Gomax MA-5288V2 User Manual

8x8 hdbaset lite matrix with poc
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
M
A
-
5
2
8
8
V
2
M
A
-
5
2
8
8
V
2
8X8 HDBaseT Lite Matrix with PoC
User Manual
rev: 140530
Made in Taiwan

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MA-5288V2 and is the answer not in the manual?

Questions and answers

Related Manuals for Gomax MA-5288V2

Summary of Contents for Gomax MA-5288V2

  • Page 1 8X8 HDBaseT Lite Matrix with PoC User Manual rev: 140530 Made in Taiwan...
  • Page 2 fety Noti The MA-52 288V2 HDBaseT Lite matrix x with PoC has been tested for conformanc ce to safety regulations s and requ uirements, a and has b been certifie ed for inte ernational u use. Howev ver, like al electronic e equipments s, the MA-52...

  • Page 3: Ackage Contents

    Furthermore, the built-in IR extension function makes users at display site access the DVD player, PS3 or any HDMI supported devices directly! In addition, MA-5288V2 also supports PoC (Power over Cable) which can power both units from TX with power supply.

  • Page 4: Specifications

    SPECIFICATIONS Model Name MA-5288V2 Technical MA-5288V2 MA-5288V2-RX True 8x8 matrix switcher Role of usage Receiver [RX] Transmitter [TX] HDMI Deep Color & full 3D HDMI compliance HDCP compliance Video bandwidth Single-link 340MHz [10.2Gbps] Video support 480i / 480p / 720p / 1080i / 1080p60 Audio support Surround sound (up to 7.1ch) or stereo digital audio...

  • Page 5: Panel Descriptions

    PANEL DESCRIPTIONS Transmitting unit ► MA-5288V2 Front Panel Source Status: Input source indicator LED IR SENSOR: IR sensor for receiving the IR commands from IR remote Output Push Button & 7-segment LED: Front panel push buttons used to select the number of display channel &...

  • Page 6: Receiving Unit

    ► Receiving unit MA-5288V2-RX Rear Panel Front Panel RJ-45: Plug in a Cat.X cable LED: Power indicator IR Blaster: Infrared 3.5mm socket for plugging in the extension cable of IR blaster IR Receiver: Infrared 3.5mm socket for plugging in the extension cable of IR receiver...

  • Page 7: Ir Pass-Through

    IR BLASTER: IR control on individual display device IR RECEIVER: IR receiver connected here can receive all IR command signals from the IR remote controls of MA-5288V2 and all other HDMI source devices. CAUTION! Incorrect placement of IR Blaster and Receiver may result in the failure of the IR extenders. Please check carefully before plugging in the IR extender to the respective IR sockets.

  • Page 8: Operation Approach

    OPERATION APPROACH Method A: Push-in Button preset save learn default 1. IN/OUT MAP 1) Use the “+”or “-“ output push button to select the number of display 2) Use the “+”or “-“ input push button to select the number of input source “+”: change selected input/output port in ascending order “-”...
  • Page 9 4. Default EDID Mode 1) Push “input+(default)”button to select the input channel which you want to learn default EDID and then keep pushing “input+(default)”button when you select your desired input channel 2) Push the “+”or “-” output push button and then the LED will show “E”“d” one time to enter Learn Default EDID Mode 3) Use “+”or “-”...
  • Page 10 Method B: IR Remote Control 1. IN/OUT Switch Operation Procedure 7-Segment LED IN/OUT Switch Output Number (1~8) + Input Number (1~8) 1. Press output number key “3” to select Output 3 Ex: Input 2 To Output 3 2. Press input number key “2” to select Input 2 2.
  • Page 11 Operation Procedure 7-Segment LED Output Status Status + Output Number (1~8) + Take 1.Press “STATUS” button Ex: Output 4 2.Press output number key “4” to select Output 4 (Input 2) 3.Press “TAKE” button Save Current Mapping Save + Output Number (1-8 storage site) + Take 1.Press “SAVE”...
  • Page 12 Method D: Software Control through RS-232 port I/O Routing Button COM Port Selection Setting Button Connection Status EDID Button Connect/Disconnect Button Network Button Control SW via RS-232 System Button Control SW via Network 1. I/O Routing Button 1) I/O: a) Select the input b) Click “Send”...
  • Page 13 2) Save Mapping: a) Select Mapping(1-8) b) Click “Save” button to save current mapping 3) Preset Mapping: a) Select Mapping(1-8) a) Click “Recall” button to recall previous mapping which are saved 2. Rename I/O Button 1) Rename I/O: a) Rename output name b) Rename input name 2) Rename Mapping: a) Rename Mapping name...
  • Page 14 3. EDID Button 1) Learn EDID from Default a) Select Default EDID(1-8 Default EDID) b) Select Input c) Click “Send” button to learn default EDID 2) Learn EDID From Display a) Select output b) Select Input c) Click “Send” button to learn display EDID 3) Load EDID File to Input a) Select Input b) Click “Load”...
  • Page 15 5) Create EDID a) Click “Create” button to create EDID file b) Select the EDID content c) Click “Save EDID on Computer” to save the generated EDID as a file...
  • Page 16 4. Network Button a) Save Setting => Save the IP address which you key in on the column b) Read Setting: => Read the IP address from the device PS: The default IP address is 192.168.1.111...
  • Page 17 5. System Button 1) Version: => To get the F/W version information 2) Factory Reset 3) Help => To view the steps of the firmware update 4) Firmware Update Main Board 5) Firmware Update Web IC 6) Firmware Update DB Board 7) Firmware Update Valens 8) Firmware Update Front Panel 6.
  • Page 18 7. Connection Status 1) Connected Status: 2) Connecting Status: 3) Disconnected Status: 8. Connect/Disconnect Button Click this button “ ” to change connection status 9. RS-232 Button 1) Click “ ” button to switch to RS-232 function. 2) If RS-232 is connected, the button will show the sign image to let you know. 10.
  • Page 19 Method E: Web Interface Control The default IP address: 192.168.1.111 Account: admin Password: matrix I/O Routing Button Setting Button EDID Button 1. I/O Routing Button 1) I/O: a) Select the input b) Click “Send” to change the I/O setting 2) Save Mapping: a) Select Mapping(1-8) b) Click “Save”...
  • Page 20 2. etting Button 1) Rename I/O: a) Rename output name b) Rename input name 2) Rename Mapping: a) Rename Mapping name 3) Password change: (the password has to be 6 characters) a) Key in “old password” b) Key in “new password” c) Key in “new password”...

  • Page 21: Edid Learning

    EDID LEARNING The EDID learning function is only necessary whenever you encounter any display on the HDMI output port that cannot play audio and video properly. Because the HDMI source devices and displays may have various level of capability in playing audio and video, the general principle is that the source device will output the lowest standards in audio format and video resolutions to be commonly acceptable among all HDMI displays.
  • Page 22 The quality of output video is not good enough, how can I do? Please adjust the 8-level equalization on the receiver units. The HDMI signal level varies from 0 (strongest) to 7 (weakest) for respective transmission length from longest possible range to short distance.
  • Page 23 NOTICE 1. If the DVI or HDMI device requires the EDID information, please use EDID Reader/Writer to retrieve and provide DVI/HDMI EDID information. 2. All HDMI over CAT5 transmission distances are measured using Belden 1583A CAT5e 125MHz LAN cable and ASTRODESIGN Video Signal Generator VG-859C & VG-870B. 3.

  • Page 24: Warranty

    SELLER will NOT be liable for direct, indirect, incidental, special, or consequential damages resulting from any defect or omission in this manual, even if advised of the possibility of such damages. Also, the technical information contained herein regarding the MA-5288V2 features and specifications is subject to change without further notice.
