Fuel Tank Adapter
Operating Instructions & Parts Manual
Model Number
Capacity
HW93350
80 Lbs
Made in the USA
SFA Companies ©2006
10939 N. Pomona Ave. Kansas City, MO 64153
816-891-6390
customerservices@heinwerner-automotive.com
-Before using this product, read this manual and follow all its Safety Rules and Operating Instructions
HW93350-M0
Advertisement
Table of Contents
Summary of Contents for HEIN-WERNER AUTOMOTIVE HW93350
- Page 1 Fuel Tank Adapter Operating Instructions & Parts Manual Model Number Capacity HW93350 80 Lbs Made in the USA SFA Companies ©2006 10939 N. Pomona Ave. Kansas City, MO 64153 816-891-6390 customerservices@heinwerner-automotive.com -Before using this product, read this manual and follow all its Safety Rules and Operating Instructions...
- Page 2 TABLE OF CONTENTS Warranty Save These Instructions Product Description Specifications & Safety Instructions Warnings Assembly & Installation Operation Maintenance Replacement Parts TWO YEARS LIMITED WARRANTY For a period of two (2) years from date of purchase, SFA Companies will repair or replace, at its option, without charge, any of its products which fails due to a defect in material or workmanship under normal usage.
- Page 3 Overall Adapter Overall Adapter Model Weight Size Length Width Height Weight HW93350 80 Pounds 40 gallons 32" 15 3/8" 9 1/4" 49 pounds SAFETY INSTRUCTIONS BEFORE USE 1. Verify that the product and the application are compatible, if in doubt call Hein-Werner Technical Service (888) 332-6419.
- Page 4 WARNING • Study, understand, and follow all instructions provided with and on this device before operating this device. • Do not exceed rated capacity. • Use only on hard, level surfaces capable of sustaining rated capacity loads. • Do not modify this device. •...
- Page 5 9. Ascertain that all nuts and bolts are securely tightened. Note: The integrity of your Transmission Jack should not be affected by these two holes as long as the instructions are followed. 9.5” Figure 2 . Figure 3. Figure 4 . Figure 5. HW93350-M0...
- Page 6 ! DANGER ! • ALWAYS have a Class B fire extinguisher available. • Drain ALL fuel from the vehicle fuel tank into an approved and grounded fuel storage tank. • NEVER drain or store fuel in an open container, near open flames, heat sources, or spark inducing environments.
- Page 7 Contact Hein-Werner @ (888) 332-6419 The fuel tank does not maintain Loose padded support Contact Hein-Werner @ (888) 332-6419 steadiness while on the adapter The adapter is shaky or feels loose Loose nuts and/or bolts Tighten all nuts and bolts HW93350-M0...
- Page 8 4 each Grounding Cable Assembly 247554 2 each Foam Pad/Foot Assembly (1" Hole) 247576 2 each (not shown) Safety Tension Strap 247578 2 each Foam Pad/Foot Assembly (1/2" Hole) 247754 2 each Hardware Kit 247760 1 each (not shown) HW93350-M0...
