Summary of Contents for Griesbach Diamond H2O LINQ DLS-30-100
- Page 1 Diamond LINQ Softener Single Tank Product Manual Diamond LINQ Softener Single Tank Product Manual pg. 0 920-757-5440 www.diamondh2o.com N1022 Quality Drive, Greenville, WI 54942...
- Page 2 Diamond LINQ Softener Single Tank Product Manual Set Up Instructions for DLS-Series Single Tank Inspect the packaging of the equipment to confirm that nothing was damaged during shipping. (Figure 1) Remove the resin tank(s) and valve(s) from the packaging. Make sure everything is included and without damage.
- Page 3 Diamond LINQ Softener Single Tank Product Manual Table 1: Media Requirements. Example: A DLS-120-100 would require 4 cubic feet of resin and 50 pounds of gravel per tank. Model Number Amount of Resin per Amount of Gravel Tank (cu. ft.) per Tank (pounds) Distributer DLS-30-100...
-
Page 4: How A Water Softener Works
Diamond LINQ Softener Single Tank Product Manual How A Water Softener Works Water hardness is derived from Calcium and Magnesium minerals that have been dissolved into the water under the earth’s surface. These minerals are found in limestone deposits and are the source of hard water. -
Page 5: Service/Operation
Diamond LINQ Softener Single Tank Product Manual Figure 7: General Softener Operations Key: Hard Water Soft Water Salinized Water Resin Service/Operation Backwash: Flow reversed to flush debris from resin bed to drain. Regenerate Fill: Water is sent to the Brine Tank to create regenerant for next regeneration cycle. - Page 6 Diamond LINQ Softener Single Tank Product Manual Installation Requirements A level floor position ahead of piping into water heater. Unit must be installed at least 10’ ahead of the inlet to a water heater to prevent damage due to back-up of hot water.
- Page 7 Diamond LINQ Softener Single Tank Product Manual 1. Obtain the required tools listed below: A. Utility Knife B. Pliers C. Phillips Screwdriver D. Hammer E. Level F. Softener filling funnel 2. Place the tanks near a water source. A. Select a position near a floor drain that has adequate carrying capacity to handle the backwash flow rate.
- Page 8 Diamond LINQ Softener Single Tank Product Manual 3. Setting up the tank: A. Fill the tank up to 30% full of water. B. Check the system specifications on page 2 to determine the correct amount of gravel and resin needed for your system. C.
-
Page 9: Connect The Brine Tank
Diamond LINQ Softener Single Tank Product Manual 4. Connect the brine tank. A. Remove the ties on the brine line hose (included in the brine tank). B. Remove the well cap and connect one end of the brine line hose to the brine line connection (Shown in Figure 14) of the brine tank. -
Page 10: Connect The Power Supply
Diamond LINQ Softener Single Tank Product Manual 5. Connect the Valves to the Water Source A. Pipe or tube a line from the Control Valve Drain (Figure 15) to the drain. DO NOT install a valve in this line ... - Page 11 Diamond LINQ Softener Single Tank Product Manual 7. Start up the system for the first time. A. Add about three gallons of water to the brine tank. B. Double check that the tanks are filled with water. a. Manually put the control valve into regeneration (Hold the SET/CHANGE button or press the “regen now”...
- Page 12 Diamond LINQ Softener Single Tank Product Manual Programming pg. 11...
- Page 13 Diamond LINQ Softener Single Tank Product Manual pg. 12...
- Page 14 Diamond LINQ Softener Single Tank Product Manual pg. 13...
- Page 15 Diamond LINQ Softener Single Tank Product Manual 9. Diamond LINQ Application For simplified set up and control, please install the Diamond LINQ on a compatible Bluetooth 4.0+ enabled smart phone or tablet. A. Depending on your device, download and install the Diamond LINQ app from: ...
- Page 16 Diamond LINQ Softener Single Tank Product Manual E. Dashboard The dashboard will contain general information for monitoring your softener which is contained in blocks. Blocks with a red “Set” can be changed or updated. Other blocks are read only. NOTE: Consult your dealer before making any changes from the Dashboard.
- Page 17 Diamond LINQ Softener Single Tank Product Manual F. Advanced Settings The advanced settings section of the app should only be programmed by a dealer. These settings contain values that will affect the performance of the water softener and the quality of the treated water.
- Page 18 Diamond LINQ Softener Single Tank Product Manual G. Status and History The status and history screen displays statistics which can be used to increase system efficiency and diagnose certain issues. The system includes a totalizer which keeps track of total water usage and regeneration data.
-
Page 19: Troubleshooting
Diamond LINQ Softener Single Tank Product Manual 10. Troubleshooting pg. 18... - Page 20 Diamond LINQ Softener Single Tank Product Manual 10. Troubleshooting (2) pg. 19...
- Page 21 Diamond LINQ Softener Single Tank Product Manual pg. 20...
