Section 1: Purpose and Applicability The purpose of this document is to detail the installation and operation instructions for the GMT 125 -15/15 Fuse Panel. 1.1 Product Model This document applies to the following models of the Comm/net Systems, Inc GMT 125 - 15/15 Fuse Panel: TAbLE 1. - Page 8 THIS PAGE INTENTIONALLY LEFT BLANK GMT 125 - 15/15 FUSE PANEL SETUP AND OPERATION MANUAL PAGE 2 - PURPOSE AND APPLIcABILITy...
-
Page 9: Section 3: Unpacking And Inspection
Section 3: Unpacking and Inspection The Comm/net Systems GMT 125 - 15/15 Series Fuse Panel was carefully packaged at the factory to withstand the normal rigors of shipping. However, you should carefully inspect the box and contents to confirm that no damage has occurred in transit. Most shipping carriers require notification of shipping damage within twenty-four hours of delivery, and it is the responsibility of the recipient to inspect the shipment immediately upon receipt. -
Page 10: Mounting
4.2 Mounting NOTICE THIS PRODUCT MUST bE INSTALLED WITHIN A RESTRICTED ACCESS LOCATION WHERE ACCESS IS THROUGH THE USE OF A TOOL, LOCK AND KEY, OR OTHER MEANS OF SECURITY, AND IS CONTROLLED bY THE AUTHORITY RESPONSIbLE FOR THE LOCATION. THIS PRODUCT MUST bE INSTALLED AND MAINTAINED ONLY bY QUALIFIED TECHNICIANS. -
Page 11: Input Connections
4.4 Input Connections WARNING y INPUTS MUST bE PROTECTED bY A LISTED CIRCUIT bREAKER OR bRANCH RATED FUSE. THE CIRCUIT bREAKER OR FUSE MUST bE RATED 125A MAX. y MULTIPLE POWER SOURCES ARE PRESENT, ENSURE ALL INPUT POWER FEEDS ARE NOT ENERGIZED bEFORE INSTALLING THEM. -
Page 12: Output Connections
4.5 Output Connections CAUTION y DO NOT PERFORM THIS STEP ON CIRCUITS WITH FUSES INSTALLED. y ENSURE NO POWER IS PRESENT ON THE CIRCUIT bEING WIRED bEFORE PROCEEDING. y MAKE SURE THAT ALL CAbLES HAVE INSULATED TERMINALS OR HEAT SHRINK APPLIED PRIOR TO TERMINATION, AND THAT NO-OXIDE COMPOUND IS APPLIED TO ALL COPPER-TO-COPPER CONNECTIONS. -
Page 13: Connectorized Output Versions
4.5.2 Connectorized Output Versions There are 30 positive latching DC connector positions for the output circuits found on the GMT 125 -15/15 (15 per side). Cable whips are available in a variety of lengths and wire gauges (refer to Appendix E on Page 17 for more information). Step 1. -
Page 14: Installing The Network Cable
4.8 Installing the Network Cable (016-2102-10 and 016- 2106-10 Models Only) An ethernet module is available on models with per-channel current monitoring. If remote monitoring over the network is required, complete the following steps to connect the Ethernet module with embedded web server. OTEE: For initial configuration, it is recommended to use a crossover Cat 5/5e/6 UTP cable to connect a laptop directly to the Ethernet port of the GMT panel. -
Page 15: Section 5: Operation
Section 5: Operation 5.1 Meter Module The GMT 125 - 15/15 fuse panel is available with an LCD meter module that displays bus current, total bus load, and an exclamation mark indication when a major alarm occurs. Screen contrast can be adjusted from 0-100 (increments of 5). 5.2 Review System Status via the Embedded Web Server This section applies to the GMT 125 - 15/15 products with the optional embedded... -
Page 16: Real-Time Status
5.2.2 Real-time Status Upon loading the GMT 125 - 15/15 web server, the real-time status will be displayed. Site Information User can configure these settings under Administration --> Site Settings. y Site name y Site location bus Detail y Voltage y Feeder fuse size y Load y Alarm threshold %... - Page 17 Site Settings Configure Site Settings y Site name y Site location Panel Settings Configure Panel Settings y Global alarm threshold % y 40-100 y Voltage Calibration Offset y Offset can be applied in increments of +/- 3.0V to raise or lower the displayed A/B bus voltages.
-
Page 18: Section 6: Product Specifications
Section 6: Product Specifications 6.1 Electrical Specifications NOTICE USE bUSSMANN GMT TYPE FUSES ONLY. FUSES MUST CARRY A 450A INTERRUPT RATING. TAbLE 6. GMT 125 - 15/15 MODEL SPECIFICATIONS ALL MODELS Type of Input Dual Input (A/B) Circuits Input Voltage (+/- 0%) -42 to -60V DC Input Current 125A Max... -
Page 19: Appendix A: Mechanical Drawings
Appendix A: Mechanical Drawings GMT 125 - 15/15 FUSE PANEL GMT 125 - 15/15 FUSE PANEL SETUP AND OPERATION MANUAL SETUP AND OPERATION MANUAL PRODUcT SPEcIFIcATIONS - PAGE 13 PAGE 13... - Page 20 GMT 125 - 15/15 FUSE PANEL GMT 125 - 15/15 FUSE PANEL SETUP AND OPERATION MANUAL SETUP AND OPERATION MANUAL PAGE 14 - PRODUcT SPEcIFIcATIONS PAGE 14...
- Page 21 GMT 125 - 15/15 FUSE PANEL GMT 125 - 15/15 FUSE PANEL SETUP AND OPERATION MANUAL SETUP AND OPERATION MANUAL PRODUcT SPEcIFIcATIONS - PAGE 15 PAGE 15...
-
Page 22: Appendix B: Accessories
Appendix b: Accessories TAbLE 7. PANEL ACCESSORIES PART NUMBER DESCRIPTION 750-278-10 Rear Rack Mounting Kit; GMT 125 GMT 125 rear rack mounting kit Appendix C: Supported Lugs for Termination TAbLE 8. INPUT CONNECTIONS WIRE GAUGE SUPPORTED COMM/NET PART MANUFACTURER MANUFACTURE PART CRIMP DIE REQUIRED NUMBER NUMBER... -
Page 23: Appendix E: Output Connections
Appendix E: Output Connections E.1 Output Connector Cable Whips (For Connectorized Models Only) Note: All cable assemblies are unterminated unless otherwise specified. For more connectorized output harness lengths and color combinations, please contact Comm/net Systems sales. TAbLE 11. OUTPUT CONNECTOR CAbLE WHIPS (RTN) LENGTH COLOR... - Page 24 NOTES: GMT 125 - 15/15 FUSE PANEL SETUP AND OPERATION MANUAL PAGE 18...
- Page 25 THIS PAGE INTENTIONALLY LEFT BLANK...
