- Page 1 IP315 Backplane for PICMG 1.3 User’s Manual Version 1.0 (JAN 2020)
- Page 2 IBASE Technology, Inc. (hereinafter referred to as “IBASE”). Disclaimer IBASE reserves the right to make changes and improvements to the products described in this document without prior notice.
- Page 3 0.1% by weight (1000 ppm) except for cadmium, limited to 0.01% by weight (100 ppm). • Lead (Pb) • Mercury (Hg) • Cadmium (Cd) • Hexavalent chromium (Cr6+) • Polybrominated biphenyls (PBB) • Polybrominated diphenyl ether (PBDE) IP315 User’s Manual...
- Page 4 Danger of explosion if the internal lithium-ion battery is replaced by an incorrect type. Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer’s instructions or recycle them at a local recycling facility or battery collection point. IP315 User’s Manual...
- Page 5 Software in use (such as OS and application software, including the version numbers) If repair service is required, you can download the RMA form at http://www.ibase.com.tw/english/Supports/RMAService/. Fill out the form and contact your distributor or sales representative. IP315 User’s Manual...
-
Page 6: Table Of Contents
Dimensions ..................5 Chapter 2 Hardware Configuration .......... 6 Setting the Jumpers ................7 Connector Locations on IP315 ............8 Jumpers Quick Reference ..............9 2.3.1 USB 2.0 Connector (USB1,USB2)..........9 2.3.2 ATX Power ON Pin Header (J3) ..........9 2.3.3 Reset Pin Header (J4) .............. - Page 7 This page is intentionally left blank. IP315 User’s Manual...
-
Page 9: Chapter 1 General Information
Chapter 1 General Information The information provided in this chapter includes: • Features • Specifications • Board Picture • Board Dimensions... -
Page 10: Introduction
Introduction IP315 is a Backplane for PICMG 1.3 CPU module. Measuring 310 mm x 327 mm (12.2” x 12.9”), it provides expansion slots connectors including one PICMG 1.3 slot, one PCIe(16x) slot (x8 signal), two PCIe(8x) slot (x4 signal), four PCIe(4x) slot (x1 signal), four PCI slot, two USB 2.0, and two SATA3.0. -
Page 11: Specifications
8pin power connector x 1(for 12V) Power Connector 3-pin type fan connector x 2 Operating 0°C ~ 60°C (32°F ~140°F) Temperature Others Validated with IB995 RoHS2.0 PCB Layer 4 Layers Board Size 310mm x 327mm (12.2” x 12.9”) IP315 User’s Manual... - Page 12 Board Picture Top View IP315 User’s Manual...
-
Page 13: Dimensions
General Information Dimensions IP315 User’s Manual... -
Page 14: Chapter 2 Hardware Configuration
Chapter 2 Hardware Configuration This section provides information on jumper settings and connectors on the board in order to set up a workable system. • Jumper and connector locations • Jumper settings and information of connectors... -
Page 15: Setting The Jumpers
1 2 3 When two pins of a jumper are encased in a jumper cap, this jumper is closed, i.e. turned On. When a jumper cap is removed from two jumper pins, this jumper is open, i.e. turned Off. IP315 User’s Manual... -
Page 16: Connector Locations On Ip315
Connector Locations on IP315 Board diagram of IP315 IP315 User’s Manual... -
Page 17: Jumpers Quick Reference
When pressed again, it will power off the system. 2.3.3 Reset Pin Header (J4) The reset switch allows you to reset the system without turning the main power switch off and then on again. Orientation is not required when making a connection to this header. IP315 User’s Manual... - Page 18 IP315 User’s Manual...
-
Page 19: Connectors Quick Reference
SHB Express™ Connector Pinout BP_CONNC1, BP_CONND1 PCI Routing (PCI1,PCI2,PCI3,PCI4) 2.4.1 ATX Power Connector (J1) Signal Name Signal Name 3.3V 3.3V 3.3V -12V Ground Ground PS-ON Ground Ground Ground Ground Ground Power good 5VSB +12V +12V 3.3V Ground IP315 User’s Manual... -
Page 20: Atx 12V Power Connector (Atx_12V_2X1)
RSVD 12 GND USBOC3# 12 CLKC CLKD b_PETp0 GND a_PETp1 a_PETp10 13 SATAHT0 +3.3V 0 GND b_PETn0 GND a_PETn1 a_PETn10 14 SATAHT0 SATAHT0 CLKA CLKB 0 GND N GND N GND b_PERp0 a_PERp10 15 GND SATAHR0 +3.3V IP315 User’s Manual... - Page 21 +12V +12V 47 +3.3V +3.3V AD02 a_PERn0 +12V +12V 48 +3.3V +3.3V AD03 AD01 a_PETp1 GND +12V +12V 49 +3.3V +3.3V AD00 a_PETn1 GND` 50 +3.3V +3.3V a_PERp1 51 GND a_PERn1 52 GND a_PETp2 GND 53 GND IP315 User’s Manual...
-
Page 22: Pci Routing (Pci1,Pci2,Pci3,Pci4)
+3.3V +3.3V 81 +12V +12V +3.3Vaux +3.3Vaux 82 +12V +12V 2.4.5 PCI Routing (PCI1, PCI2, PCI3, PCI4) PCI Routing List IDSEL REQ# GNT# INT# Device AD31 B,C,D,A PCI1 AD30 C,D,A,B PCI2 AD29 D,A,B,C PCI3 AD28 A,B,C,D PCI4 IP315 User’s Manual...
