- Page 1 User’s Manual BPSE24V40ART2U BPSE48V40ART2U BPSE72V40ART2U Cyber Power Systems, Inc. K01-C000610-00 www.cyberpower.com...
-
Page 3: Table Of Contents
TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS ....................4 UNPACKING ............................5 OVERVIEW ............................6 FRONT/REAR PANEL DESCRIPTION ........................6 HARDWARE INSTALLATION ......................7 RACKMOUNT INSTALLATION ..........................7 VERTICAL/TOWER INSTALLATION ........................8 BATTERY INSTALLATION AND REPLACEMENT ...................9 TECHNICAL SPECIFICATIONS ......................10... -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS This manual contains important instructions. Please read and follow all instructions carefully during installation and operation of the unit. Read this manual thoroughly before attempting to unpack, install, or operate the Battery modules. CAUTION! The UPS unit must be connected to a grounded AC power outlet with fuse or circuit breaker protection. -
Page 5: Unpacking
UNPACKING Battery module Rackmount rails (2) User’s manual Battery cable Flat head screws: Pan head screws: M4X8L (8) M5X12L (4) Plastic washers (8) Screw hole dust Rackmount ears covers (8) (Stands) (2) PowerPanel® Business software is available on our website. Please visit www.cyberpower.com and go to the Software Section for free download. -
Page 6: Overview
OVERVIEW FRONT/REAR PANEL DESCRIPTION BPSE24V40ART2U/BPSE48V40ART2U/BPSE72V40ART2U 1. Input Connector Use this input connector to connect the Battery module to the Power module or to the next Battery module. 2. On-board Replaceable Fuse Cover Replaceable fuse is accessible from the rear panel. It must be done by qualified personnel. -
Page 7: Hardware Installation
HARDWARE INSTALLATION HARDWARE INSTALLATION These Battery modules can be mounted in a rackmount or vertical tower orientation. This versatility is especially important to growing organizations with changing needs that value having the option to position a Battery module on a floor or in a rackmount system. Please follow the instructions below for the respective mounting methods. -
Page 8: Vertical/Tower Installation
HARDWARE INSTALLATION Step 3: Install the Battery module on the rack Place the Battery module onto the rackmount rails with the front of the unit facing you. Secure the Battery module to your rack with four M5X12L screws at the front of the rack. (Located in position 2 &... -
Page 9: Battery Installation And Replacement
HARDWARE INSTALLATION BATTERY INSTALLATION AND REPLACEMENT Step 1: Unscrew the top cover and separate the top cover from the Battery module. Step 2: Unscrew the steel bars and separate the steel bars from the Battery module. Step 3: Remove the battery pack from the Battery module. Step 4: Open the battery pack and change the batteries. -
Page 10: Technical Specifications
TECHNICAL SPECIFICATIONS Models BPSE24V40ART2U BPSE48V40ART2U BPSE72V40ART2U Battery Specifications 12V x 2pcs x 2 sets 12V x 4pcs x 2 sets 12V x 6pcs x 2 sets Rated Battery Voltage Overload Protection Fuse Physical Dimension (WxHxD)mm 438 x 88 x 430... - Page 12 11F., No.26, Jinzhuang Rd., Neihu Dist., Taipei City 114, Taiwan Entire contents copyright © 2019 Cyber Power Systems, Inc. All rights reserved. Reproduction in whole or in part without permission is prohibited. PowerPanel® Business and PowerPanel® Personal are trademarks of...
