Wheego LiFe 2011 Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

owner's manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LiFe 2011 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Wheego LiFe 2011

Summary of Contents for Wheego LiFe 2011

  • Page 1 owner’s manual...
  • Page 2 My Wheego Dealer’s Telephone number:__________________________ The Wheego LiFe is designed to be plugged in when not in use; the batteries gradually discharge when the car is not plugged in. Damage due to failure to keep The vehicle identification number (VIN) can be found on the VIN plate, located on the batteries properly charged is not covered under your warranty.

  • Page 3: Table Of Contents

    WHEEGO’s objectives include customer safety, product satisfaction and pride of ownership. This Owner’s Manual is designed to acquaint you with the proper and safe operation of your WHEEGO. Please take the time to read and understand the manual before operating your vehicle.
  • Page 4 Maintenance schedules and general care instructions are included in the Maintenance section. lesser capacity and/or using a cord from an outlet to the WHEEGO that is not sufficient in This manual is applicable to the following WHEEGO line of vehicles: wire gauge could create a fire hazard.

  • Page 5: Consumer Information/ Reporting Safety Issues

    If NHTSA receives similar complaints, it may open an investigation, and if it finds that a Your ability to drive your WHEEGO can be seriously impaired with blood alcohol levels safety defect exists in a group of vehicles, it may order a recall and remedy campaign.

  • Page 6: Understanding Your Car's Features

    WARNING Your Wheego LiFe’s 12V battery under the front hood powers the accessories such as headlights and horn. Electrolytes can leak from damaged or defective batteries. 4. UNDERSTANDING YOUR CAR’S FEATURES Avoid contact with skin, eyes, or clothing.
  • Page 7 A. Key Fob 3 BUTTON KEY FOB Your key fob allows remote locking and unlocking of the driver and passenger doors and the rear hatch. Press the round silver button to release the ignition key. Lock doors Unlock doors Open rear hatch (press and hold for 3 seconds)
  • Page 8 B. DASHBOARD AND CONTROLS INSTRUMENT PANEL • Instrument Panel o Speedometer o Odometer/Trip Meter/Miles on Charge o BDI Gauge o Amp Meter o Volt Meter Eco-Meter o Indicator Lights o Setting Clock, Metric/English, Contrast Level • External Lights, Turn Signals and Hazard Warning Flashers •...
  • Page 9 SPEEDOMETER ODOMETER/TRIP METER/ The Speedometer shows the current driven MILES ON CHARGE speed of the vehicle in miles per hour. Press the stem on the lower right of the console to access the Odometer (miles), The display beneath the speedometer Trip Meter (miles), and Miles remaining shows the status of the shifter: Park, on Current Charge Meter.
  • Page 10 The more green that is showing, the more you are driving the battery pack while the key is in the ON position. The 100% in a fashion that is economical on the battery pack. The Wheego LiFe charged position is all the way to the top and the fully discharged utilizes regenerative braking, which captures kinetic energy normally lost position is on the bottom.
  • Page 11 Service Light - indicates your car needs service. Contact your Wheego dealer. (Flashing) Tire Pressure Monitor Failure Indicator – Indicates the Tire Pressure Monitoring system is not working.
  • Page 12 Low Brake Fluid Light – Indicates you are low on brake fluid. OEM Settings – for manufacturer use only (password protected) Maintenance/Service – for Wheego technicians only (password protected) Airbag Light – Indicates the airbag may not be working properly; you need to User Functions –...
  • Page 13 CONSOLE CONTROL D-PAD Backlight Low – Screen contrast when the headlights are on (night driving). Default is 02. User Functions LCD Settings Choose value between 1 and 10. The higher the number, the brighter the screen. Backlight High – Screen contrast when the headlights are off (daytime driving). Default is 10.
  • Page 14 EXTERNAL LIGHTS AND TURN SIGNALS The left lever controls the turn signals and lights. To turn on the parking lights, instrument panel lights and other external lights, rotate the lever knob up Headlights / Highbeams one click. To turn on the headlights, rotate the lever knob up one more click.
  • Page 15 HAZARD WARNING FLASHER CAUTION A damaged or worn wiper blade may reduce vision and impair you from seeing well Your vehicle’s hazard warning flasher is an enough to drive safely. A worn wiper blade could damage windshield glass. If your wiper emergency warning system.
  • Page 16 KEY SWITCH TIRE PRESSURE MONITORING SYSTEM Unplug cord before inserting the key into switch. The car must be in park before Each tire should be checked monthly when cold and inflated to the inflation pressure you begin the starting sequence. When the key is turned clockwise to the first recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure “ACC”...
  • Page 17 The TPMS malfunction indicator is combined with the low tire pressure telltale. When the There are 3 knobs to control the ventilation system. The left knob controls the temperature. Turn it counterclockwise to increase the temperature and clockwise to decrease the temperature. system detects a malfunction, the telltale will flash for approximately one minute and then remain continuously illuminated.
  • Page 18 To ensure your child is as safe as possible in a vehicle, never place him/her in front of an airbag. If your child rides in the WHEEGO, move the seat as far back as possible, away from the airbag. Infants will only be safe in their rear-facing child safety seats if the airbag has been switched off.
  • Page 19 RADIO - AM/FM/CD/USB/MP3 RECEIVER Ejects the disc Loading slot Display window USB input jack INTERIOR DOME LIGHT Detaches the panel Control dial Remote sensor Auxiliary input jack The interior dome light illuminates the passenger compartment of the vehicle. There are three switch positions: Included in this section are the basics for operating the radio/CD player.
  • Page 20 There are lock and unlock buttons on the vehicle key that will The windows in your electronically lock and unlock the doors. The doors can also be WHEEGO vehicle are locked and unlocked manually with the key. If the doors are locked motor operated. Push on...
  • Page 21 D. REMOTE CHARGING PORT DOOR RELEASE TAILGATE LATCH RELEASES The charging port door is released when you pull up on the remote lever located on the floor next to the driver’s door (toward the rear of the driver seat). HOOD RELEASE The hood release is located to the left of the brake pedal in front of the driver’s door.
  • Page 22 Park (P) C. SHIFTER AND PARKING BRAKE With the key turned ON and the brake depressed, push in the button on the left of the The transmission positions are: shifter knob and move the shifter to Park (P) position. Pull up on the emergency brake. Stop / out of gear P - Park The car is now ready to be turned off.
  • Page 23 Sport (2) With the key turned ON and the brake depressed, release the emergency handbrake if it NOTE is engaged. Push in the button on the left of the shifter knob and move the shifter to the The parking brake is adjustable and should be checked periodically by a trained Sport (S) position.
  • Page 24 D. FOOT PEDALS E. SEATS BRAKE PEDAL 1. Adjustable Bucket Seats The brake pedal is located on the driver’s floor to the left of the accelerator pedal. To slow 2. Head Rests or stop the vehicle, firmly press the foot brake pedal. 3.
  • Page 25 1. ADJUSTABLE BUCKET SEATS 2. HEAD RESTS The driver and passenger seats have a metal bar located under Your vehicle is equipped with driver and passenger head rests which are designed to help protect the seat occupant in the the front edge of the seat to allow the seats to be moved toward event of a crash. All occupants, including the driver, should the front or rear of the vehicle as needed by the passengers. not operate the vehicle or sit in a vehicle’s seat until the head restraints are placed in their proper positions.
  • Page 26 3. SEAT BELTS PROPER USE OF YOUR LAP AND SHOULDER BELT The WHEEGO is equipped with safety belts for driver and passenger. Research has shown 1. Enter the vehicle and sit back. 2. The safety belt buckle is located just behind the outer side edge of the seat. Grasp that safety belts save lives.
  • Page 27 WARNING Maximum occupancy is limited to 2 people (including the driver) in the WHEEGO LiFe. Using a seat belt extender when not needed can increase the risk of injury in a collision. Only use when the seat belt is not long enough when it is worn low and It is extremely dangerous to ride in a cargo area of a vehicle.
  • Page 28 4. CHILD RESTRAINTS INFANTS AND CHILD RESTRAINTS Safety experts recommend that children ride rearward-facing in the vehicle until they are at least one year old and weigh at least 20 lbs (9 kg). Two types of child WARNING restraints can be used rearward-facing: infant carriers and “convertible” child seats. Everyone in your vehicle needs to be buckled up at all times–babies and children, The infant carrier is only used rearward-facing in the vehicle.
  • Page 29 TIPS FOR GETTING THE MOST OUT OF YOUR CHILD RESTRAINT • Before buying any restraint system, make sure that it has a label certifying that it meets all applicable Safety Standards. The manufacturer also recommends that you try a child restraint in the vehicle seats where you will use it before you buy it. •...
  • Page 30 CHILDREN TOO LARGE FOR BOOSTER SEATS Children who are large enough to wear the shoulder belt comfortably, and whose legs are NOTE long enough to bend over the front of the seat when their back is against the seat back, For additional information refer to seatcheck.org or call 1-866-SEATCHECK.
  • Page 31 When the passenger airbag enables emergency responders arriving at an accident scene to work on victims without feature is turned off, the airbag will not deploy in the event of worrying about the danger of shock (to either the victims or to themselves) from the an accident. lithium battery pack. Emergency personnel should turn the ignition key off and take it out to make sure the car is turned off. Only a Wheego authorized service technician should To turn the passenger airbag back on, insert the key and turn reconnect the battery. it to the “on” position. When infants in rear-facing child safety seats and children who are unrestrained are placed in the front seat with an airbag, they may be too close to an inflating airbag in the event of a crash. An airbag will inflate at speeds up to 200...

  • Page 32: Charging Your Car

    CAUTION can charge your car anywhere Do The Wheego LiFe is designed to be plugged in when not in use; the batteries there is standard 120V power. gradually discharge when the car is not plugged in. Damage due to failure to keep If you are only driving your batteries properly charged is not covered under your warranty. Batteries must not...
  • Page 33 If you purchase the recommended 220V charging station, it comes equipped with a The charging status lights are located in the charging port. When the vehicle is charging, hardwired charging cord with J1772 standard connection as shown. the three LEDs in the charge port will flash, indicating power input to the charger. (If you are using the 120V cord, only one LED will flash green, indicating that only one of the three The J1772 charge port receptacle on the car is an industry standard, so your car can be on-board chargers are being used.) charged from any 120V or 240V public charging station equipped with the J1772 connector.
  • Page 34 LONG TERM STORAGE Should you need to store your WHEEGO vehicle for a period of more than a week, you will need to temperatures as this will make sure it is plugged in. Do not store your car at extreme high or low...

  • Page 35: Driving Your Car

    1. Disconnect the power cord, and store it in a safe place (or return cord to charging station holder). Should you need to transport your WHEEGO vehicle, the best way is to use a car carrier or 2. Enter the vehicle and close both doors.

  • Page 36: Vehicle Maintenance

    7. VEHICLE MAINTENANCE A. Batteries and charging B. Battery disposal C. Brakes and fluid level D. Tires E. Tire changing F. Fuse blocks G. Key replacement, Key fob battery replacement H. Care and cleaning I. Maintenance schedule J. Fluids and lubricants...
  • Page 37 12 Volt battery. This The Wheego LiFe is designed to be plugged in when not in use; the batteries insures that it will not become discharged if an accessory were to be left on overnight. It is gradually discharge when the car is not plugged in.
  • Page 38 WARNING WARNING • Improper handling of high voltage wiring, batteries or control systems could • Improper handling of high voltage wiring, batteries or control systems could result in serious or fatal injury by electric shock. result in serious or fatal injury by electric shock. •...
  • Page 39 The Lithium batteries are also recyclable - contact a certified Wheego technician for removal. Contact your local and/or state environmental officials regarding battery disposal information.
  • Page 40 D. TIRES The standard tire delivered on your Wheego LiFe is a Triangle Tire Talon Sport tubeless WARNING steel belted radial tire, Model TR918. The size is 195/50R15. Proper tire inflation is essential Improperly inflated tires are dangerous and can cause accidents.
  • Page 41 Tire inflation pressure is shown on the sidewall of the 195/50R15 tires and in the following table: WARNING Do not use a tire size other than the one specified on your vehicle’s tire label. • TIRE AND LOADING INFORMATION Improperly sized tires can cause vehicle components to wear out prematurely •...
  • Page 42 The following chart shows the recommended tire inflation pressure The following information is imprinted on your tire Label Value Meaning Term Definition Reading Tire Manufacturer Triangle Tire Tire Model Talon Sport Cold inflation pressure Inflation pressure of tire 51psi US DOT Compliance Code DOT 2VXD wwyy DOT compliant before the car is driven...
  • Page 43 Contact your WHEEGO Dealer for a replacement tire. Jacking at any location other than a proper jacking point may cause major vehicle body damage.
  • Page 44 F. FUSE BLOCKS A second fuse box is located The fuse block is located under inside the car, on the driver’s side the hood on the driver’s side under the dash. A sticker on the next to the firewall. A sticker cover indicates the function and is attached to the inside of the amp rating of each fuse. fuse block cover that shows the function and amp rating of the fuses.
  • Page 45 G. KEY REPLACEMENT / KEYFOB BATTERY REPLACEMENT H. CARE AND CLEANING To obtain an extra or replacement key for your vehicle, please contact your WHEEGO dealer. Windows and windshield glass can be cleaned using a liquid household glass cleaner. You will need to have your key code and VIN available when you call. Your local locksmith Do not use abrasive cleaners on the vehicle glass as it can cause scratches.
  • Page 46 I. MAINTENANCE SCHEDULE J. FLUIDS AND LUBRICANTS I = inspect Miles in thousands R = replace Brake fluid DOT-3 Parking brake & cable adjustment L = lubricate Transmission lubricant - 75W85 Castrol PD oil (should not need to be refilled) Brake pedal clearance AC refrigerant 134a Rear wheel brake shoe/drum...

  • Page 47: Diagnostics/Troubleshooting

    8. DIAGNOSTICS/TROUBLESHOOTING Diagnostic Screens NOTE: Should the hazard flashers start to automatically flash after turning the vehicle ON, Battery Diagnostics 1 remove the key from the switch, press the lock button on the key, then press the unlock Field Value/Range Meaning/Notes button, put the key back into the switch and turn the vehicle back ON to restore normal Pack Voltage...
  • Page 48 Battery Diagnos tics 2 Climate Control Dia gnostics Watts per Mile Raw 0 to 32767 W/m Real time watts per mile calculation without Temp Set Point 68 to 95°F Sets desired cabin temperature filtering Cabin Temperature 0 to 150°F Shows estimated cabin temperature Watts per Mile 0 to 32767 W/m Average watts per mile...

  • Page 49: Customer Service And Warranty

    Operating System Version in the motor controller Build Number Identifies the build number of the operating system Owners of a WHEEGO can obtain maintenance and warranty service, if required, from VCL Version Shows the VCL version installed in the controller...
  • Page 50 The lithium battery pack is covered for 48 months, 60,000 miles (whichever comes first) The WHEEGO warranty is that each car will be free from any original defect in parts, LABOR warranty period. An extended warranty is available offering an additional...
  • Page 51 Damage caused by water or other liquid entering the battery compartment. In no event shall Wheego Electric Cars or any of its affiliates be liable for any incidental, o Discharged batteries that can be recharged and returned to service.
  • Page 52 Without limiting the generality of the foregoing, Wheego Electric Cars disclaims a warranty claim may do so through an authorized WHEEGO dealer, service provider or any implied warranty of merchantability or fitness for a particular use or purpose, and all by contacting Wheego Electric Cars.

  • Page 53: Vehicle Identification And Specifications

    E. TRANSFER OF WARRANTY label inside the driver’s door jamb. Upon the sale or transfer of a Wheego, the original owner may transfer this Warranty in accordance with Company procedures for a fee of $100.00. Please see your Dealer for details.
  • Page 54 Vehicle Length: 118.90 inches Vehicle Height: 62.99 inches For the Wheego Life, the following load limits apply. Wheelbase: 79.74 inches Curb Weight (weight of the car with no passengers or cargo): approximately 2,828 lbs.

  • Page 55: Index

    INDEX INDEX 12V Battery Jack - 20, 34 Door Open Light - 22 Drivers forum - 2 Cautions - 7, 23, 29, 30, 62, 66, 72, 74, 89 Impact Sensor - 61 A/C Light - 21 Charging - 62-67 Indicator Lights - 20-22 Adjustable Bucket Seats - 48 EasyCare - 3 Charging Cable - 62, 63...
  • Page 56 INDEX INDEX Maintenance - 90 Safety Information - 9, 10 Vehicle Identification Number (VIN) - 2, 105 Mirror Controls - 39 Seatbelts - 21, 50-54 Vehicle Maintenance - 70 Seats - 47-49 Ventilation Controls - 32, 33 Notes - 7, 45 Service Light - 20 Volt Meter - 19 Shifter - 42-45...
  • Page 57 • Always assume the vehicle is powered-up despite no engine noises. • Never touch, cut, or open any orange cable or components protected by orange shields. To disconnect main power in the Wheego LiFe: 1. Put vehicle in park, turn ignition off, and remove key.
