- Page 1 Instruction Manual MAG Welding Torches Semi-Automatic Torches TL Series 180amp. TL-18 200amp. TL-20 TL-20F TL-20L 350amp. TL-35 TL-35K TL-35F TL-35G Please read this instruction manual Please be sure to deliver this instruction manual before using the product. to the end user of this product.
-
Page 2: Table Of Contents
Contents Notes regarding safety ............2 Specifications ..............Prepareration for Welding ............ 3 Wire Feeder Adapters ............Replacing the Torch Body ........... 4 Replacing the Inner Tube ............ 4 Replacing the Tip Body ............5 Replacing the Liner .............. Parts List Torch Adapter ..............7 Adapter ................7... -
Page 3: Notes Regarding Safety
●Please contact TOKIN CORPORATION or its dealer if there are any unclear points in this manual. If there are any questions regarding service, contact the *Welding flashes contain harmful ultraviolet and infrared lights which can cause dealer of your purchase or TOKIN CORPORATION. -
Page 4: Specifications
Specifications TL-20 TL-35 TL-35F Torch Model TL-18 TL-20F TL-20L TL-35G TL-35K Rated Current Ａ Wire Size （0.8,0.9,1.0） 1.2 （0.6,0.8） 0.9 （1.0） 1.2 （0.8,0.9,1.0） 1.2 （0.8,0.9,1.0） 1.2 Cable Length ｍ 3/4/5/6 3/4/5/6 ％ （CO ） Duty Cycle ％ （MAG） Air Cooled Cooling Method Apparent Weight 0.65 0.65 （0.85） 0.65 Total Weight 1.9 （2.1）... -
Page 5: Replacing The Torch Body
Replacing the Torch Body Using a hexagon wrench loosen the set screw and pull out the torch body. Inner Tube Torch Body Set Screw Hexagon Wrench O-Ring Insulating Rubber When inserting the new torch body always make sure the inner tube and O-ring are in place. Then securly tighten the set screw. Inner Tube O-Ring Please be sure to fully insert the torch body and firmly tighten the set screw. If inadequately tightened heat generation from poor electric supply and gas leaks may occur. ... -
Page 6: Replacing The Tip Body
Replacing the Tip Body If damaged by heat or spatter please unscrew the tip body using a wrench and replace with a new one. Tighten Securely Tip Body Torch Body Tip Body NOTICE: To avoid excess heat generation and unstable arc please be sure to always tighten the tip body securely. TL-35F ■ When removing the tip body from Tip Body Plastic Cap Torch Body a ... -
Page 7: Replacing The Liner
Replacing the Liner For Tokin Connection If wire feeding becomes unsteady due to liner wear or is clogged with wire shavings, rust or dirt, please replace the liner by the following procedure. Electric Connector Electric Connector Liner Torch Adapter ライナ Liner Nut File off any burred edges. ①Place the cable in a straight line. ②Unscrew the liner nut. Rotate the torch end counterclockwise ③Fully insert the new liner into the cable. Measure the length L which protrudes until the liner fitting can be easily grasped. Pull out the liner. from the end. Pull the liner out and cut off the same length L from the front. ... -
Page 8: Parts List
■Parts List TL-18/20 TL-35 10-1 Torch Adapter Adapter ■Replace the guide tube 1.Push by screwdliver head and pull out guide tube. Wire Feeder Adapter Adapter Guide Tube 2.Insert new adapter guide tube from the sharpened tip. - Page 9 ■Parts List 1.Nozzle １ ５.Adapter Nut Item Part No. Part No. Item 038 040 TL-18,20 Φ13 020 002 Adapter Nut 038 041 TL-18,20 Φ16mm １ ６.Liner Nut 038 042 TL-18,20 Narrow Nozzle 001 002 Φ16(350A)73L Part No. Item 001 003 Φ12(350A)73L 020 003 TL/CSH/TH/CP 001 008 Φ18(350A)73L 001 009 Φ16(350A thick 2.5t) １ ７.Screw 001 004 N Narrow Nozzle (350A) Part No. Item 001 007 350A Arc Spot Nozzle 020 004 TL/CSH/TH/CP 2.Orifice １...
- Page 10 MEMO...
- Page 11 MEMO...
- Page 12 MAG Welding Torches 1509 Okubo-cho, Nishi-ku, Hamamatsu-shi, Shizuoka Japan 432-8006 TEL : +81-53 - 485 - 5252 FAX : +81-53 - 485 -5680 E-mail trading@tokinarc.co.jp http://www.tokinarc.co.jp...
