- Page 1 ACLAVIS ® CoM Baseboard TX-Original 1v1 LVDS Glyn GmbH & Co KG – ACLAVIS® CoM LVDS Baseboard 1v1 Page 1 of 45...
- Page 2 GLYN GmbH & Co. KG, D-65510 Idstein. The GLYN GmbH & Co. KG, D-65510 Idstein does not accept liability or provide any guarantee with respect to the contents of this documentation. The GLYN GmbH & Co. KG, D-65510 Idstein retains the right of revising this work.
-
Page 3: Table Of Contents
4 Revision List ......................42 Appendix A: Ordering Information ACLAVIS® Baseboards ........43 Appendix B: Ordering Information Ka-Ro TX-Boards ..........44 Contact Information ....................45 Glyn GmbH & Co KG – ACLAVIS® CoM LVDS Baseboard 1v1 Page 3 of 45... -
Page 4: Introduction
LVDS Display Optical Isolate IOs Size and supply 10V – 30V DC Power supply -40°C bis 85°C 100mm x 75mm Glyn GmbH & Co KG – ACLAVIS® CoM Baseboard TX-Original 1V1.1 Page 4 of 45... -
Page 5: General Precautions
Hold components by the edges and do not touch the ICs on them! ► Whenever you uninstall any component, place it on a grounded antistatic pad or in the bag that came with the component! Glyn GmbH & Co KG – ACLAVIS® CoM Baseboard TX-Original 1V1.1 Page 5 of 45... -
Page 6: Baseboard Hardware
2 Baseboard Hardware 2.1 Blockdiagram Glyn GmbH & Co KG – ACLAVIS® CoM Baseboard TX-Original 1V1.1 Page 6 of 45... -
Page 7: Baseboard Overview
2.2 Baseboard Overview Backplane Glyn GmbH & Co KG – ACLAVIS® CoM Baseboard TX-Original 1V1.1 Page 7 of 45... -
Page 8: Boot-Jumper
2.3 Boot-Jumper closed Boot from USB/UART open Boot from NAND, eMMC (default) Boot-Mode See also chapter 2.4.8.2 Jumper microUSB Typ B Glyn GmbH & Co KG – ACLAVIS® CoM Baseboard TX-Original 1V1.1 Page 8 of 45... -
Page 9: Pin Description
2.4 Pin Description 2.4.1 TX-DIMM-Pinout For information about the 200-PIN DIMM pinout, please refer to the TX module datasheet. Glyn GmbH & Co KG – ACLAVIS® CoM Baseboard TX-Original 1V1.1 Page 9 of 45... -
Page 10: St4 Can/Rs485
TX6 pin assignment i.MX6 Pad Name TXCOM pin Selected Function GPIO UART3_TXD EIM_D24 GPIO3[24] UART3_RXD EIM_D25 GPIO3[25] FLEXCAN2_TX KEY_COL4 GPIO4[14] FLEXCAN2_RX KEY_ROW3 GPIO4[11] Glyn GmbH & Co KG – ACLAVIS® CoM Baseboard TX-Original 1V1.1 Page 10 of 45... - Page 11 CAN Termination Resistor R31: You can connect the Resistor via solder bridge B101! RS485 Termination Resistor R22: You can connect the Resistor via solder bridge B100! Glyn GmbH & Co KG – ACLAVIS® CoM Baseboard TX-Original 1V1.1 Page 11 of 45...
-
Page 12: St13 Rs232 (Uart-C)
TX6 pin assignment 4-wire i.MX6 TXCOM pin Selected Function GPIO Pad Name UART2_TXD_DATA SD4_DAT7 GPIO2[15] UART2_RXD_DATA SD4_DAT4 GPIO2[12] UART2_RTS_B SD4_DAT5 GPIO2[13] UART2_CTS_B SD4_DAT6 GPIO2[14] Glyn GmbH & Co KG – ACLAVIS® CoM Baseboard TX-Original 1V1.1 Page 12 of 45... - Page 13 Schematics Glyn GmbH & Co KG – ACLAVIS® CoM Baseboard TX-Original 1V1.1 Page 13 of 45...
-
Page 14: St14 Rs232 (Uart-B)
1-2-7 connected onboard not connected not connected TX6 pin assignment 2-wire i.MX6 TXCOM pin Selected Function GPIO Pad Name UART1_TXD_DATA SD3_DAT7 GPIO2[15] UART1_RXD_DATA SD3_DAT6 GPIO2[12] Glyn GmbH & Co KG – ACLAVIS® CoM Baseboard TX-Original 1V1.1 Page 14 of 45... - Page 15 Schematics Glyn GmbH & Co KG – ACLAVIS® CoM Baseboard TX-Original 1V1.1 Page 15 of 45...
-
Page 16: St5 Df1 Lvds Connector
VLCD LVDS0_CLK_N LVDS0_CLK_P VLCD LVDS0_TX0_N LVDS0_TX0_P LVDS0_TX1_N LVDS0_TX1_P LVDS0_TX2_N LVDS0_TX2_P LVDS0_TX3_N LVDS0_TX3_P DDCDAT1 DDCCLK1 LVDS1_TX0_N LVDS1_TX0_P LVDS1_TX1_N LVDS1_TX1_P LVDS1_TX2_N LVDS1_TX2_P LVDS1_TX3_N LVDS1_TX3_P VLCD LVDS1_CLK_N LVD1_CLK_P Glyn GmbH & Co KG – ACLAVIS® CoM Baseboard TX-Original 1V1.1 Page 16 of 45... - Page 17 LVDS0_TX3_P DDCDAT1(I2C_DATA) DDCCLK1(I2C_CLK) LVDS1_TX0_N LVDS1_TX0_N LVDS1_TX0_P LVDS1_TX0_P LVDS1_TX1_N LVDS1_TX1_N LVDS1_TX1_P LVDS1_TX1_P LVDS1_TX2_N LVDS1_TX2_N LVDS1_TX2_P LVDS1_TX2_P LVDS1_TX3_N LVDS1_TX3_N LVDS1_TX3_P LVDS1_TX3_P VLCD VLCD LVDS1_CLK_N LVDS1_CLK_N LVDS1_CLK_P LVDS1_CLK_P Glyn GmbH & Co KG – ACLAVIS® CoM Baseboard TX-Original 1V1.1 Page 17 of 45...
- Page 18 Schematics Glyn GmbH & Co KG – ACLAVIS® CoM Baseboard TX-Original 1V1.1 Page 18 of 45...
-
Page 19: St11 Ethernet
TX6 pin assignment TXCOM pin Selected Function i.MX6 Pad Name GPIO ETN_TXN #ETN_LED2 ETN_TXP ETN_3V3 ETN_RXN #ETN_LED1 ETN_RXP Glyn GmbH & Co KG – ACLAVIS® CoM Baseboard TX-Original 1V1.1 Page 19 of 45... - Page 20 Schematics Glyn GmbH & Co KG – ACLAVIS® CoM Baseboard TX-Original 1V1.1 Page 20 of 45...
-
Page 21: St8 Usb Host Interface
DATA+ TX6 pin assignment TXCOM pin Selected Function i.MX6 Pad Name GPIO USBH_VBUSEN EIM_D31 GPIO3[31] GPIO3[30] #USBH_OC EIM_D30 10K-PU USBH_DM USB_H1_DN USBH_VBUS USB_H1_VBUS USBH_DP USB_H1_DP Glyn GmbH & Co KG – ACLAVIS® CoM Baseboard TX-Original 1V1.1 Page 21 of 45... - Page 22 Schematics Glyn GmbH & Co KG – ACLAVIS® CoM Baseboard TX-Original 1V1.1 Page 22 of 45...
-
Page 23: St2, St3, St6 Usb Otg
DATA+ TX6 pin assignment ST3 PIN ST6 PIN TXCOM pin Selected Function i.MX6 Pad Name GPIO USBOTG_VBUS USB_OTG_VBUS USBOTG_DM USB_OTG_DN USBOTG_DP USB_OTG_DP USBOTG_ID EIM_D23 GPIO3[23] Glyn GmbH & Co KG – ACLAVIS® CoM Baseboard TX-Original 1V1.1 Page 23 of 45... -
Page 24: Jumper Microusb Typ B
Schematics 2.4.8.1 Jumper microUSB Typ B Glyn GmbH & Co KG – ACLAVIS® CoM Baseboard TX-Original 1V1.1 Page 24 of 45... -
Page 25: Jumper Microusb Typ B Boot-Mode
2.4.8.2 Jumper microUSB Typ B Boot-Mode 2.4.8.3 ST6 optional Connector for TFT Touch (USB Host) Glyn GmbH & Co KG – ACLAVIS® CoM Baseboard TX-Original 1V1.1 Page 25 of 45... -
Page 26: St9 Power Supply
2.4.10 ST9 Power Supply Optional assembled Phoenix 1.5/2-5.08: Schematics Glyn GmbH & Co KG – ACLAVIS® CoM Baseboard TX-Original 1V1.1 Page 26 of 45... -
Page 27: St4 Tft Backlight Connector
Normally the ferrit L2 is mounted. So PIN 1 is 5V DC! If you want to have VIN on PIN 1 you have to unmount ferrit L2 and mount L1! L1 unmounted, L2 mounted 5V (default) L1 mounted, L2 unmounted Glyn GmbH & Co KG – ACLAVIS® CoM Baseboard TX-Original 1V1.1 Page 27 of 45... -
Page 28: Led D6
2.4.12 LED D6 Schematics Glyn GmbH & Co KG – ACLAVIS® CoM Baseboard TX-Original 1V1.1 Page 28 of 45... -
Page 29: Optical Isolated Ios St8
2.4.13 Optical Isolated IOs ST8 TX6 pin assignment TXCOM pin Selected Function i.MX6 Pad Name GPIO INPUT NANDF_CS2 GPIO6[15] INPUT EIM_A16 GPIO2[22] OUTPUT EIM_EB3 GPIO2[31] OUTPUT EIM_A17 GPIO2[21] Schematics Glyn GmbH & Co KG – ACLAVIS® CoM Baseboard TX-Original 1V1.1 Page 29 of 45... -
Page 30: St101 Arduino Compatible Pin Header
2.4.12 ST101 Arduino compatible Pin Header Hint: If you want to use UART3 (PIN 16, 17) on PIN Header you have to remove resistor R21 (RS485)! See Board Schematics. Glyn GmbH & Co KG – ACLAVIS® CoM Baseboard TX-Original 1V1.1 Page 30 of 45... - Page 31 GPIO5[31] GPIO5_IO30 CSI0_DAT12 GPIO5[30] CSPI_SS0 EIM_EB2 GPIO2[30] CSPI_MOSI EIM_D18 GPIO3[18] CSPI_MISO EIM_D17 GPIO3[17] CSPI_SCLK EIM_D11 GPIO3[16] GPIO5_IO18 CSI0_PIXCLK GPIO5[18] GPIO5_IO21 CSI0_VSYNC GPIO5[21] GPIO5_IO19 CSI0_MCLK GPIO5[19] Glyn GmbH & Co KG – ACLAVIS® CoM Baseboard TX-Original 1V1.1 Page 31 of 45...
-
Page 32: St1 Pin Header
2.4.13 ST1 Pin Header Glyn GmbH & Co KG – ACLAVIS® CoM Baseboard TX-Original 1V1.1 Page 32 of 45... - Page 33 GPIO1[2] KP_COL[1] GPIO_4 GPIO1[4] KP_ROW[1] GPIO_5 GPIO1[5] KP_COL[2] KEY_COL2 GPIO4[10] KP_ROW[2] KEY_ROW2 GPIO4[11] KP_COL[3] KEY_COL3 GPIO4[12] KP_ROW[3] KEY_ROW3 GPIO4[13] I2C_SDA GPIO_6 GPIO1[6] I2C_CLK GPIO_3 GPIO1[3] Glyn GmbH & Co KG – ACLAVIS® CoM Baseboard TX-Original 1V1.1 Page 33 of 45...
-
Page 34: St2 Micro Sd Card
GPIO Pad Name SD1_CD SD3_CMD GPIO7[2] SD1_D[0] SD1_DAT0 GPIO1[16] SD1_D[1] SD1_DAT1 GPIO1[17] SD1_D[2] SD1_DAT2 GPIO1[19] SD1_D[3] SD1_DAT3 GPIO1[21] SD1_CMD SD1_CMD GPIO1[18] SD1_CLK SD1_CLK GPIO1[20] Schematics Glyn GmbH & Co KG – ACLAVIS® CoM Baseboard TX-Original 1V1.1 Page 34 of 45... -
Page 35: Component Location
2.5 Component Location Glyn GmbH & Co KG – ACLAVIS® CoM Baseboard TX-Original 1V1.1 Page 35 of 45... -
Page 36: Mechanical Drawing
2.6 Mechanical Drawing Glyn GmbH & Co KG – ACLAVIS® CoM Baseboard TX-Original 1V1.1 Page 36 of 45... -
Page 37: Hardware-Installation
Ensure a good connection to the spring contacts on the bottom side of the module and that the clips are tightly locked in place! Glyn GmbH & Co KG – ACLAVIS® CoM Baseboard TX-Original 1V1.1 Page 37 of 45... -
Page 38: Connect A Display With The Board
3.2 Connect a Display with the Board Glyn GmbH & Co KG – ACLAVIS® CoM Baseboard TX-Original 1V1.1 Page 38 of 45... -
Page 39: Power Supply Connectors
L2 and mount L1! L1 unmounted, L2 mounted 5V (default) L1 mounted, L2 unmounted This is a mounting option for series product! Glyn GmbH & Co KG – ACLAVIS® CoM Baseboard TX-Original 1V1.1 Page 39 of 45... -
Page 40: Df1 Logic Voltage L3 / L4
5V DC to these PINs! If you want this, you have to unmount ferrit L4 and mount L3! L3 unmounted, L4 mounted 3.3V (default) L3 mounted, L4 unmounted This is a mounting option for series product! Glyn GmbH & Co KG – ACLAVIS® CoM Baseboard TX-Original 1V1.1 Page 40 of 45... -
Page 41: Working With The Board During Developement (Starterkit)
► Linux is usually preinstalled on the module (Module baught as part of a starterkit!). Just wait until Linux has booted and log in, depending on the rootfs with the optionally needed password: User:root Password:root(optional) Glyn GmbH & Co KG – ACLAVIS® CoM Baseboard TX-Original 1V1.1 Page 41 of 45... -
Page 42: Revision List
4 Revision List V1.0 07.09.2016 Initial Release V1.1 10.12.2016 Corrections Glyn GmbH & Co KG – ACLAVIS® CoM Baseboard TX-Original 1V1.1 Page 42 of 45... -
Page 43: Appendix A: Ordering Information Aclavis® Baseboards
CoM Baseboard for Ka-Ro TX-LVDS COMs & LVDS TFTs CoM_BB_TX-Original_1v1 ACLAVIS® CoM Baseboard TX-Original CoM Baseboard for Ka-Ro TX-Standard COMs & GLYN Family Concept TFTs Glyn GmbH & Co KG – ACLAVIS® CoM Baseboard TX-Original 1V1.1 Page 43 of 45... -
Page 44: Appendix B: Ordering Information Ka-Ro Tx-Boards
2048 X 1536 TX6Q-8037 i.MX6QP7 800 MHz 2048 MB 4 GB* von -40 bis 70°C 2048 X 1536 *eMMC **LVDS work with ACLAVIS® CoM Baseboard TX-Original LVDS Glyn GmbH & Co KG – ACLAVIS® CoM Baseboard TX-Original 1V1.1 Page 44 of 45... -
Page 45: Contact Information
Contact Information Glyn GmbH & Co KG – ACLAVIS® CoM Baseboard TX-Original 1V1.1 Page 45 of 45...
