Summary of Contents for Rocelco BSTC
- Page 2 Table of Contents Table of Contents and Warnings 2/10 Part List 3/10 Assembly and Installation 4/10 1.2 Installing the Casters and Poles 4/10 2. Adjusting the Pole Height 5/10 3. Installing the Media Shelf 6/10 4. Installing the TV Mount 7/10 5.
- Page 3 M8X15mm M8X60mm M8X25mm M8X25mm M6X25mm M5X25mm...
- Page 4 1.1 Install casters to base Step1 Step2 Step3 Turn over base Turn base upright 1.2 Install poles to base Step4 Step5 Step6a Use your finger to depress the right upper pole spring plunger ball located in the cable window. Carefully pull the upper pole upward until your desired height is reached Twist upper pole toward the plunger holes, and engage the spring ball into the plunger hole to set in place...
- Page 5 2. Adjust the height of the telescopic mounting poles Right upper poles Step5 Step5 Left upper poles Lower poles Spring plunger Figure 1 Figure 1...
- Page 6 3. Install the media shelf...
- Page 7 4. Install the TV mount...
- Page 8 5. Select your VESA pattern and attach TV brackets Note: (I ,J)+K,L To avoid damage, a spacer must be used when the mounting hole is minimal. Spacer Suggestions...
- Page 9 6. Mounting TV -Assistance Required! Assistance Required Security screw...
- Page 10 7. Cable Management Note: Use caution when routing cables to avoid damage.
