Summary of Contents for Dover HYDRO AquaBlend Xtreme
- Page 1 user manual AquaBlend Xtreme...
-
Page 3: Table Of Contents
index 1.OO overview page 1.01 Package Contents 1.02 General Description 1.03 Specifications 1.04 Safety Precautions & Warranty Compliance 1.05 General Tips 2.OO installation and operation 2.01 Installation & Start-up 2.02 Suggested Installation 2.03 Operation 3.OO maintenance 3.01 General Maintenance Tips & Schedule 3.02 Routine Maintenance Instructions 4.OO troubleshooting... -
Page 4: Package Contents
1.OO overview Safety Precautions WARNING! Please read precautions thoroughly before operation. Meet all applicable local codes and regulations. THANK YOU FOR YOUR INTEREST IN OUR PRODUCTS Please use this equipment carefully and observe all warnings and cautions. protective clothing and eyewear when dispensing chemicals or other materials or when working in the WEAR vicinity of all chemicals, filling or emptying equipment, or changing metering tips. -
Page 5: General Description
1.OO overview (continued) 1.O2 General Description The AquaBlend Xtreme models are designed to inject liquid concentrate or soluble powder that recommended and approved for injection into fluid systems. AquaBlend Xtreme has specifically been designed to handle various water treatment chemicals and organic acids. -
Page 6: Safety Precautions & Warranty Compliance
1.OO overview (continued) 1.O4 Safety Precautions & Warranty Compliance WARNING! Please read precautions thoroughly before operation. Must meet all applicable local codes and regulations. Remove Red Caps Prior to Installation Avoid a Potentially Hazardous Chemical Accident Select a safe location. Chemical container should be kept Your injector is 100% factory tested before delivery and away from children and/or high usage areas and the location may contain a small amount of water. -
Page 7: Installation & Start-Up
2.OO installation & operation 2.O1 Installation & Start-up Fluid Filter (Required) Additional Siphoning Prevention Install a filter of 140 mesh (104 micron) or finer depending Place solution container on a level below the injector suction on your fluid quality to prolong the working life of the tube fitting. - Page 8 2.OO installation & operation (continued) 2.O3 Operation Clicking Sound is Normal Bleed Port Fluid flowing through the injector will automatically cause Ensure all air is out of the unit by pressing the bleeder the injector to “click” and inject a set amount of solution button, on the lid, in until water comes out.
-
Page 9: Oo Maintenance
3.OO maintenance 3.O1 General Maintenance Tips & Schedule Rinse Injector After Each Use Perform these maintenance Additive allowed to remain in injector can dry, foul or damage procedures to extend the life of your unit. the lower end at the next start-up. Place suction tube into a 1 qt. -
Page 10: Routine Maintenance Instructions
3.OO maintenance (continued) 3.O2 Routine Maintenance Instructions ↓ Step 1. Step 2. Step 3. Unscrew and remove Pull down on shaft, rotate shaft Remove shaft with gasket and lower end from assembly. 90° and remove. install new. If damage on sealing surface of shaft, replace shaft. -
Page 11: Oo Troubleshooting
4.OO troubleshooting 4.O1 New Install Troubleshooting Problem Cause Solution • Are the red plugs at the inlet, outlet and suction tube fitting openings removed? • Is the unit installed backward? The arrow on the unit must a. Fluid not flowing through unit point in the direction of the fluid flow. -
Page 12: Oo Injector Repair Parts
5.OO injector repair parts 5.O1 Body and Piston Exploded Parts Diagram Service Parts List Part No. Description HYD011732 Kit M - Mounting bracket kit HYD017200XT Kit H - Motor piston replacement HYD102601NPT Body, NPT, PVDF, AquaBlend Xtreme HYD102601BSP Body, BSP, PVDF, AquaBlend Xtreme... -
Page 13: Lower End Parts 0.2% - 2
5.OO injector repair parts (continued) 5.O2 lower end parts O.2% - 2% exploded parts diagram Service Parts List Part No. Description HYD017210XT Kit A: Dosage gasket kit HYD017211XT Kit B: Wear kit HYD017213XT Kit D: Check valve kit HYD017214XT Kit E: Wear parts maintenance kit HYD017216XT Kit G: Complete lower end kit... -
Page 14: Lower End Parts 0.78% - 5
5.OO injector repair parts (continued) 5.O3 lower end parts O.78% - 5% exploded parts diagram Service Parts List Part No. Description HYD017220XT Kit A: Dosage gasket kit HYD017221XT Kit B: Wear kit HYD017223XT Kit D: Check valve kit HYD017224XT Kit E: Wear parts maintenance kit HYD17226XT Kit G: Complete lower end kit... -
Page 15: Limited Warranty
6.OO warranty Congratulations on Your Purchase! This warranty is not valid if the defects are found to be due to the We make the best and most reliable fluid-driven injectors available. product’s misuse, lack of maintenance, fluid impurities such as Hydro Systems will provide for replacement of all parts proven to sand or iron, defective installation, freezing, fluid hammer, abuse, be defective in material or workmanship from the date of purchase...
