TO:
ALL MERCEDES–BENZ PASSENGER CAR DEALERS
February 2000
DATE:
REF. NO.
P-SI-82.64/129
GROUP:
82
Revision:
SUBJECT:
MODEL 208.365/370
VOICE ACTIVATED CELLULAR TELEPHONE/CD CHANGER INSTALLATION
WARNING!
Disconnecting the negative battery cable is not recommended due to otherwise extensive
reprogramming requirements. WIRING HARNESSES WILL BE ELECTRICALLY ACTIVE. IT IS
THEREFORE NECESSARY TO EXERCISE EXTREME CAUTION WHILE EXECUTING THESE
INSTALLATION INSTRUCTIONS. FAILURE TO DO SO, COULD RESULT IN SEVERE PERSONAL
INJURY OR DEATH FROM ELECTRICAL SHOCK. The ignition and radio power must remain OFF until
the final test is performed.
Application Specific D2B Notes:
•
CD changer, telephone, and voice recognition module fibers are installed at the factory. Telephone and
voice recognition fibers run along the left rear quarter panel and the CD fibers along the right rear quarter panel.
•
The vehicle is configured from the factory for the CD changer only.
•
Two sets of fiber cables run along the left quarter panel. One set is for the telephone only and the other for
telephone and voice recognition. While not in the factory configured ring, these optics are coupled together
just forward of the battery on the right. Which set of optics to use, will depend whether the telephone only or
telephone with voice recognition will be installed.
•
All reconfiguration points are in the trunk in front of the battery and to the right of the fuse panel.
© 2005 Mercedes-Benz USA, LLC
Advertisement
Related Manuals for Mercedes-Benz 208.365
Summary of Contents for Mercedes-Benz 208.365
- Page 1 Which set of optics to use, will depend whether the telephone only or telephone with voice recognition will be installed. • All reconfiguration points are in the trunk in front of the battery and to the right of the fuse panel. © 2005 Mercedes-Benz USA, LLC...
- Page 2 Mounting the PSE and Linear Compensator Locate the (Figure 1): • 25-pole D-connector • 15-pole D-connector • coaxial cable from the front center console • fiber optic connectors (2) • integrated antenna coaxial coupling Figure 1 P82.70-2929-01 © 2005 Mercedes-Benz USA, LLC...
- Page 3 Connect the 25-pole side of the telephone Y- cable to the PSE and gently tighten the retaining screws. Connect the green 14-pole connector to the linear compensator and tie back the excess cable (Figure 2). Figure 2 P82.70-2930-01 © 2005 Mercedes-Benz USA, LLC...
- Page 4 Mounting the Optional Voice Recognition Module (VRM) Proceed to Section D if not installing the VRM. Fasten the VRM to the bracket with two (2) M4 x 8 machine screws (Figure 3). Figure 3 P82.70-2931-01 © 2005 Mercedes-Benz USA, LLC...
- Page 5 (3) M6 flange nuts. Route all cables neatly around the control units and bracket assembly (Figure 5). Note: Fiber optic cables must be handled with care, free of kinks, bends, and abrasions. Figure 5 P82.70-2933-01 © 2005 Mercedes-Benz USA, LLC...
- Page 6 Using an awl, open the four (4) pre-molded cradle mounting holes (two are holes and two are located in the slots on the underside of the tray) (Figure 8). Note: Trim away any excess plastic ridges on the tray upper surface. © 2005 Mercedes-Benz USA, LLC...
- Page 7 Using a blunt object such as a ratchet handle, push out the knockout at the back of the false floor. Figure 8 P82.70-2920-01 © 2005 Mercedes-Benz USA, LLC...
- Page 8 (Figure 11). 15. Apply a slight downward pressure on the telephone and Tele Aid coil cords and secure them to the front and rear tie-down-points with a new wire tie (Figure 11). © 2005 Mercedes-Benz USA, LLC...
- Page 9 Figure 11 P82.70-2923-01 © 2005 Mercedes-Benz USA, LLC...
- Page 10 #8 x ⅜ ʺ sheet metal screw (Figure 13). Figure 13 P82.70-2925-01 18. Install the foam covered carpet piece onto the floor of the compartment covering the channel mounting screw (Figure 14). © 2005 Mercedes-Benz USA, LLC...
- Page 11 Figure 14 P82.70-2926-01 © 2005 Mercedes-Benz USA, LLC...
- Page 12 Insert the lever into the switch opening with the handle pointing up. Figure 15 P82.70-2927-01 Apply steady inward pressure while gently rotating the lever toward you until a ‘click’ is heard (Figure 16). Figure 16 P82.70-2928-01 © 2005 Mercedes-Benz USA, LLC...
- Page 13 (Figure 19). 10. Continue to position the CD changer so that the tabs on the mounting bracket align over the © 2005 Mercedes-Benz USA, LLC...
- Page 14 11. Secure the top mounts with the provided screws. Figure 19 P82.64-2215-01 © 2005 Mercedes-Benz USA, LLC...
- Page 15 CD Changer CD Changer CD Changer CTEL 1 CTEL 1 D2B Component 2 CTEL 1 CTEL 1 Not Present Not Present Voice Activation D2B Component 3 Voice Activation Not Present Not Present Not Present Not Present © 2005 Mercedes-Benz USA, LLC...
- Page 16 CD Changer Disk 1~6 load and unload properly Magazine load and eject operate smoothly CD sliding door opens/closes properly Audio is clear and crisp First and last track on selected CD can be accessed Telephone © 2005 Mercedes-Benz USA, LLC...
- Page 17 CD Changer Main Unit ID Card CD magazine 002 820 62 89 1 pair Orientation covers (installed) Q 6 82 0179 Mounting screws CD Installation Kit Q 6 82 0409 Main bracket Hardware package Cover © 2005 Mercedes-Benz USA, LLC...
- Page 18 Q 6 82 0322 Hardware kit Q 6 82 0462 Parts Information (Voice Recognition System) Qty. Part Name Part Number/Exchange Voice Recognition Module Kit Q 6 82 0448 Voice recognition module Q 6 82 0422 © 2005 Mercedes-Benz USA, LLC...
- Page 19 PTT lever Q 6 82 0479 Operation guide P 271 0000 Tutorial cassette tape P 270 3098 © 2005 Mercedes-Benz USA, LLC...
