- Page 1 EP120 series EP120-08-123/EP120-16-246/EP120-24-370 Unmanaged Gigabit PoE+ Switches Quick Installation Guide EP120 系列 非管理型千兆 PoE+ 以太網交換机快速安裝指南 Rev1.1 2017 May...
- Page 2 AC Power. Make sure that there is proper heat dissipation and adequate ventilation around the Switch. Do not place any heavy objects above the Switch. Users can check more technical specifications from http://www.soarnex.com if necessary. LED Indicators EP120-08-123 EP120-16-246 EP120-24-370...
- Page 3 The LEDs of the Switch are located on the front panel. Color Status Description Indicative Solid Light Power On Power Green Light Off Power Off Fan Error The fan is abnormal Solid Light (EP120-16/24) This indicates that the PoE power is less than 7 Solid Light Watts PoE Max...
- Page 4 Hardware Installation 1. Attach the rubber footpads to the recessed areas on the bottom of the Switch. 2. Place the Switch on a flat desk or shelf. 3. Attach the mounting brackets on the both sides of the Switch and secure them with the screws.
- Page 5 4. EP120-24-370: Up to 30 Watts per port and the maximum total power budget of 370 Watts 僅适用于海拔 2000 米以下地區安全使用 © Copyright SOARNEX Technology Corp. 2015 Contents are subject to change without prior notice. Document is also available on SOARNEX Website Rev 1.1 2017 May...
- Page 6 3. 交流电源線 x 1 4. 机架安装架 ( EP120-16/24) x 1 5. 橡胶脚墊 x 4 6. 快速安装指南 x 1 注意事項 請在一个温度和濕度均适宜的環境下安装交換机。 电源線引出口要在离開交換机 1.82 米（6 英尺）以內。 确保交換机周边有一定的熱量耗散空间以及一定的通风空间。 不要在交換机上放置重物。 請在公司网站 http://www.soarnex.com 上查看更多的技述說明資料。 LED 指示燈 EP120-08-123 EP120-16-246 EP120-24-370 交換机的 LED 指示燈位于前面板上 . LED 指示燈 顏色 狀態 描述...
- Page 7 PoE 可用功率小於 7W 恒亮 PoE Max 紅色 PoE 工作正常 燈滅 1000Mbps 以太网接口鏈路已建立 恒亮 綠色 1000Mbps 以太网接口有數據收發 閃爍 10/100Mbps 以太网接口鏈路已建立 恒亮 Speed 橙色 10/100Mbps 以太网接口有數據收發 閃爍 燈滅 燈滅 以太网端口无連接或被管理員關閉 已連接 PoE 受电设备 (PD) ，并且端口已正常供电 綠色 恒亮 表示下列故障之一導致該端口出錯：過大电壓 , 過低 橙色 恒亮 电壓...
- Page 8 SOARNEX Technology Corp. support@soarnex.com http://www.soarnex.com 29072466P120082...
