Designing, Manufacturing and Supplying WB Series Electric Isolated Sensor and Digital
Electrical Sensor since 1989
USER MANUAL
WBI412M05 AC Current Sensor
www.mywbdz.com
alex827@qq.com
Technical Service: 86 816 2778271
Quality Complain: 86 816 2278273
Fax Line: 86 816 2281934
ISO9001 ISO14000 ISO18000
Certified
Quality Warranty
Any quality problem found in WB series products, we offer
Three years free charge of repair the products, and six months guaranteed free charge of change and return the
products.
1
Mianyang Weibo Electronics Co.,Limited
No.7 Road 2 of Xianren Road Youxian District Mianyang City P.R. China
Tel: 86-816-2971265 Fax: 86-816-2281934
www.mywbdz.com
alex827@qq.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Mianyang Weibo Electronic WBI412M05
Summary of Contents for Mianyang Weibo Electronic WBI412M05
- Page 1 Designing, Manufacturing and Supplying WB Series Electric Isolated Sensor and Digital Electrical Sensor since 1989 USER MANUAL WBI412M05 AC Current Sensor www.mywbdz.com alex827@qq.com Technical Service: 86 816 2778271 Quality Complain: 86 816 2278273 Fax Line: 86 816 2281934 ISO9001 ISO14000 ISO18000...
- Page 2 WBI412M05 AC Current Sensor Safety claim The information in the safety claim of the equipment documentation is intended to ensure that equipment is properly installed in order to maintain it in a condition. It is assumed that everyone who would be associated with the equipment should be familiar with the contents of that safety section, or this safety guide.
- Page 3 Product Description and Application WBI412M05 uses a special isolation module to measure the AC current in the grid and circuit in real time and transform it into the DC voltage (Uz) output of the standard vertebra; with high precision, high isolation, low drift, low power consumption and wide temperature range. It has strong anti-interference ability and wide working power range.
- Page 4 Terminals definition Working power ground(GND) Current input（IN-） Positive voltage output (OUT+) Current output（IN+） Negative voltage output (OUT-) Positive working power(+E) Non-identified terminals cannot be used！ Key Technical Data: 1. Input: 0.5A, 1A, 2A, 3A, 4A, 5A AC; 2. Output: 0-20mA, 4-20mA DC 3.
- Page 5 Step 1: Immobilize one side of product‘s mounting trough to the DIN mounting rail; Step 2: Pull out the spring clasp; Step 3: Place whole mounting trough to the DIN mounting rail properly; Step 4: Release spring clasp to make sure the installation. 2.
- Page 6 output value Vz should be calculated as: Vz = 5V×Ir/50A (5) Using output monitoring meter V2 to measuring the output voltage V0 of the sensor, the basic introduced errorγof the sensor should be calculated as: γ= (Vo－Vz)/5V×100 (6) Repeating step (4) (5), if calculated absolute value is less than the given accuracy value of the sensor, it shows the sensor’s accurate grade is qualified.
