AIC Wireless Lynx User Manual

Server motherboard
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Lynx
Server Motherboard
User's Manual
UM_Lynx_v3.5_120919

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Lynx and is the answer not in the manual?

Questions and answers

Summary of Contents for AIC Wireless Lynx

  • Page 1 Lynx Server Motherboard User's Manual UM_Lynx_v3.5_120919...

  • Page 2: Table Of Contents

    Table of Contents Preface ������������������������������������������������������������������������������������������������� i Safety Instructions ������������������������������������������������������������������������������ ii About This Manual ������������������������������������������������������������������������������ iii Chapter 1� Product Features �������������������������������������������������������������� 1 1�1 Components �������������������������������������������������������������������������������������1 1.2 Specifications �����������������������������������������������������������������������������������2 1�3 Feature ���������������������������������������������������������������������������������������������3 Chapter 2� Hardware Setup ���������������������������������������������������������������� 4 2�1 Central Processiong Unit ������������������������������������������������������������������4 2.1.1 Processor Support ....................4 2.1.2 Processor Heat Sink Module and Processor Socket Assembly .......5 2.1.3 Processor Heat Sink Module ................6...
  • Page 3 4.4.5 Socket Configuration ..................41 4.4.6 ME Configuration ..................... 47 4.4.7 PCH Configuration ................... 48 4.4.8 H2O IPMI Configuration .................. 49 4.4.9 APEI Configuration................... 49 4.4.10 Console Redirection ..................49 4.4.11 H2O Event Log Config Manager ..............50 4.4.12 H2oUve Configuration ................... 50 4�5 Security ������������������������������������������������������������������������������������������51 4.5.1 Security ......................
  • Page 4 Copyright © 2018 AIC, Inc� All Rights Reserved� This document contains proprietary information about AIC products and is not to be disclosed or used except in accordance with applicable agreements.
  • Page 5 Document Release History Release Date Version Update Content November User's Manual release to public 2017 March 1. Gramnar Errors 2018 2. Add About this Manual 1. Datasheet January 2. Hardware Settings update 2019 3. SW update April BIOS update. 2019 August BIOS update.

  • Page 6: Preface

    Preface Copyright No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photo-static, recording or otherwise, without the prior written consent of the manufacturer. Trademarks All products and trade names used in this document are trademarks or registered trademarks of their respective holders.

  • Page 7: Safety Instructions

    Safety Instructions When installing, operating, or performing maintenance on this equipment, the following safety precautions should always be observed in order to reduce the risk of fire, electric shock, and personal injury. Read and understand all instructions. Observe warnings and instructions marked on the product. •...

  • Page 8: About This Manual

    This document pellucidly presents a brief overview of the product design, device installation, and firmware settings for the Lynx motherboard. For the latest version of this user's manual, please refer to the AIC website: https://www.aicipc.com/en/productdetail/20870.

  • Page 9: Chapter 1� Product Features

    Chapter 1� Product Features Lynx User Manual Spica User Manual Chapter 1. Product Features 1�1 Components Lynx OCP Mezzanine V2.0 (A+B+C) OCP Mezzanine V2.0 (A+B) Support PCIe Gen3 x16 Support PCIe Gen3 x16 (Share with Max I/O® #1) (Share with Max I/O® #2) 2 x NGFF(M.2) M-Key...

  • Page 10: Specifications

    Lynx User Manual Chapter 1. Product Features 1.2 Specifications Intel® Lewisburg PCH on-chip solution SATA 10 x SATA 6.0 Gb/s (Skylake/Cascade Lake/Cascade Lake Refresh) Processor Support Aspeed AST2500 Advanced PCIe Graphics & Fabric Interface, Skylake-F SKU CPU Remote Management Processor...

  • Page 11: 1�3 Feature

    By implementing Intel® Xeon® Scalable Processors, fully integrated microarchitecture with AIC MAX I/O® 2.0 which support up to 96 lanes of PCIe Gen3, Lynx server board can maximize your I/O intensive application demand, providing six channels per CPU with total twenty-four DIMM slots deployment which can support up to DDR4 2933/2666MHz.

  • Page 12: Chapter 2� Hardware Setup

    Chapter 2� Hardware Setup Spica User Manual Lynx User Manual Chapter 2. Hardware Setup 2�1 Central Processiong Unit 2�1�1 Processor Support The server board includes two processor sockets (LGA-3647) that provides support for Intel® Xeon® Processor Scalable Family processor and a Thermal Design Power (TDP) of up...

  • Page 13: Processor Heat Sink Module And Processor Socket Assembly

    Lynx User Manual Chapter 2. Hardware Setup 2�1�2 Processor Heat Sink Module and Processor Socket Assembly Each processor socket on the server board is pre-assembled with a loading mechanism that is designed to secure the Processor Heat Sink Module (PHM) to the server board as shown below.

  • Page 14: Processor Heat Sink Module

    Lynx User Manual Chapter 2. Hardware Setup 2�1�3 Processor Heat Sink Module The PHM refers to the sub-assembly where the heat sink and processor are clipped together onto the server board prior to installation. The PHM consists of the components shown below.
  • Page 15 Lynx User Manual Chapter 2. Hardware Setup The PHM sits level with the processor socket assembly. The PHM is NOT installed properly if it does not sit level with the processor socket assembly. Once the PHM is seated over the processor socket assembly, the four heat sink torque screws must be tightened in order as shown below.

  • Page 16: 2�2 Hfi Carrier Card For Host Fabric Interface (Hfi) Supported

    Lynx User Manual Chapter 2. Hardware Setup 2�2 HFI Carrier Card for Host Fabric Interface (HFI) Supported The Intel® Fabric Passive (IFP) Internal Cable Assembly enables high speed, low loss data connections between the Intel® Xeon™ Phi™ processor (KNL-F) and chassis connections to an external network interface via QSFP +28 style connectors.

  • Page 17: 2�3 System Memory

    Lynx User Manual Chapter 2. Hardware Setup 2�3 System Memory 2�3�1 Placement CPU1 JDIMMJ1 JDIMMJ0 JDIMMK1 JDIMMK0 JDIMML1 JDIMML0 JDIMMC0 JDIMMC1 JDIMMB0 JDIMMB1 JDIMMA0 JDIMMA1 CPU0 JDIMMD1 JDIMMD0 JDIMME1 JDIMME0 JDIMMF1 JDIMMF0...

  • Page 18: Dimm Population

    Lynx User Manual Chapter 2. Hardware Setup 2�3�2 DIMM Population DIMM DIMM Numbers Placement Numbers CPU1 CPU0 JDIMMI0 JDIMMC0 JDIMMI1 JDIMMC1 JDIMMH0 JDIMMB0 JDIMMH1 JDIMMB1 JDIMMG0 JDIMMA0 JDIMMG1 JDIMMA1 2 DIMMs CPU1 CPU1 CPU1 CPU1 CPU0 CPU0 CPU0 CPU0 JDIMM_I0...
  • Page 19 Lynx User Manual Chapter 2. Hardware Setup CPU1 CPU0 JDIMMI0 JDIMMC0 JDIMMI1 JDIMMC1 JDIMMH0 JDIMMB0 JDIMM_I0 JDIMM_C0 JDIMMH1 JDIMMB1 JDIMMG0 JDIMMA0 JDIMMG1 JDIMMA1 JDIMM_H0 JDIMM_B0 10 DIMMs CPU1 CPU1 CPU1 CPU1 CPU0 CPU0 CPU0 CPU0 JDIMM_G0 JDIMM_A0 JDIMM_K0 JDIMM_E0 JDIMMJ1...
  • Page 20 Lynx User Manual Chapter 2. Hardware Setup CPU1 CPU0 JDIMMI0 JDIMMC0 JDIMM_I0 JDIMM_C0 JDIMMI1 JDIMMC1 JDIMMH0 JDIMMB0 JDIMM_I1 JDIMM_C1 JDIMMH1 JDIMMB1 JDIMMG0 JDIMMA0 JDIMM_H0 JDIMM_B0 JDIMMG1 JDIMMA1 JDIMM_H1 JDIMM_B1 20 DIMMs JDIMM_G0 JDIMM_A0 CPU1 CPU1 CPU1 CPU1 CPU0 CPU0 CPU0...

  • Page 21: Dcpmm Dimm Population

    Lynx User Manual Chapter 2. Hardware Setup 2�3�3 DCPMM DIMM Population Asymetric population CPU0 DIMM JDIMMF0 JDIMMF1 JDIMME0 JDIMME1 JDIMMD0 JDIMMD1 JDIMMC0 JDIMMC1 JDIMMB0 JDIMMB1 JDIMMA0 JDIMMA1 App Direct DRAM1 DRAM1 DRAM1 DRAM1 DRAM1 DRAM1 DRAM1 DRAM1 DRAM1 DRAM1 DCPMM...

  • Page 22: Installation

    Lynx User Manual Chapter 2. Hardware Setup 2�3�4 Installation Step 1 Unlock the dimm socket by pressing the retaining clips outward. Step 2 Insert the memory module into the slot. Make sure that the dimm notch is accurately positioned. DIMM notch...

  • Page 23: Chapter 3� Motherboard Settings

    Chapter 3� Motherboard Settings Lynx User Manual Chapter 3. Motherboard Settings This section provides illustrations that display the internal jumpers, connectors, and system LED indicators. 3�1 Block Diagram Platform Environment Control Interface(PECI) USB2#9 DIMM #I1 DIMM #C1 USB2#8 USB2.0(X2) DIMM #L1...

  • Page 24: 3�2 Content List

    Lynx User Manual Chapter 3. Motherboard Settings 3�2 Content List 3�2�1 Connector and Header Connector and Header Location Connector and Header Location JPWR1 Backplane Power JPWR2 BMC I2C10 Header JBMC_I2C10 Header JPWR3 JPWR4 Power Supply JPWR5 BMC SPI Socket JSPI_BMC...

  • Page 25: Jumper

    Lynx User Manual Chapter 3. Motherboard Settings 3�2�2 Jumper Jumper Location Jumper Location Power Supply COM BMC Disable Jumper JBMC_DIS Bus Disable Jumper Power Supply Flash Descriptor PSKILL Disable Security override Jumper Jumper PS_ON Enable NTB Configuration JNTB Jumper Jumper...

  • Page 26: 3�3 Placement

    Lynx User Manual Chapter 3. Motherboard Settings 3�3 Placement...

  • Page 27: Pin Definition

    Lynx User Manual Chapter 3. Motherboard Settings 3.4 Pin Definition 3�4�1 Connector 1a ~ 1d Backplane Power Header (JPWR1, JPWR2, JPWR3, JPWR4) 2 Power Supply Connector (JPWR5) 3 Power Supply Header (JPMBUS_PDB) 4 PMBus Header (JPMBUS) SMB_PMBUS_CLK SMB_PMBUS_DATA PMBUS_ALERT_N +3.3V...
  • Page 28 Lynx User Manual Chapter 3. Motherboard Settings 6a ~ 6b Power Supply Connector (JPWR6, JPWR7) 7a PCH Fan Connector (J4) 7b CPU0 Fan Connector (J21) 7c CPU1 Fan Connector (J22) +12V TACH 8a Front I/O USB Header (JUSB_INT1, JUSB_INT2) 8b Front I/O USB Header (JUSB_INT2)
  • Page 29 Lynx User Manual Chapter 3. Motherboard Settings 9 Front I/O USB 2.0 Header (JUSB20) 10 OCuLink Connector (JSYS_EXT) BMC GPIO Header (JBMC_GPIO1) BMC GPIO Header (JBMC_GPIO2) GPIOP3 GPIOP2 GPIOI3 GPION7 +3.3V_DUAL...
  • Page 30 Lynx User Manual Chapter 3. Motherboard Settings 12 Front Panel Header (JFRNT_SSI) 13 PCH SGPIO Header (JSGPIO) 14 PCH SSGPIO (JSSGPIO) 18 LCM Header (JLCM) SW_PWR_BTN# SW_RST_BTN# TXDC RXDC...
  • Page 31 Lynx User Manual Chapter 3. Motherboard Settings COM Port (JCOM1, JCOM4) 21 Buzzer Header (JBUZZER) BMC_BUZZER- 22 IPMB Header (JBMC_I2C1) I2C1SDA I2C1SCL N.C. 23 BMC I2C10 Header (JBMC_I2C10) I2C10SCL I2C10SDA 29 VGA Header (JVGA_INT) DACROA N.C. DACGOA DDC_DATAO DACBOA AHSYNCO N.C.
  • Page 32 Lynx User Manual Chapter 3. Motherboard Settings 31 VRM SMB Header (JSMB_VR) SMB_VR_DAT SMB_VR_CLK 32 PCH GPIO Header (JPCH_GPIO) PCH_GPP_C16 PCH_GPP_C17 33 VROC KEY BOX Header (JRAID_KEY) +3.3V_DUAL PCH_GPP_C10 39 SATA DOM Power Header (JDOM_PWR) 41 PCIE Hot-Plug SMB Header (JPCIE_HP)
  • Page 33 Lynx User Manual Chapter 3. Motherboard Settings Power Supply Connector (J9, J10) +12V +12V +12V +12V +12V +12V +12V +12V +12V +12V +12V +12V +12V +12V +12V +12V +12V +12V PMBUS_SDA PMBUS_A0 PMBUS_SCL PMBUS_A1 PS_ON +12V_AUX ALERT CR_BUS_N SENSE- 12LS...

  • Page 34: Jumper

    Lynx User Manual Chapter 3. Motherboard Settings 3�4�2 Jumper A1 ~ A2 Power Supply COM Bus Disable H BMC Disable Jumper (JBMC_DIS) Jumper (J15, J16) JBMC_DIS Setting J15, J16 Setting Short Disable Short Disable Open Normal Defualt Open Enable Defualt...

  • Page 35: 3�5 System Led Indicator

    Lynx User Manual Chapter 3. Motherboard Settings 3�5 System LED Indicator 3�5�1 Internal LED JDIMMJ0 JDIMMK1 NGFF2 ACT LED JDIMML0 JDIMMC0 JDIMMC1 NGFF1 ACT LED JDIMMB0 JDIMMB1 UID LED UID LED JDIMMA1 RSMRST PG LED RSMRST PG LED SYSTEM PG LED...

  • Page 36: Chapter 4. Bios Configuration Settings

    Chapter 4. BIOS Configuration Settings Lynx User Manual Chapter 4. BIOS Configuration Settings This chapter demonstrates how to configure the UEFI BIOS settings in your system device. You can enter the BIOS screen during system startup. To enter BIOS configuration settings, •...

  • Page 37: 4�2 Bios Setup

    Lynx User Manual Chapter 4. BIOS Configuration Settings 4�2 BIOS Setup 4�2�1 Menu Press  and  to select the options of the menu bar. Press Enter to access the option screen. Menu Description Main Displays basic system information and date & time.
  • Page 38 Lynx User Manual Chapter 4. BIOS Configuration Settings  There will be a message “Entering SETUP” displayed on the diagnostics screen.  Identify the BIOS version. NOTE For the official released version, the last digit of the BIOS version must end in a “0.“...
  • Page 39 Lynx User Manual Chapter 4. BIOS Configuration Settings  Load Optimal Default Setting.  Save the setting and exit the BIOS setup utility.
  • Page 40 Lynx User Manual Chapter 4. BIOS Configuration Settings 4�2�3 Update To identify the latest BIOS version, please check the BIOS setup.
  • Page 41 Lynx User Manual Chapter 4. BIOS Configuration Settings Update BIOS by INSYDE H2OFFT-D utility under DOS environment If you need to update Flash in the DOS environment, please use H2OFFT-D utility. To use this utility, you must include the flash.bat , H2OFFT-D.exe, and bin file in the same folder.

  • Page 42: Dcpmm Setup

    Lynx User Manual Chapter 4. BIOS Configuration Settings 4�2�4 DCPMM Setup  Refer to section 4.2.2 step 1 and 2 to enter the Front Page menu.  Enter the option "Device Management."  In "Device Management" page, enter "Intel(R) Optane(TM) DC Persistent Memory...
  • Page 43 Lynx User Manual Chapter 4. BIOS Configuration Settings Intel(R) Optane(TM) DC Persistent Memory Configuration • DIMMs...
  • Page 44 Lynx User Manual Chapter 4. BIOS Configuration Settings • Regions • Namespaces...
  • Page 45 Lynx User Manual Chapter 4. BIOS Configuration Settings • Total Capacity • Diagnostics...
  • Page 46 Lynx User Manual Chapter 4. BIOS Configuration Settings • Preferences...

  • Page 47: 4�3 Main

    Lynx User Manual Chapter 4. BIOS Configuration Settings 4�3 Main Main Option Key: 4�3�1 Main Main System time Configures the current time. System date Configures the current date.

  • Page 48: 4�4 Advanced

    Lynx User Manual Chapter 4. BIOS Configuration Settings 4�4 Advanced Advanced Option Key: 4.4.1 Peripheral Configuration Peripheral Configuration PCIe SR-IOV [Enable] Disable PCIe ARI Enable [Disable] ARI Forward Enable [Disable] Spread Spectrum Enable [Disable] 4.4.2 Video Configuration Video Configuration Display Mode...

  • Page 49: Sio Ast2500

    Lynx User Manual Chapter 4. BIOS Configuration Settings 4�4�4 SIO AST2500 SIO AST2500 Serial Port A Auto [Enable] Disable Base I/O Address [3F8] Interrupt IRQ3 [IRQ4] Serial Port B Auto [Enable] Disable Base I/O Address [2F8] Interrupt [IRQ3] IRQ4 Serial Port D...
  • Page 50 Lynx User Manual Chapter 4. BIOS Configuration Settings Volatile Memory [Auto] Mode AppDirect cache Auto Enable [Disable] eADR Support Auto Enable [Disable] 1LM Memory 256B Target, 64B Target, 64B Interleave [Auto] 256B Channel Channel Granularity Memory Map IMC Interleaving [Auto]...
  • Page 51 Lynx User Manual Chapter 4. BIOS Configuration Settings App Direct [Enable] Disable Memory Hole SWSMI [ASL] implementation SMBus Max Min= 0, Max= 4294967295, [350] Access Time NGNVM DIMM NGN Configuration Secure Erase SMBus Release Min= 0, Max= 4294967295, [150] Unit...
  • Page 52 Lynx User Manual Chapter 4. BIOS Configuration Settings PCI 64-Bit Resource [Enable] Disable Allocation PCIe Train by BIOS [Yes] PCIe Hot Plug Auto Manual Enable [Disable] PCIe ACPI Hot Plug Enable [Disable] Per-Port PCI-E Completion Timeout (Global) [No] Per-Port Disable...
  • Page 53 Lynx User Manual Chapter 4. BIOS Configuration Settings Intel® VMD 32-bit non-prefetchable for Volume [64-bit non-prefetchable] Intel® VMD MemBar2 IIO Configuration Management technology attribute Device on 64-bit prefetchable Socket 0 WFR Uncore GV Auto Enable [Disable] Rate Reduction Uncore Freq...
  • Page 54 Lynx User Manual Chapter 4. BIOS Configuration Settings Non-Snoop Latency Latency Min=0, Max=7, [0] Multiplier Tolerence Requirement Non-Snoop Min=0x0, Max=0x3ff Latency Value IIO0_PKGC_ Enable CLK_GATE_ [Disable] DISABLE IIO1_PKGC_ Enable CLK_GATE_ [Disable] DISABLE IIO2_PKGC_ Enable CLK_GATE_ [Disable] DISABLE UPI01_PKGC_ Enable CLK_GATE_...

  • Page 55: Me Configuration

    Lynx User Manual Chapter 4. BIOS Configuration Settings 4.4.6 ME Configuration ME Configuration Altitude Min=0x0, Max=0xffff, [0x8000] Server ME General ME Configuration Configuration MCTP Bus Owner Min=0x0, Max=0xffff, [0x0] ME Initialization Min=0, Max=12, [2] Complete Timeout Enable HSIO [Enable] Disable...

  • Page 56: Pch Configuration

    Lynx User Manual Chapter 4. BIOS Configuration Settings 4.4.7 PCH Configuration PCH Configuration PCH Devices PCH state after G3 [S5] Last State SATA Controller [Enable] Disable Configure SATA as [AHCI] RAID Support Aggressive Link Power [Enable] Disable Management Port 0~7...

  • Page 57: H2O Ipmi Configuration

    Lynx User Manual Chapter 4. BIOS Configuration Settings 4.4.8 H2O IPMI Configuration H2O IPMI Configuration IPMI Support [Enable] Disable BMC Warmup Time Min=0, Max=240, [90] ACPI SPMI Table [Enable] Disable Boot Option Support [Enable] Disable Set BIOS version to [Enable]...

  • Page 58: H2O Event Log Config Manager

    Lynx User Manual Chapter 4. BIOS Configuration Settings 4.4.11 H2O Event Log Config Manager H2O Event Log Config Manager BIOS Log Event To BIOS Event Log BIOS Event [BMC SEL] Memory Disable Configuration Log Viewer Event Log [Stop Overwrite Clear All...

  • Page 59: 4�5 Security

    Lynx User Manual Chapter 4. BIOS Configuration Settings 4�5 Security Security Option Key: 4�5�1 Security Security Current TPM Device Not Detected TPM 1.2 [TPM 2.0] TPM Active PCR Hash [SHA1, SHA256] Algorithm TPM Hardware Supported Hash [SHA1, SHA256] Algorithm TrEE Protocol Version 1.0 [1.1]...

  • Page 60: 4�6 Power

    Lynx User Manual Chapter 4. BIOS Configuration Settings 4�6 Power Power Option Key: 4�6�1 Power Power Wake on PME Enable [Disable]...

  • Page 61: 4�7 Boot

    Lynx User Manual Chapter 4. BIOS Configuration Settings 4�7 Boot Boot Option Key: 4�7�1 Boot Boot Boot Type [Dual Boot Type] Legacy Boot Type UEFI Boot Type Quick Boot [Enable] Disable Quiet Boot Enable [Disable] Network Stack [Enable] Disable [Disable]...

  • Page 62: 4�8 Exit

    Lynx User Manual Chapter 4. BIOS Configuration Settings 4�8 Exit Exit Option Key: 4�8�1 Exit Save and Exit Exit Saving Changes Exit system setup and save your changes. Save Change Without Exit Save your changes without exiting the system. Exit Discarding Changes Discard your changes when existing the system.

  • Page 63: Chapter 5. Bmc Configuration Settings

    Chapter 5. BMC Configuration Settings Lynx User Manual Chapter 5. BMC Configuration Settings 5�1 Login NOTE This feature works with the JAVA 6 run time installed console environment. The IP address below is an example using the default IP setting. The IP address is configurable.

  • Page 64: 5�2 Web Gui

    Lynx User Manual Chapter 5. BMC Configuration Settings 5�2 Web GUI 5�2�1 Menu Bar Click to select the options of the menu bar. Menu Description The Dashboard page gives the overall information about the status of a Dashboard device. Sensor The Sensor Readings page displays all the sensor related information.

  • Page 65: User Information And Quick Button

    Lynx User Manual Chapter 5. BMC Configuration Settings 5�2�2 User Information and Quick Button The user information and quick access buttons are located at the top right corner. It displays the logged-in user, his/her privilege and the four quick buttons allowing you to perform different functions.
  • Page 66 Lynx User Manual Chapter 5. BMC Configuration Settings 5�2�3 Dashboard The Dashboord page displays device, system, and network information. Click Dashboard on the menu bar to view the overall information of the server. 5�2�4 Sensor The Sensor page displays the status and records on related sensors.

  • Page 67: Fru Information

    Lynx User Manual Chapter 5. BMC Configuration Settings 5�2�5 FRU Information The FRU Information page displays Basic Information, Chassis Information, Board Information and Product Information of the FRU device. Click FRU Information on the menu bar to view the details of the selected device.

  • Page 68: Settings

    Lynx User Manual Chapter 5. BMC Configuration Settings 5�2�7 Settings The Settings page displays the configuration settings for KVM Mouse Setting, Media Redirection Settings, Network Settings, Platform Event Filter, Services, SMTP Settings, SSL Settings, System Firewall, User Management, and Video Recording.

  • Page 69: Remote Control

    Lynx User Manual Chapter 5. BMC Configuration Settings 5�2�8 Remote Control The Remote Control page displays the configuration for power control and remote KVM. Launch KVM...
  • Page 70 Lynx User Manual Chapter 5. BMC Configuration Settings Procedure To Start KVM Step 1 Click Start KVM to start the H5Viewer video redirection. Step 2 Click Browse to select CD Image. Step 3 Click Start Media to redirect the selected CD image file to the Host.
  • Page 71 Lynx User Manual Chapter 5. BMC Configuration Settings Remote KVM Menu and Option Key Button Description Start KVM Starts the H5Viewer video redirection. Stop KVM Stops the H5Viewer video redirection. Pause Video This option is used for pausing Console Redirection.
  • Page 72 Lynx User Manual Chapter 5. BMC Configuration Settings This menu item can be used to act as the right- Right <Ctrl> side <CTRL> key when in Console Redirection. This menu item can be used to act as the right- Right <Alt>...

  • Page 73: Power Control

    Lynx User Manual Chapter 5. BMC Configuration Settings 5�2�9 Power Control The Power Control page allows you to view and control the power of your server. To open Power Control, click Power Control from the menu bar. The various options of Power Control are given below.

  • Page 74: Maintenance

    Lynx User Manual Chapter 5. BMC Configuration Settings 5�2�10 Maintenance This Maintenance page displays the configuration settings for Backup Configuration, Firmware Image Location, Firmware Information, Fimware Update, Preserve Configuration, Restore Configuration, Restore Configuration, and Restore Factory Defaults. Maintenance Procedure 1. Click Check All to backup the selected configuration items. The Backup...

  • Page 75: Sign Out

    Lynx User Manual Chapter 5. BMC Configuration Settings 5�2�11 Sign out To log out of the BMC: Method 1: Click Sign out from the menu bar. The Logout dialog box will pop out. Method 2: Click the root quick button on the top right corner of the screen.

  • Page 76: 5�3 Firmware Update

    1. Boot to the DOS (MS-DOS or Free DOS is workable). 2. Enter BMC firmware directory [XXXXXLXOOOYYY_ARK]; XXXXX: project name ; OOO: for Lynx standard version YYY:firmware version; K: For auxiliary version 3. Execute a�bat batch file to update the BMC firmware.

  • Page 77: Chapter 6� Technical Support

    Chapter 6� Technical Support Taiwain, Global Headquarters South California, United States Address: No. 152, Section 4, Address: 21808 Garcia Lane Linghang N� Rd, Dayuan District, City of Industry, CA 91789, Taoyuan City 337, Taiwan United States Tel: +886-3-433-9188 Toll free: +7-4997019998 Tel: +1-909-895-8989 Fax: +886-3-287-1818 Fax: +1-909-895-8989#157...
