Summary of Contents for RIDGE RYDER RR10PK
- Page 1 PAGE 1...
- Page 2 FEATURES The Ridge Ryder RR10PK 1 Watt UHF CB Radio Twin Pack is a great kit for tradies, campers, hikers, 4wders or anyone in between. The kit includes two rechargeable 1W handheld radios, belt clips, a twin charging dock, 240V and 12V charging cables, all packed in a handy carry case.
-
Page 3: Table Of Contents
CONTENTS SAFETY INFORMATION AND WARNINGS........PAGE: 4 RADIO CONTROLS, CONNECTORS & DISPLAY......PAGE: 6 RADIO OPERATION................PAGE: 7 FUNCTION - Channel Selection.............PAGE: 9 - CTCSS & DCS............PAGE: 9 - VOX, Call Tone............PAGE:10 - TOT, Roger Beep, Button Beep.........PAGE:11 - DCM, Duplex (Basic)...........PAGE:12 TRANSMITTING.................PAGE:13 DUPLEX (DETAILED)................PAGE:14 UHF CB CHANNEL GUIDELINES.............PAGE:15 UHF CB CHANNELS AND FREQUENCIES........PAGE:16... -
Page 4: Safety Information And Warnings
SAFETY INFORMATION AND WARNINGS INFORMATION ON SAFE OPERATION Please read this information before installing or using your UHF radio. The operation of your UHF radio in Australia is subject to conditions in the following Licence: In Australia the ACMA Radio communications (Citizen Band Radio Stations) and in New Zealand by MED the General User Radio Licence for Citizen Band Radio. - Page 5 SAFETY INFORMATION AND WARNINGS (continued) ELECTROMAGNETIC INTERFERENCE/COMPATIBILITY Nearly every electronic device is susceptible to electromagnetic interference (EMI). To avoid the pos- sibility of electromagnetic interference and/or compatibility conflicts, turn off the radio in any location where posted notices instruct you to do so such as health care facilities. AIRCRAFT When instructed to do so, turn off your radio when on-board an aircraft.
-
Page 6: Radio Controls, Connectors & Display
RADIO CONTROLS, CONNECTORS & DISPLAY RADIO LAYOUT ANTENNA LED INDICATOR HEADSET OUTPUT LCD DISPLAY BELT CLIP PTT BUTTON MENU/PWR BUTTON DOWN ARROW UP ARROW MONI BUTTON CALL BUTTON SPEAKER BATTERY COVER LCD DISPLAY DCM ICON VOX ICON SCAN ICON DUPLEX / REPEATER ICON TRANSMITTING ICON DSC ICON RECEIVING ICON... -
Page 7: Radio Operation
RADIO OPERATION POWER ON/OFF To turn the RR10PK ON, press and hold the “(MENU/PWR) BUTTON”, the display will light up, indicating the unit is now ON. To turn the RR10PK OFF, press and hold the “(MENU/PWR) BUTTON”, the display will black out, indicating the unit is now OFF. - Page 8 SQUELCH CONTROL The RR10PK has automatic squelch control which silences the constant background noise during periods of inactivity. The radio will still receive transmissions when a signal is present, however it will eliminate background noise when a signal is not present.
-
Page 9: Function- Channel Selection
FUNCTION- Channel Selection SELECTING THE UHF CHANNEL To select a channel, press the “(MENU/PWR) BUTTON” once, the channel number on the LCD will start flashing. Press the “UP ARROW” or “DOWN ARROW” to scroll to the desired channel. Once the desired channel has been selected, press the “(MONI) BUTTON” and this will save the selected channel and the radio will return to the default screen with the new channel displayed. - Page 10 A call tone is a 2 second signal that is sent out from the radio to let other users know you would like to talk to them. It is an alternative option from just speaking into the MIC to make the user stand out. The RR10PK has 10 call tone options. To transmit a call tone, press the “(CALL) BUTTON”.
- Page 11 FUNCTION- Turn Off Time (TOT) WHAT IS TURN OFF TIME (TOT)? Turn Off Time (TOT) automatically cuts of the radio transmission after a certain period of time. SETTING TURN OFF TIME (TOT) To access the TOT feature, press the “(MENU/PWR) BUTTON” five times, “TO” will display on the screen.
- Page 12 FUNCTION- Dual Channel Monitor (DCM) WHAT IS DUAL CHANNEL MONITOR (DCM)? Generally on a UHF only one channel can be monitored at a time (unless the radio is in scan mode). Dual channel monitor allows two channels to be monitored simultaneously. SETTING DUAL CHANNEL MONITOR (DCM) To access dual channel monitor, press the “(MENU/PWR) BUTTON”...
- Page 13 FUNCTION- Using The UHF Radio TRANSMIT AND RECEIVE PROCEDURE Your UHF radio contains a transmitter and receiver. To control your exposure and ensure compliance with the general population/uncontrolled environment exposure limits, always adhere to the following procedure: • Transmit no more than 50% of the time. •...
- Page 14 DUPLEX OPERATION VIA REPEATERS DETAILED EXPLANATION OF DUPLEX This feature allows the use of local repeater stations that are designed to automatically re-transmit your broadcast over large areas, thus increasing the range of the UHF radio. Repeater stations are privately operated radio systems and are installed throughout Australia each repeater station oper- ates on preset channels.
- Page 15 UHF CB CHANNEL GUIDELINES RADIO COMMUNICATIONS (CITIZEN BAND RADIO STATIONS) CLASS Licence 2002 NOTE: The operation of your UHF radio in Australia and New Zealand is subject to conditions in the following Licences: In Australia, the ACMA Radio Communications (Citizen Band Radio Stations) and in New Zealand by MED the General User Radio Licence for Citizen Band Radio.
- Page 16 UHF CHANNELS AND FREQUENCIES UHF CHANNEL FREQUENCY TABLE PAGE 16...
- Page 17 UHF CHANNELS AND FREQUENCIES (continued) CTCSS TONE TABLE PAGE 17...
- Page 18 UHF CHANNELS AND FREQUENCIES (continued) DCS CODE TABLE PAGE 18...
- Page 19 UHF CHANNELS AND FREQUENCIES (continued) DCS CODE TABLE (continued) PAGE 19...
- Page 20 Australian Consumer Law in relation to the goods and services to which this warranty relates. PLU: 533227 CODE RR10PK Manufactured and packaged for SRGS PTY LTD ABN 23 113 230 050 751 Gympie Road, Lawnton Queensland 4501, Australia...
