AGPTEK Wireless Controller User Manual
Thank you for purchasing the AGPTEK product. Please read this
[User Manual] carefully before using the product, and retain it in
for future use. If you have any questions or suggestions about
our products, please contact: support@agptek.com.
Package Contents
1. Wireless Controller*2
2. NES Wireless Receiver*2
3. USB Wireless Receiver*2
4. USB Cable*2
5. User Manual*1
Detatils Description
USB Recharge Port
Start/Wakeup Button
Link Indicate: Red LED
Recharge Indicate: Blue LED
Fast STARTUP:
Plug the adapter to Console/PC, then press the START button
of Controller.
1. Insert the receiver into the NES game console or PC.
2. Press and hold the START+SELECT+UP for 1s until Red LED
flashes quickly. At this point Controller is in pairing mode. After
Red LED does not flash quickly, but stays on, which means the
pairing between the receiver and controller is successful.
3. If without any operations after 5s, Controller will enter into
the standby mode. Red LED will turn off, and only the LED of NES
Wireless Receiver will flash (USB Wireless Receive will not). You
can activate the Controller via pressing any button.
4. Controller will enter into sleep mode if there is no operations
after 10 mins. You can press the Start button to wake up the
controller.
5. RESET Key = Press the START+SELECT at the same time.
Controller Working States:
1．Pairing Mode: Press and hold START+SELECT+UP for 1s until
Red LED flashes quickly, which means Controller will enter into
pairing mode.
2．Link Mode: If Controller and Receiver connect successfully,
Red LED will light up. At this moment, you can play games.
3．Standby Mode: If without any operations after 5s, Controller
will enter into standby mode, and LED will turn off. Press any one
of buttons can wake it up.
4．Sleep Mode: If without any operations after 10 mins,
① NES Wireless Receiver:
For NES Classic mini
② USB Wireless Receiver:
For Windows XP/7/8/10, Mac OS,
Linux, Raspberry Pi.
②
①
m
m
m
m
m
m
m
m
Controller will enter into sleep mode. Only START button can
wake it up.
5．Power off: When the batteries in your controller are dead, the
controller will power off automatically.
LED Description:
Controller
State LED
Controller
Red LED
and Receiver
lights up
connect
successfully
In standby or LED turns
sleep mode off
Red LED
In paring
flashes
mode
quickly
Blue LED
In charging
lights up
Blue LED
Fully charged
turns off
Specifications
Model
Compatibility
Charge method
Charge time
Battery
Working time
Wireless transmission
Bluetooth effective
distance
Net weight
NES Wireless Receiver
State LED
Controller and
Red
Receiver connect
lights up
successfully
Standby or Sleep Red
mode flashes
WC2
NES Classic mini, Windows
XP/7/8/10, Mac OS,
Raspberry Pi
Charge by 5V 500mA Charger,
Charge by computer
2.0port .
About 2H
250mAH
100H
2.4GHz wireless connection
≤10m
62g
EN
LED
LED
Linux,
USB
