Summary of Contents for ifi AURORA
- Page 1 User Manual...
- Page 3 2. Never obstruct the unit or place it near any objects or liquids that may damage the unit. iFi audio suggests downloading and installing the MUZO Player App* on your iOS/Android device rst to enable you to operate the playback options on the Aurora.
- Page 4 Note: Auto-Protection mode When the Aurora is playing at an excessively high volume, it may enter 'Auto-Protection' mode (volume level will be automatically reduced) to avoid 'clipping' so that the driver units and the ampli er are not damaged. No harm to the equipment should ensue.
- Page 5 3.5mm DC 12V/20A INPUT COAXIAL OPTICAL Aurora CAUTION ATTENTION Technology licensed from AMR-Audio, UK AirPlay Assembled in China 1. Automatic Room Tailoring 5. 3.5mm(AUX) input 6. Coaxial input (ART Ultrasonic Sonar) 7. Optical input 2. RCA(AUX) input 8. LAN input 3.
- Page 6 1. The rear IEC or 12v socket is for connecting to a power source. 2. For a wired Internet connection, connect a LAN/Ethernet cable from the Aurora to the router. 3. For a wireless Internet connection, if your router has a WPS button, simply press and pair.
- Page 7 1. Power ON (via AC power cable or 12V/20A source such as marine mains power) 2. Select Bluetooth input on the Aurora 3. Pair via ‘iFi Hi-Res audio’ on your Smart device Bluetooth menu 4. Once paired, select the music app such as Spotify or Apple Music.
- Page 8 Set-top Box Blu-Ray/DVD/CD Player Router SDHC Micro card 3.5mm DC 12V/20A INPUT COAXIAL OPTICAL Auto/Marine Aurora Power Supply CAUTION ATTENTION Technology licensed from AMR-Audio, UK AirPlay Assembled in China HDD, USB memory stick Echo Dot...
- Page 9 4. Volume control 5. Previous/Next (only available in WiFi mode*) 6. Play/Pause 7. Brightness 8. Input 9. ART Auto Room Tailoring (HOLD for 3 secs to switch between ART/Audiophile modes) 10. TrueBass 11. Battery compartment Aurora *Depends on the software player support...
-
Page 10: Input Selection
Volume Control Volume can be adjusted by using the front touch bar on the Aurora, the included remote control or the MUZO Player App*. Input selection Analogue Inputs RCA/Co-axial – connect left & right cables from an analogue source such as a CD player. - Page 11 Network Attached Storage (NAS) source. Use the MUZO Player App* to stream Spotify (incl. Connect), TIDAL, Napster, QQ Music and many more. Optical – derive signal input straight from a TV so the Aurora acts as a sound bar. Coaxial – connect an SPDIF source such as a Blu-ray player.
- Page 12 ** FAT32 - formatting past the Windows 32GB limit 1) The Aurora reads FAT32 only (not NTFS/ExFat/HPF+) 2) OS X formats FAT32 regardless of size. 3) Windows OS by itself is unable to format a drive above 32GB. Third party utilities are required.
- Page 13 For maximum musical enjoyment, we need well thought out room correction for any audio system. This is EVEN more prevalent with a one-box solution such as the Aurora as all similar one-box products sound like a mono source because they are….a mono source.
- Page 14 Most room correction uses DSP. iFi does not use DSP of this k ind in any of its products. The Aurora incorporates sound-matrix technologies that operate entirely in the analogue domain.
- Page 15 The TrueBass system, incorporating the two downward- ring bass radiators, ensures that the Aurora delivers genuine bass with realistic depth and de nition. Dual- level depth control means you can adjust the bass response according to taste –...
- Page 16 The iFi current multiplier circuit is entirely different because the switching frequency is xed at an ultra-high level - around 1.5MHz, hence it has ultra-high resolution. This results in a high level of efficiency, multiplying the current supplied by the valve several thousand-fold, whilst maintaining far greater linearity and lower noise than typical switching ampli ers.
- Page 18 Balmoral Lodge,139-141 Cambridge Road, Southport, PR9 7LN. UK. i -audio.com Ver1.1...
