Summary of Contents for Cairox 010 LCD 2T
- Page 1 Installation manual 010 LCD 2T 010 LCD 4T WALL LCD MB 010 2T MB 010 4T MB 010 E IOM_005_00 IOM_011_00...
-
Page 3: Editorial Pictograms
Symbols The pictograms in the next chapter provide the necessary unmistakable way. information for correct, safe use of the appliance in a rapid, Editorial pictograms User Service Refers to pages containing instructions or information for Refers to pages containing instructions or information for the user. -
Page 4: General Warnings
GENERAL General warnings This instruction is an integral part of the booklet of It is forbidden to modify the safety or adjustment the appliance on which the kit is installed. Please consult devices without authorisation from and indications of the this booklet for general warnings and fundamental safety manufacturer. - Page 5 010 LCD 2T - MB 010 2T - 010 LCD 4T - MB 010 4T Assembly, set-up and connection of on-board control panels 010 LCD 2T, MB 010 2T, 010 LCD 4T, MB 010 4T The controllers have two independent clean contacts...
- Page 6 OFF). a normal fan. CP presence contact input connection (only for 010 LCD 2T and 010 LCD 4T models) On closing the contact connected to the CP input (ref. A) The input cannot be connected in parallel to that of other the panel is placed in stand-by mode.
- Page 7 Air temperature probe assembly (only for models 010 LCD 2T, 010 LCD 4T) To position the temperature probe (ref. A): insert the probe into the lower hole (ref. C) pass the probe through the hole on the shoulder (ref. B) fix the probe on the relevant hook (ref.
- Page 8 010 LCD 2T and 010 LCD 4T connections water temperature probe 10kΩ boiler consent output (free contact max 1A) cold water temperature probe 10kΩ (only for chiller consent output (free contact max 1A) 010 LCD 4T) air temperature probe 10kΩ...
- Page 9 MB 010 2T and MB 010 4T connections serial connection for wall-mounted remote -AB+ not used in this version control WALL LCD (respect AB polarity) H2** hot water temperature probe 10kΩ RS water probe (2kΩ) (MB 010 2T only) H4** cold water temperature probe 10kΩ...
- Page 10 WALL LCD Wall-mounted remote control panel assembly WALL LCD The wall-mounted remote control WALL LCD is an Use the base of the controller (ref. B in diagram) to trace the fixing points on to the wall (use two opposing holes). electronic thermostat (fitted with an optional temperature Then proceed with the following operations: probe which can be remotely installed in one of the fan...
- Page 11 Spring-loaded terminal connections -AB+ and CP Rigid or flexible wires with a 0.2 to 1.5 mm² cross-section easily, whereas with flexible cable it may be easier to can be inserted in the spring-loaded terminal blocks for use a long pointed pair of pliers to insert correctly. the serial connection.
- Page 12 WALL LCD Connections Connect the RS485 line of the wall-mounted remote control The RS485 cable connection is polarised, respect the to one or more (up ot a maximum of 30) devices fitted with "A" and "B" indications on every periphery connected electronics for remote control MB 010 2T or MB 010 4T (for connecting, it is preferable to use a shielded two- using a suitable two-core cable for serial connections RS485...
-
Page 14: Led Signals
MB 010 E Assembly and fitting of fan control for remote control MB 010 E. When fitted on board the machine it allows for managing the For board MB 010 E control outputs these impedance values motor, with modulated speed; motor regulation can be made must be considered, especially when controlling more than using an analogue 0-10V DC input with 25 kΩ... - Page 15 Connection diagram MB 010 E with 0-10V DC thermostats / signals make the electrical connections to a thermostat fit for use according to the diagram Electrical power supply 230V-50 Hz RS version cabling Appliance piloting input 0÷10 V water probe for RS 2 kΩ water solenoid valve (230V/ 50Hz 1A output DC inverter fan motor voltage)
