- Page 1 Operation Manual TDP-0 Series Single Punch Tablet Machine （ As technology continues to update, we retain the right to change technology design. ）...
- Page 2 Catalogue 一、Products introduction ..................2 二、Technical parameter ..................2 三、Structural description ........................ 四、Operation adjustment ..................3 五、Maintenance requirements ................4 六、Precautions .......................4 七、Attached drawing ................... 5...
- Page 3 Products introduction 一、 The lightest tablet press machine,only hand-operate. Mini tablet press machine,only 20KG. Hand-operated. This machine is used for pressing different kinds of granular raw materials into round tablets. It is applicable to trial manufacturing in lab or batch production in small amount different kinds of tablets, sugar pieces, calcium tablets and tablets of abnormal shape.
- Page 4 The main work process is divided into: A.filling, B.stamping, C.out slice.Three procedures for continuous, its each program are adjustable, suitable for forming of various kinds of tablets. Operation adjustment 四、 Installation of punch die Firstly, disassemble the hopper, feeder and the middle die , wipe up the table board die hole and the punch die to be assembled, and assemble them as per the following steps：...
- Page 5 Turn the flywheel by hand to make the discharge cam rise to the highest point along with the connecting rod and the lifting fork. Then loosen the fixing plate and turn the discharging adjustment wheel on the lower punch core, observe whether the mouth level of the bottom punch is aligned with the plain.
- Page 6 七、Attached drawing...
