- Page 1 OPERATORS MANUAL DIAMOND DRILLING DRILL STANDS QDS-150 QDS-350 QDS-500 QDS-800...
-
Page 2: Technical Data
TECHNICAL DATA TE C HNI CA L D ATA Model QDS-150 Model QDS-350 Model Capacity w/o extension spacers (mm) 150Ø 350Ø Max. Capacity with extension spacers (mm) Effective Stroke (mm) Dimensions L x W x H (mm) 330 x 200 x 815... - Page 3 Lock Clamp Bolt) Guidance Roller Buttress Bar Base Leveling Bolts Cradle Cradle Lock Bolt 10. Adjustable Roller Axle Bolts (on left side only) 11. Carriage Lock Lever EXTENSION SPACERS OPTIONAL FOR QDS-500 & QDS 800 200mm 150mm 100mm 45mm WWW.DIAQUIP.CO.UK...
- Page 4 Now the assembly may be fitted into the dovetail in the stand’s cradle and the cradle lock bolt securely tightened. WWW.DIAQUIP.CO.UK...
- Page 5 These mount to the cradle using two bolts and both bolts must be securely tightened. The motor unit in turn mounts to the spacer WARNING: Always ensure that all mounting fasteners are securely tightened. WARNING: Never attempt to drill unless the stand is fixed securely beyond any doubt. WWW.DIAQUIP.CO.UK...
- Page 6 Refer to the scale on the column indicating the angle. Adjust to the desired angle and tighten the clamp. CAUTION: Do not overtighten the clamp. Only tighten the necessary amount to make the clamp secure. Overtightening could distort the column. WWW.DIAQUIP.CO.UK...
-
Page 7: Carriage Lock
Turn just enough so that the roller cannot be Right side Roller Axle Bolts are not adjustable turned by hand. Now test the tightness of the carriage by cranking it up and down. There should be no free-play, yet no binding throughout its travel. WWW.DIAQUIP.CO.UK... - Page 8 NOTES WWW.DIAQUIP.CO.UK...
- Page 9 NOTES WWW.DIAQUIP.CO.UK...
- Page 10 NOTES WWW.DIAQUIP.CO.UK...
- Page 11 NOTES WWW.DIAQUIP.CO.UK...
- Page 12 APPROVED SERVICE CENTRE; DIAQUIP HEAD OFFICE | MANCHESTER, UK 0161 406 0609 SALES@DIAQUIP.CO.UK WWW.DIAQUIP.CO.UK...
