes no claim that the information contained herein
TM
reserves the right to make
TM
TM
.
TM
TM by IMS EP • Designed & Manufactured in the U.S.A.
www.installerschoice.com
