142.5mm
formera
Quick Installation Guide
Indoor Wireless FHD IP Camera
Model: X2
.00
.00
Package Contents
IP Camera
Mounting Bracket
Power Adapter
Wi-Fi Antenna
Quick Installation Guide
Indoor Wireless HD IP Camera
Quick Installation Guide
V1.1
95.00mm
1
Hardware Introduction
Physical Description
Induction IC
LENS
PIR
Microphone
SD Card
Slot
Audio Output
Reset/WPS Button Mounting Port
Speaker
Antenna
I/O Alarm
Power
I / O Alarm
LAN
DC 5V
LAN
Network light
Power light
190.00mm
Network Light Status
Network Light
O
No Wi-Fi connection
Flashing every 0.2 seconds
EZLink takes e ect (default)
Flashing every 0.4 seconds
WPS is connecting
Slow Flash once per second
Wi-Fi connected
Constant for 3 seconds
Camera resetting
Hardware Installation
Audio
OUT / IN
Audio Input
1. Screw the mount on the wall with the two screws
provided.
2. Loosen the thumb screws to adjust the mount to
the desired position. Once the position is set,
tighten the screws securely.
285.00mm
Description
380.00m
Advertisement
Summary of Contents for formera X2
- Page 1 Wi-Fi Antenna Reset/WPS Button Mounting Port Speaker Quick Installation Guide Indoor Wireless HD IP Camera Antenna I/O Alarm Model: X2 Power I / O Alarm DC 5V 1. Screw the mount on the wall with the two screws provided. Network light...
- Page 2 1. Install Wi-Fi antenna and position upright. http://formera.net to your computer, run it to search settings with its username / password recovery to and access the IP Camera in LAN. 2. Connect the power adapter to the camera.
