Summary of Contents for Auxdio AM8328
- Page 1 Multi-Room Music System AM8328 Multi-Room Music System User Manual Multi-Room Music System Host AM8328 Welcome to use the Multi-Room Music System. To make the better use of this equipment, please read this instruction carefully prior to use. http://www.auxdio.com.cn http://www.dsppatech.com...
-
Page 2: Table Of Contents
Multi-Room Music System Contents 1. About Multi-Room Music System ....................... 2 2. Functional Characteristics of System Host ....................2 DESCRIPTION OF APPEARANCE AND FUNCTION OF HOST ........4 1. Description of Function of Front Panel ...................... 4 DESCRIPTION OF CONNECTION ..................... 5 1. - Page 3 Multi-Room Music System 2.11 Other Settings ............................17 2.12 System Upgrade ............................17 3. Zone Control: Control of eight zone ......................18 3.1 Sound Source Selection..........................18 3.2 Playing of USB/SD Music ..........................19 3.3 Playing of other sound sources ........................20 CONTROL OF EQUIPMENT WITH BM828R PANEL ............
-
Page 4: About Multi-Room Music System
Multi-Room Music System 1. About Multi-Room Music System AM8328 system is a set of perfect modernized Multi-Room Music System. In addition to all the functions the traditional household audio should have, this set of system has two special function: ① Listening different music programs in different rooms. For example: There is the difference in the music loved by the elderly and young people. - Page 5 Multi-Room Music System drive to the host for playing. Support the network radio function, so you’v no need to worry about the poor antenna signal. Line Out,set to follow the designated zone (any one of the eight zone). ...
-
Page 6: Description Of Appearance And Function Of Host
Multi-Room Music System Description of Appearance and Function of Host 1. Description of Function of Front Panel 1) USB interface (USB2.0) It is used to connect external USB device, such as USB flash disk, mobile HDD, or card reader. 2) Power light (POWER) When turning on the power, this indicator light will be in the normally green on state;... - Page 7 Multi-Room Music System 2. Description of Functions of Rear Panel DVD audio input interface RS232 interface Auxiliary audio input interface Also known as remote control interface. To To connect the other sound source equipments control the function of the equipment through conforming to the interface level standard.
-
Page 9: Description Of Connection
Multi-Room Music System Description of Connection 1. Schematic Diagram of Line Audio Input & Output Connection Other sound sources Extending power DVD machine amplifier Remark: The above inputs and outputs shall be connected with the lotus form plug as shown in the right-handed figure. -
Page 10: Schematic Diagram Of Connection Of Router And Extending Power Amplifier
Multi-Room Music System 2. Schematic Diagram of Connection of Router and Extending Power Amplifier 1) Connection of router 2) Connection of Extending Power Amplifier AM8300 Remark: The above connection shall be made with T586A network cable; if it is required to extend the connection line, please make it by the method as shown in the figure below: First pin RJ45 interface... -
Page 11: Schematic Diagram Of Connection Of Infrared Study / Control And Rs232 Central Control
Multi-Room Music System 3. Schematic Diagram of Connection of Infrared study / Control and RS232 Central Control 1) Connection of infrared study / control Note: The infrared receiver and emitter shall not be connected to the wrong sockets; or they will not work! 2) Connection of RS232 central control Smart central control system or smart household... -
Page 12: Schematic Diagram Of Connection Of Panel Control
Multi-Room Music System 4. Schematic Diagram of Connection of Panel Control Remark: For connection of input in two channels, either channel shall be connected by “hand-in-hand” mode Infrared remote controller The line remote controller in any room is controlled by the infrared remote controller... -
Page 13: Schematic Diagram Of Connection Of Zone Output
Multi-Room Music System 5. Schematic Diagram of Connection of Zone Output Zone 1~8 adopt the stereo dual-track output. In zone 1, the output power of every track is 100W; in other zone, the output power of every track is 30W. The connection of zone 1 is exemplified below. The connection mode of the other zone is completely the same as that of the zone 1. -
Page 14: Operation Instruction To Host
Multi-Room Music System Operation Instruction to Host 1. Description of Power-On State and Main Interface After connecting the system line properly, switch on the power of this equipment, turn on the power switch on the front panel of the host (Refer to the description of the front panel), and the system enters the power-on state, which will cost approximately 30 seconds. -
Page 15: Detailed Description Of System Setting
Multi-Room Music System 2. Detailed Description of System Setting. 2.1 Setting of time and date ① Touch “system setting icon” to enter the following interface; ② Touch “time” to enter the time setting interface; ③ Touch the place as shown in the figure; “ON” indicates that the automatic timing function is started;... -
Page 16: Selection Of Language
Multi-Room Music System ⑤ Touch “Time and date setting” to enter the time and date setting interface, so as to modify the time and date. 2.2 Selection of language Touch “language” to enter the language selection interface, so as to switch the language of host between Chinese and English. -
Page 17: Timing Setting
Multi-Room Music System 2.4 Timing setting ① Touch “timing” to enter the timing setting interface; Touch here to add timing point ② Touch the place as shown in the figure above to enter the timing edition interface. Zone selection “ON” indicates that the zone is opened at timing point;... -
Page 18: Network Module Setting
Multi-Room Music System When entering the infrared study operation interface for the first time, it can be seen that the function buttons of learning displays the dark gray. Finishing the leaning, such functional buttons will display the bright green. For example, if you want to learn the “play” function of DVD, first touch the DVD play button as shown on the above figure, the countdown at the bottom will be started;... -
Page 19: Line Output
Multi-Room Music System 2.7 Line Output Touch “line output” to enter the line output interface. Touch the zone to be followed optional line output 2.8 Network Detection Touch the “network detection” to enter the network detection interface. In case of the normal network connection, the IP address allocated will be displayed at the bottom of the screen. -
Page 20: Sd/Usb Program Source Edition
Multi-Room Music System 2.9 SD/USB Program Source Edition Touch “SD/USB program source edition” to enter the song list updating interface, to switch and change the song list. You can copy and delete the song in the list as shown in the figure below. 2.10 Network Radio Edition Touch the “network radio edition”... -
Page 21: Other Settings
Multi-Room Music System 2.11 Other Settings Touch “other settings” to enter the other settings interface, to adjust backlight intensity and modify the terminal address setting. Open the panel behind the button to select the zone to be controlled 2.12 System Upgrade Touch the “system upgrade”... -
Page 22: Zone Control: Control Of Eight Zone
Multi-Room Music System 3. Zone Control: Control of eight zone The living room is taken as the example for the following operations. The operations for the other zone are completely the same as those for the living room. After entering the main menu, click the living room to enter the picture as shown in the figure below: Zone switch Song/radio list... -
Page 23: Playing Of Usb/Sd Music
Multi-Room Music System 3.2 Playing of USB/SD Music ① Touch sound source selection button to enter the sound source selection interface and select “USB/SD” as the sound source; ② Touch to call out the play list as shown in the figure below (SD backlight indicates that the folder stored under SD is being read) ③... -
Page 24: Playing Of Other Sound Sources
Multi-Room Music System 3.3 Playing of other sound sources The operation mode for playing of other sound sources is roughly the same. The playing of the network sound source is taken as the example below. ① Touch the sound source selection button to enter the sound source selection interface and select “NET1”... -
Page 25: Control Of Equipment With Bm828R Panel
Multi-Room Music System Control of Equipment with BM828R Panel Please search P8 “Schematic Diagram of Connection of Panel Control” for connection of the panel in details Control the host with the panel ① Set the zone to be controlled by the panel Turn on this switch to switch on the panel the zone to be controlled by this switch;... -
Page 26: Example Of Apple Ios System Operation
Multi-Room Music System 1. Example of Apple IOS System Operation ① Select the zone you want to control in the “Room” interface. It is allowed to select single or more zone as shown in the figure below The tick in front of it indicates that this zone is selected Touch here to open or close the zone... -
Page 27: Example Of Android System Operation
Multi-Room Music System ③ Detailed description of system setting Only the zone selected will appear in the directory of the “room”; in addition, it is Enter this option to edit the names of the zone possible to modify the name of the zone in this interface Add network radio 2. - Page 28 Multi-Room Music System ② Touch the “control” button to control the selected zone. Note: If the zone is not selected, it is impossible to enter the control interface. Touch here to select sound source, as shown in right-handed figure Select play mode, Mute button e.g.
- Page 29 Multi-Room Music System Replace power supply fuse When fuse is broken, please replace it with the same size fuse. (Please find the fuse specification under power plug) The fuse position is shown as below: Remove Install ④ ③ ② ① Fuse replacement steps: 1．...
-
Page 30: Precautions
Never place any corrosive on or near the console. 3. After-sales Service Precautions Auxdio will provide a three-year charge-free warranty (including replacement of parts) from the date when you purchase provided that the product is installed and operated as specified. ... - Page 31 Please store the manual and warrant card well. For problems or precautions not referred in this manual, please contact our distributor or visit our site at http://www.auxdio.com.cn. Please contact our technician (or distributor) in case of failure within the warranty period. We will take no responsibility in case that the product is disassembled or repair by unauthorized personnel.
-
Page 32: Packing List
Multi-Room Music System Packing list Product Quantity AM8328 Host 1 set Red and white RCA signal line 1 piece Power line 1 piece Operation instruction 1 copy Quality certificate and warranty card 1 copy USB flash disk 1 piece Infrared Data Transceivers... -
Page 33: Performance Specification
Multi-Room Music System Performance Specification Item Indicator Quantity of zone Eight zone Line input sensitivity 520mV (± 50mV) >10kΩ Line input resistance Zone 1, 2×100W/8Ω Rated output power Zone 2-8, 2×30W/8Ω Audio indicator Frequency response 20Hz-20kHz (± 0.5dB) Total harmonic distortion <0.3% (f=1kHz, 1/3 of rated output power) Signal-noise ratio >... -
Page 34: Multi-Music" Of Qr Code
Multi-Room Music System “Multi-Music” of QR Code “Multi-Music” of QR Code for Apple “Multi-Music” of QR Code for Android... - Page 35 http://www.dsppatech.com...
