Summary of Contents for Axler GSU-1
- Page 1 GSU-1 UNIVERSAL GIMBAL SUPPORT...
- Page 2 T H A NK Y O U F O R C H O O S IN G A X L E R The Axler GSU-1 is a dual-handle system designed to work with most single-handle gimbals providing increased stabilization. It distributes the weight...
- Page 3 O V E R V I E W 1. Grip handles (×2) 2. Handle locks (×2) 3. 1/4-20 sockets (×2) 4. Clamp 5. Crossbar 6. Shoulder-strap hooks 7. Clamp locks (×2) 8. Telescoping brace extension 9. Brace extension socket 10. Twist lock 11.
- Page 4 AT TA C HIN G T HE H A ND L E S Loosen the grip's locking knob, slide the handle onto the crossbar, and lock it in position. You can pull the knob outward for ratchet capability. (Fig. 1) Fig.
- Page 5 Fig. 7 Fig. 6 A C C E S S O R Y AT TA C HME N T The GSU-1 offers two 1/4-20 threaded sockets in the front and a 25 mm diameter crossbar. Use these to attach Axler articulating arms or 25 mm clamps and connect accessories like a video monitor onto your rig.
- Page 6 U S IN G T HE GIMB A L S UP P O R T The Universal Gimbal Support offers a variety of configurations to support the weight of your rig and help you capture the best image. With the shoulder harness, body brace, and adjustable handles, you can distribute the weight across your body and use the support to shoot action or static shots at any angle.
- Page 7 Vertical Follow Action Horizontal Grip Reversed Handle Inverted Gimbal Position w/o Harness...
- Page 8 ONE-YEAR LIMITED WARRANTY This Axler product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement,...
