- Page 1 Generation II Cartridge Filter with 6 Position Valve Model GEN 180 — Item No. 0-1802-019 Model GEN 240 — Item No. 0-1802-022 “the original portable pool” ® Owner's Guide *Shown with Power Pak III, not included. 365-1775...
- Page 2 “READ ALL INSTRUCTIONS” Failure to follow these important WARNING safety instructions and other basic safety precautions may result in serious personal injury. IMPORTANT SAFETY INSTRUCTIONS Before you begin installing your filter, refer to your pump PREVENT SEVERE SHOCK owners guide for very important installation and electri- To prevent the risk of severe electrical shock, plug your cal information related to your filter.
-
Page 3: Installation
Did you read the IMPORTANT SAFETY INSTRUC- TIONS? If not, READ THEM NOW. They contain very important safety information related to the installation of your filter. Familiarize yourself with the installation sequences by reading these instructions first. AVOID SHORTCUTS that may result in reworking the installa- SKIMMER RETURN tion. - Page 4 OPTION FOR HARD PLUMBING TO FILTER/VALVE RETURN PORT POOL RETURN If your option is to hard plumb the pump discharge to FITTING filter inlet, it will be necessary that you order a “hard plumb adaptor” (P/N 348-1036) and one “Clamp” (P/N 387-1024).
- Page 5 MODEL GEN 180 Insert the o-ring (63) into the union adaptor groove, then secure the cemented pipe assembly onto the union Install a 1-1/2" inside diameter waste discharge hose adaptor (62) with the union nut (65). (not supplied) on the waste port located on the 6 position valve.
-
Page 6: Initial Start-Up
WHEN TO CLEAN CARTRIDGES FILTER: Normal pool filtering position. May also be used when vacuuming the pool. The cleaning of the cartridges may occur depending on CLOSED: This position is used only when servicing local environmental conditions and sudden changes. pump or cleaning strainer basket. -
Page 7: Maintenance
9. CLEAN CARTRIDGES 16. CLOSE TANK DRAIN Attach the BLASTER NOZZLE to a garden hose. Replace the drain cap and gasket. Tighten securely Position cartridge in an upright position, supporting by hand. with one hand when cleaning. Hold the blaster 17. - Page 8 3. After servicing, reassemble and install in reverse. LUBE VALVE SHAFT Make sure tank O-Ring and sealing areas are free To lubricate the O-Ring on the valve shaft, depress of any dirt or grit and the o-ring is evenly seated valve handle fully and apply lubricant on the shaft before replacing cover.
-
Page 9: Exploded View
EXPLODED VIEW MODELS GEN 180 and 240 TO TOP PUMP PORT TO WASTE TO POOL RETURN TO FRONT PUMP PORT TO SKIMMER HI-FLOW RETURN PAK OWNER'S GUIDE WARRANTY CARD NOTE: CARTRIDGE CONFIGURATION FOR GEN 180 SHOWN (See Parts List for GEN 240 part quanities) - Page 10 PARTS LIST GENERATION II, MODELS GEN 180 AND 240 ITEM PART # DESCRIPTION 1121-1544 Tank - Model (GEN 180) 1121-1545 Tank - Model (GEN 240) 330-1172 #10 x 1/2" Screw 1121-1543 Tank Internal Adaptor w/Insert 308-1225 5/16" Thread Seal 330-1245 5/16-18 x 1-1/4"...
-
Page 11: Parts List
PARTS LIST GENERATION II, MODELS GEN 180 AND 240 ITEM PART # DESCRIPTION Pin Retainer 340-1195 340-1189 Valve Handle Cap 387-1023 #28 Band Clamp 346-1049 1-1/2" x 4' Hose Hose Adaptor 340-1224 308-1039 O-Ring - 1.925 I.D. 395-1014 2" Pressure Gauge 343-1042 Nozzle Blaster w/Washer Warranty Card... - Page 12 Note: Contact your pool dealer for any problems you cannot solve. WARNING Change of Design: Doughboy Recreational expressly reserves the right to change or modify the design PREVENT NO DIVING! and construction of any product in due course of our manufacturing procedures, without incurring any DROWNING Shallow water.
