TOUCHSCREEN INSTALLATION

Review the two setup options below to determine the
!
best placement for your Touchscreen.
SETUP OPTION 1: Desktop Setup
On the back of the Touchscreen, pull out the two supporting brackets.
1
Place the Touchscreen upright in it's desired location.
2
1
FOR ADDITIONAL HELP, CALL CUSTOMER CARE AT 1-877-602-5276
3
SETUP OPTION 2: Wall Mounting
Determine where you would like to place
1
the Touchscreen.
Remove the protective film from the
2
Mounting Plate.
Apply the Wall Mounting Bracket to the
3
Mounting Plate.
Using the Mounting Bracket as a template,
4
drill holes into where you would like the
Touchscreen to be placed.
If placing on plaster or brick, insert the Wall
!
Anchors before securing the Mounting Bracket
to the wall.
Once the Mounting Bracket has been
5
screwed into the wall, attach the
Touchscreen to the Mounting Bracket.
2
Hold the Touchscreen and gently push it
6
downwards to lock it in place.
2
3
4
5
6
4
