PASCO EM-8655 Assembly Instruction

Assembly Instruction
Sheet for the PASCO
Model EM-8655
100,000 µ F, 10 V Capacitor
Introduction
The EM-8655 Capacitor is used as an auxiliary
accessory with the CASTLE Kit (EM-8624A)
to demonstrate lengthening the time scale of
transient bulb lighting.
Before assigning this large capacitor to your
students the two screws need to be installed in
the capacitor as illustrated. It is recommended
to use a slotted screwdriver to tighten the
screws as opposed to leaving them finger tight.
012-05017B
$1.00
Screw (2X)
10-32UNCx3/4"
