5-Ton Horizontal Electric Log Splitter
Owner's Manual
WARNING:
Read carefully and understand all ASSEMBLY AND OPERATION
INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety
precautions may result in serious personal injury.
Item #66717
READ & SAVE THESE INSTRUCTIONS
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Ironton 66717
- Page 1 5-Ton Horizontal Electric Log Splitter Owner’s Manual WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item #66717 READ & SAVE THESE INSTRUCTIONS...
- Page 2 ® Thank you very much for choosing an Ironton product! For future reference, please complete the owner’s record below: Serial Number/Lot Date Code: ________________________________ Purchase Date: ____________________________________________ Save the receipt, warranty, and this manual. It is important that you read the entire manual to become familiar with this product before you begin using it.
-
Page 3: Table Of Contents
Table of Contents Intended Use ............................4 Packaging Contents ..........................4 Technical Specifications ........................4 Important Safety Information ....................... 4 Specific Operation Warnings ....................... 6 Main Parts of Log Splitter ........................8 Before Each Use ............................ 9 Operating Instructions ........................10 After Each Use ............................. -
Page 4: Intended Use
Intended Use The Ironton 5-Ton Horizontal Electric Log Splitter was designed for home use. It’s built to operate best at temperatures between 41º F and 104º F. The surrounding humidity should less than 50% at 104℉ .It should be stored or transported at temperatures between -13º F and 131º F. - Page 5 ⚠WARNING WORK AREA SAFETY • Inspect the work area before each use. Keep work area clean, dry, free of clutter, and well-lit. Cluttered, wet, or dark work areas can result in injury. Using the product in confined work areas may put you dangerously close to cutting tools and rotating parts. •...
-
Page 6: Specific Operation Warnings
before using. • Disconnect the power/air supply from the product and place the switch in the locked or off position before making any adjustments, changing accessories, or storing the tool. Such preventive safety measures reduce the risk of starting the tool accidentally. •... - Page 7 Safety and Product Labels Reference Description Quantity General Warning Decal Pinch Point Warning Decal Air Bleed Warning Decal Electric Shock Hazard Spec Decal Operation Instructions Decal Ironton Decal Page 7 of 19...
-
Page 8: Main Parts Of Log Splitter
Main Parts of Log Splitter Part# Description Quantity Part# Description Quantity Oil tank Pushbutton box Log pusher Moving wheel Work table Lift handle Wedge Hydraulic control lever Lift handle Control lever guard Support leg Bleed screw Work table extension with Oil drain bolt with remaining plate dipstick... -
Page 9: Before Each Use
Wiring Diagram Plumbing Diagram Before Each Use ⚠WARNING • Always wear the proper protective equipment including ANSI Z87.1 compliant eye protection, steel toed boots, and snug fitting gloves without drawstrings or loose cuffs. • Do not wear loose fitting or dangling clothing. •... -
Page 10: Operating Instructions
Operating Instructions ⚠WARNING • Always wear the proper protective equipment including ANSI Z87.1 compliant eye protection, steel toed boots, and snug fitting gloves without drawstrings or loose cuffs. • Do not wear loose fitting or dangling clothing. • Crush Hazard. Keep hands away from wedge, endplate/ram, and partly spit logs. •... - Page 11 2. After a 5-second interval, the oil under pressure will overheat and the machine could be damaged. For an extremely hard log, rotate the log 90º to see whether it can be split in a different direction. If you are not able to split the log, its hardness exceeds the capacity of the machine and thus that log should be discarded to protect the log splitter from damage.
- Page 12 Replacing Hydraulic Oil Replace the hydraulic oil in the log splitter after every 150 hours of use. Follow these steps: 1. Make sure that all the moving parts have stopped and the log splitter is unplugged. 2. Unscrew the oil drain bolt and remove it. 3.
-
Page 13: After Each Use
Check the oil level periodically to ensure it is between the two grooves on the dipstick. Refill when low. The following hydraulic oils are recommended for the transmission: • Shell Tellus 22 • Mobile DTE 11 • ARAL Vitam GF 22 •... -
Page 14: Maintenance
4. After using the log splitter for a while, sharpen the wedge using a fine-toothed file and smooth any burrs or crushed areas along the cutting edge. Maintenance ⚠WARNING • Unplug power cord before servicing the log splitter. 1. Clean the log splitter after each use. Left over debris may affect future operation. 2. -
Page 15: Parts Diagram
Parts Diagram Page 15 of 19... -
Page 16: Parts List
Parts List Part # Description Qty. Part # Description Qty. Dipstick Wheel Shelf Washer Groupware Skin Cover Bolt Skin Cover Additional Spring Washer Screw Washer Spring Bolt Steel Ball Nut Cap Pressure Ltd Valve Spring Spring Adjusting Screw Copper Gasket Spring Nut Plug Screw... -
Page 17: Replacement Parts
Replacement Parts • For replacement parts and technical questions, please call Customer Service at 1-800-222-5381. • Not all product components are available for replacement. The illustrations provided are a convenient reference to the location and position of parts in the assembly sequence. •... -
Page 18: Limited Warranty
Northern Tool and Equipment Company, Inc. ("We'' or ''Us'') warrants to the original purchaser only (''You'' or ''Your'') that the Ironton product purchased will be free from material defects in both materials and workmanship, normal wear and tear excepted, for a period of 90 days from date of purchase. - Page 19 Distributed by: Northern Tool & Equipment Company, Inc. Burnsville, Minnesota 55306 www.northerntool.com Made in China Page 19 of 19...
