CHANGING THE MODE

1. Turn on the iPad Wireless Switch Interface.
2. Press and hold the MODE button. The red LED will flash once per second from 1 to 7
flashes. The number of flashes corresponds to the MODE number. Be sure to count the
flashes.
3. Release the MODE button following the number of flashes that reflects the desired
MODE. The blue and red LED will flash together the number of times indicating which
MODE has been set.
Example: To set MODE 2, hold the MODE button for 2 flashes of the red LED, release, and Example:
Example: Example:
both LEDs will flash 2 times to confirm the MODE 2 setting.
Note: Note: Once the MODE has been set, it will remain the same until it is changed following the
Note: Note:
above steps.

POWER CONSUMPTION

POWER CONSUMPTION POWER CONSUMPTION POWER CONSUMPTION
The iPad Wireless Switch Interface uses an idle timeout function to conserve power. After
two hours of inactivity when powered on and connected, the iPad Wireless Switch Interface
will power down automatically. The timer is reset when any button is pressed.
The iPad Wireless Switch Interface averages a usage of 1160 µA when powered on and 5
µA when off.

RECHARGING THE BATTERY

RECHARGING THE BATTERY RECHARGING THE BATTERY RECHARGING THE BATTERY
To charge the battery, insert the charging cable into the port and plug the other end into
any USB source, such as your iPad AC wall charger. Charging from a laptop or a computer
with a sleep setting is not recommended. A charge will last for about 200 hours.
LED INDICATIONS LED indication

LED INDICATIONS

LED INDICATIONS LED INDICATIONS LED indication LED indication LED indication
3 red flashes when attempting to power on
Red flash every 3 seconds
Red flash once a second
Switch port 1-2
Up Arrow
Page Up
Play/Pause
Space
Page 3 3 3 3 Page
Page Page
Switch Port 3-4
Down Arrow
Page Down
Next
Track
Enter
State State State State
Battery is too low to operate
Battery is low
Charging
