Summary of Contents for Mamiya N Series
- Page 1 Focusing Screens N English Instructions...
- Page 2 Introduction Six focusing screens are available to address the needs of every photographer, subject and photographic application. Screen Properties Type A Matte An all matte screen with a Fresnel lens An all matte screen with a Fresnel lens Type A4 Checker and a grid pattern.
- Page 3 Set the Mirror Lock-up Lever to its ‘SQUARE’ position. Remove the lens. Slide the Focusing Screen Release Pin (1) to the left using the focusing screen tweezers. The Focusing Screen Frame (4) will drop down. Remove the focusing screen from the Focusing Screen Frame by grasping the focusing screen’s tab (3) with the tweezers, and then lifting the focusing screen up and out of the Focusing Screen Frame.
