Carton Contents
Carefully remove and lay out all parts from the carton so as not to scratch or lose any parts or
pieces. The shipping carton should contain the pictured items on the parts pages (Pages 9-11)
Remove all packaging material and discard.
The carton will contain:
2- part boxes
2- rear wheels
1- contoured Snappy seat
Revised Date: 4/30/09
Amtryke® Model Snappy
#50-0150
1- front wheel & frame assembly
1- rear deck assembly
1- seat post tube
Page 1 of 10
Advertisement
Summary of Contents for AmTryke Snappy 50-0150
- Page 1 Amtryke® Model Snappy #50-0150 Carton Contents Carefully remove and lay out all parts from the carton so as not to scratch or lose any parts or pieces. The shipping carton should contain the pictured items on the parts pages (Pages 9-11) Remove all packaging material and discard.
- Page 2 Assembly Instructions 1. Main frame assembly. Slide the seat post tube onto the front wheel & frame assembly. Be sure to keep the two (2) seat post knob holes on the bottom right side of the tryke. Install the two (2) seat post knobs into their holes.
- Page 3 4. Install Rear Wheels. Slide rear wheel onto axle. Install washer and nut. Tighten securely, but be careful not to over tighten. Note: Air inflation valve faces the inside of the tryke. Install white plastic nut caps over axel nuts once wheels are installed on frame.
- Page 4 5. Install Loading lock. Slide loading lock on the loading lock rod on the rear frame assembly. Top of loading lock should be flush with the top of tube. Take care that the lever is not touching the tire. The handle is in line with the tire and points towards the front of the tryke.
- Page 5 b. Handle bar set shown here with stem installed forward to fit larger riders. 7. Install Snappy Seat. Seat installs using four (4) screws with washers. Line up holes on bottom of seat with holes in seat post frame. Install all four (4) screws before tightening to assure good alignment.
- Page 6 Seat Back Adjustment. Once the seat is installed you can position the seat back by loosening the adjustment screws located on the bottom of the seat. The seat back slides along the chrome tubes underneath the seat. When positioned correctly for the rider, tighten the levers securely.
- Page 7 until you are certain threads are installed properly. See Figure 16. EASY TIP: Pedal threads tighten towards front of bike no matter which side you are on! Use 15mm wrench to tighten. 10. Install Pedal Leveler String. The pedal leveler string threads through tubes on the bottom rear of each pedal.
- Page 8 12. Accessories. There are many optional accessories for the Snappy AmTryke®. Here is a sample listing of some ideas for use with this model. a. Small or Medium laterals. Use these for additional trunk support. Small (#30-1501) or Medium (#30- 1502) b.
- Page 9 Snappy foot plates. Register your AmTryke! It is very important that you please take a moment to fill out and submit the enclosed AmTryke registration form. This will help AmTryke, LLC keep track of what model of tryke you have...
- Page 10 Parts for the AmTryke® Model Snappy #50-0150 Revised Date: 4/30/09 Page 10 of 10...
